SuperServer
®
5039MD8-H8TNR
5039MD18-H8TNR
USER'S MANUAL
Revision 1.0

Advertisement

Table of Contents
loading

Related Manuals for Supermicro SuperServer 5039MD8-H8TNR

Summary of Contents for Supermicro SuperServer 5039MD8-H8TNR

  • Page 1 SuperServer ® 5039MD8-H8TNR 5039MD18-H8TNR USER’S MANUAL Revision 1.0...
  • Page 2 State of California, USA. The State of California, County of Santa Clara shall be the exclusive venue for the resolution of any such disputes. Supermicro's total liability for all claims will not exceed the price paid for the hardware product.
  • Page 3 If you have any questions, please contact our support team at: support@supermicro.com This manual may be periodically updated without notice. Please check the Supermicro website for possible updates to the manual revision level. Warnings Special attention should be given to the following symbols used in this manual.

  • Page 4: Table Of Contents

    SuperServer 5039MD(8/18)-H8TNR User's Manual Contents Chapter 1 Introduction 1.1 Overview ..........................8 1.2 Unpacking the System ......................8 1.3 System Features .........................9 1.4 Chassis Features .......................10 Control Panel ........................10 Chassis Front ........................11 Chassis Rear ........................12 1.5 Motherboard Layout ......................13 Quick Reference .......................14 System Block Diagram ......................15 1.6 Where to Get Replacement Components ................16 1.7 Returning Merchandise for Service ..................16...
  • Page 5 Contents Chapter 3 Maintenance and Component Installation 3.1 Removing Power ........................26 3.2 Accessing the System ......................27 Removing a Computing Node ..................27 Removing the Chassis Cover ...................28 3.3 Motherboard Components ....................29 Memory ..........................29 Memory Support ......................29 DIMM Module Population Configuration ................29 Memory Population Guidelines ..................30 Memory Population Sequence ..................31 Installing Memory ......................32...
  • Page 6 SuperServer 5039MD(8/18)-H8TNR User's Manual Chapter 5 Software 5.1 Microsoft Windows OS Installation ..................51 5.2 Driver Installation ........................53 5.3 SuperDoctor 5 ........................54 ® 5.4 IPMI ............................55 Chapter 6 BIOS 6.1 Introduction .........................56 Starting BIOS Setup Utility ....................56 6.2 Main Setup .........................56 6.3 Advanced Setup Configurations ..................58 6.4 IPMI ...........................
  • Page 7 Super Micro Computer, Inc. 980 Rock Ave. San Jose, CA 95131 U.S.A. Tel: +1 (408) 503-8000 Fax: +1 (408) 503-8008 Email: marketing@supermicro.com (General Information) support@supermicro.com (Technical Support) Website: www.supermicro.com Europe Address: Super Micro Computer B.V. Het Sterrenbeeld 28, 5215 ML...

  • Page 8: Overview

    SuperServer 5039MD(8/18)-H8TNR User's Manual Chapter 1 Introduction 1.1 Overview This chapter provides a brief outline of the functions and features of the 5039MD(8/18)-H8TNR server. It is a 3U Micro-cloud system with eight computing nodes, each with an X11SDD-(8/18)C-F motherboard, all enclosed in the SC938NH-R1K68B chassis. In addition to the motherboards and chassis, several important parts that are included with the system are listed below.

  • Page 9: System Features

    Chapter 1: Introduction 1.3 System Features The following table is an overview of the main features of the 5039MD(8/18)-H8TNR server. System Features Motherboard (per node) X11SDD-8C-F for 5039MD8-H8TNR; X11SDD-18C-F for 5039MD18-H8TNR Chassis SC938NH-R1K68B CPU (per node) For 5039MD8-H8TNR single Intel Xeon D-2141I processor, 8 Core, 16 Threads, 65W, System on Chip For 5039MD18-H8TNR single Intel Xeon D-2191 processor, 18 Core, 36 Threads, 86W, System on Chip Memory (per node) Up to 512GB ECC LRDIMM or 256GB ECC RDIMM in four DDR4 slots with speed of up to 2400MHz...

  • Page 10: Chassis Features

    SuperServer 5039MD(8/18)-H8TNR User's Manual 1.4 Chassis Features Control Panel Power switches and status LEDs are located on the control panel on the front of the chassis. Figure 1-1. Control Panel Control Panel Features Item Features Description The main power switch applies or removes primary power from the power supply to Power button the chassis but maintains standby power.

  • Page 11: Chassis Front

    Chapter 1: Introduction Chassis Front The illustration below shows the features included on the front of the chassis. Figure 1-2. Front View Chassis Front Features Item Features Description Control Panel Power buttons and status indicators; details on the previous page Sixteen 3.5"...

  • Page 12: Chassis Rear

    SuperServer 5039MD(8/18)-H8TNR User's Manual Chassis Rear The illustration below shows the features included on the rear of the chassis. Computing nodes and power supply modules display status lights. Figure 1-3. Rear View Chassis Rear Features Item Features Description Each node features a power button, two LAN ports, one dedicated IPMI LAN port, 1 –...
  • Page 13 Chapter 1: Introduction Figure 1-4. Node I/O Features Connecting to a Node USB, COM, and VGA port capabilities can be added to any node through the KVM port on the rear. Plug in the adapter (dongle). Figure 1-5. Adapter to Provide USB, COM, and VGA Ports...

  • Page 14: Motherboard Layout

    SuperServer 5039MD(8/18)-H8TNR User's Manual 1.5 Motherboard Layout Below is a layout of the X11SDD-(8/18)C-F motherboard with jumper, connector and LED locations shown. See the table on the following page for descriptions. For detailed descriptions, pinout information and jumper settings, refer to Chapter 4. JKVM1 USB0/1 J3 - M.2...

  • Page 15: Quick Reference

    Chapter 1: Introduction Quick Reference Jumper Description Default Setting JBT1 CMOS Clear Open (Normal) (See Chapter 4) JPME2 Manufacture Mode Select (ME Mode Select) Pins 1-2 (Normal) JWD1 Watch Dog Timer Enable Pins 1-2 (Reset to System) Connector Description Onboard Battery FAN1 System Fan Header M.2 M-key Slot...

  • Page 16: System Block Diagram

    SuperServer 5039MD(8/18)-H8TNR User's Manual System Block Diagram PCIe3.0 x 16 PCIe x16 SLOT DIMMA DDR4 2666/2400/2133/1866 MHz DIMMB(Far) PCIe3.0 x 8 DIMMD PCIe x8 MLP SLOT DDR4 2666/2400/2133/1866 MHz DIMME(Far) PCIe3.0 x 4 2 NVMe PORTS PCIe3.0 x 4 2 HDD PORTS 2 SAS PORTS NVMe/SAS/SATA (from SAS AOC)

  • Page 17: Where To Get Replacement Components

    (http://www.supermicro.com/ support/rma/). Whenever possible, repack the chassis in the original Supermicro carton, using the original packaging material. If these are no longer available, be sure to pack the chassis securely, using packaging material to surround the chassis so that it does not shift within the carton and become damaged during shipping.

  • Page 18: Chapter 2 Server Installation

    SuperServer 5039MD(8/18)-H8TNR User's Manual Chapter 2 Server Installation 2.1 Overview This chapter provides advice and instructions for mounting your system in a server rack. If your system is not already fully integrated with processors, system memory etc., refer to Chapter 4 for details on installing those specific components. Caution: Electrostatic Discharge (ESD) can damage electronic components.

  • Page 19: Server Precautions

    Chapter 2: Server Installation • In single rack installations, stabilizers should be attached to the rack. In multiple rack in- stallations, the racks should be coupled together. • Always make sure the rack is stable before extending a server or other component from the rack.

  • Page 20: Circuit Overloading

    SuperServer 5039MD(8/18)-H8TNR User's Manual Circuit Overloading Consideration should be given to the connection of the equipment to the power supply circuitry and the effect that any possible overloading of circuits might have on overcurrent protection and power supply wiring. Appropriate consideration of equipment nameplate ratings should be used when addressing this concern.

  • Page 21: Installing The Rails

    Chapter 2: Server Installation 2.3 Installing the Rails There are a variety of rack units on the market, which may require a slightly different assembly procedure. This rail set fits a rack between 26.8" and 36.4" deep. The following is a basic guideline for installing the system into a rack with the rack mounting hardware provided.

  • Page 22: Releasing The Inner Rail

    SuperServer 5039MD(8/18)-H8TNR User's Manual Releasing the Inner Rail Each inner rail has a locking latch. This latch prevents the server from coming completely out of the rack when when the chassis is pulled out for servicing. To mount the rail onto the chassis, first release the inner rail from the outer rails. 1.

  • Page 23: Installing The Inner Rails On The Chassis

    Chapter 2: Server Installation Installing the Inner Rails on the Chassis Installing the Inner Rails 1. Identify the left and right inner rails. They are labeled. 2. Place the inner rail firmly against the side of the chassis, aligning the hooks on the side of the chassis with the holes in the inner rail.

  • Page 24: Installing The Outer Rails Onto The Rack

    SuperServer 5039MD(8/18)-H8TNR User's Manual Installing the Outer Rails onto the Rack Each end of the assembled outer rail includes a bracket with hooks and square, spring-loaded pegs to fit into the square holes in your rack. Installing the Outer Rail 1.

  • Page 25: Installing The Chassis Into A Rack

    Chapter 2: Server Installation 2.4 Installing the Chassis into a Rack Once rails are attached to the chassis and the rack, you can install the server. Warning: Mounting the system into the rack requires at least two people to support the chassis during installation.

  • Page 26: Removing The Chassis From The Rack

    SuperServer 5039MD(8/18)-H8TNR User's Manual Removing the Chassis from the Rack Caution! The system is heavy. It is dangerous for a single person to remove it from the rack. Have sufficient personnel or use a lift to support the chassis. 1. Pull the chassis forward out the front of the rack until it stops. 2.

  • Page 27: Chapter 3 Maintenance And Component Installation

    Chapter 3: Maintenance and Component Installation Chapter 3 Maintenance and Component Installation This chapter provides instructions on installing and replacing main system components. To prevent compatibility issues, only use components that match the specifications and/or part numbers given. Installation or replacement of most components require that power first be removed from the system.

  • Page 28: Accessing The System

    SuperServer 5039MD(8/18)-H8TNR User's Manual 3.2 Accessing the System The chassis contains eight computing nodes, each removable from the rear of the chassis while the others continue operating. Removing a Computing Node The two storage drives controlled by the node will power down upon removal. 1.

  • Page 29: Removing The Chassis Cover

    Chapter 3: Maintenance and Component Installation Removing the Chassis Cover You can access some chassis components, such as fans, by removing the cover. Screws Figure 3-2. Removing the Chassis Cover Removing the Chassis Cover The chassis top cover can be lifted off after removing three screws. Caution: Except for short periods of time, do not operate the server without the cover in place.

  • Page 30: Motherboard Components

    Memory Memory Support The X11SDD-8C-F motherboard supports up to 256GB Registered ECC RDIMM and up to 512GB LRDIMM in four slots. Check the Supermicro website for possible updates to memory support. DIMM Module Population Configuration For optimal memory performance, follow the table below when populating memory.

  • Page 31: Memory Population Guidelines

    • Balance memory. Using unbalanced memory topology, such as populating two DIMMs in one channel while populating one DIMM in another channel, reduces performance. It is not recommended for Supermicro systems. Guidelines Regarding Mixing DIMMs • Populating slots with a pair of DIMM modules of the same type and size results in inter- leaved memory, which improves memory performance.

  • Page 32: Memory Population Sequence

    SuperServer 5039MD(8/18)-H8TNR User's Manual Memory Population Sequence When installing memory modules, the DIMM slots should be populated in the following order: DIMMA1, DIMMB1, DIMMD1, DIMME1. Blue slots versus black slots: Install the first DIMM in the blue memory slot, which is the first of a memory channel.

  • Page 33: Installing Memory

    Chapter 3: Maintenance and Component Installation Installing Memory ESD Precautions Electrostatic Discharge (ESD) can damage electronic com ponents including memory modules. To avoid damaging DIMM modules, it is important to handle them carefully. The following measures are generally sufficient. • Use a grounded wrist strap designed to prevent static discharge.

  • Page 34: Motherboard Battery

    SuperServer 5039MD(8/18)-H8TNR User's Manual Motherboard Battery The motherboard uses non-volatile memory to retain system information when system power is removed. This memory is powered by a lithium battery residing on the motherboard. Replacing the Battery Begin by removing power from the system as described in section 3.1. 1.

  • Page 35: Chassis Components

    Chapter 3: Maintenance and Component Installation 3.4 Chassis Components This section provides instructions on installing and replacing system components. To assure compatibility, only use components that match the specifications or part numbers given. Corresponding Nodes, Fans and Hard Drives The SC938BH-R1620B chassis contains eight individual nodes each containing a motherboard. Each node controls two storage drives and shares a fan with the node beside it.

  • Page 36: Storage Drives

    Blinking at 1 Hz Attention state—do not remove NVMe device (not supported in VMD mode) Note: Enterprise level hard disk drives are recommended for use in Supermicro chassis and servers. For information on recommended HDDs, visit the Supermicro website at https://www.
  • Page 37 Chapter 3: Maintenance and Component Installation Removing a Hot-Swap Drive Carrier from the Chassis 1. Press the release button on the drive carrier, which will extend the drive carrier handle. 2. Use the drive carrier handle to pull the drive out of the chassis. Figure 3-6.
  • Page 38 SuperServer 5039MD(8/18)-H8TNR User's Manual Installing a Drive 1. Remove the dummy drive, which comes pre-installed in the drive carrier, by removing the screws securing the dummy drive to the carrier. These screws are not used to mount the actual drive. Dummy Drive Drive Carrier Figure 3-7.
  • Page 39 Chapter 3: Maintenance and Component Installation Hot-Swap for NVMe Drives Supermicro servers support NVMe surprise hot-swap. For even better data security, NVMe orderly hot-swap is recommended. NVMe drives can be ejected and replaced remotely using IPMI. Note: If you are using VROC, see the VROC appendix in this manual instead.
  • Page 40 SuperServer 5039MD(8/18)-H8TNR User's Manual Checking the Temperature of an NVMe Drive There are two ways to check using IPMI. Checking a Drive • IPMI > Server Health > NVMe SSD – Shows the temperatures of all NVMe drives, as in Figure 3-8.

  • Page 41: Solid State Drives

    Chapter 3: Maintenance and Component Installation M.2 Solid State Drives Up to two M.2 solid state drives (SSDs) can be installed in socket J2 and J3 (see Section 1.5) • M.2 Interface: 2 PCI-E 3.0 x4 • M.2 Form Factor: 2280/22110 •...

  • Page 42: System Cooling

    2. Squeeze both release tabs on the top of the fan module and pull it out. 3. Replace the failed fan with an identical fan, available from Supermicro. Push the new fan into the housing, making sure the air flow direction is the same.

  • Page 43: Installing The Air Shroud

    Chapter 3: Maintenance and Component Installation Installing the Air Shroud Air shrouds and air blocks concentrate airflow to maximize fan efficiency. Air block is pre- installed and may be uninstalled by removing the two screws. Installing the Air Shroud 1. Power down the node and remove it. If an expansion card is used, install it first. 2.

  • Page 44: Power Supply

    The system features redundant power supplies. The system will continue to operate if one module fails. It should be replaced as soon as convenient. They can be changed without powering down the system. New units can be ordered directly from Supermicro or authorized distributors.
  • Page 45 Chapter 3: Maintenance and Component Installation Release Tab Figure 3-12. Replacing the Power Supply Changing the Power Supply Module: 1. Unplug the AC cord from the module to be replaced. 2. On the back of the module, push the release tab, and pull the module out using the handle.

  • Page 46: Pci Expansion Cards

    SuperServer 5039MD(8/18)-H8TNR User's Manual PCI Expansion Cards The system supports one low-profile PCI-E card in each of the eight nodes with the included riser card (RSC-RR1U-E16). Installing an Expansion Card 1. Power-down the node and remove it. 2. Remove the two screws that secure the PCI bracket to the motherboard tray. 3.
  • Page 47 Chapter 3: Maintenance and Component Installation 5. Insert the expansion card into the riser card, which is pre-installed on the motherboard (if desired the riser card may be removed from the motherboard by removing the riser card screw). 6. Slide the add-on cards bracket into the PCI card slot and fit it with the opening in the rear of the node.

  • Page 48: Chapter 4 Motherboard Connections

    SuperServer 5039MD(8/18)-H8TNR User's Manual Chapter 4 Motherboard Connections This section describes the connections on the motherboard and provides pinout definitions. Note that depending on how the system is configured, not all connections are required. The LEDs on the motherboard are also described here. A motherboard layout indicating component locations may be found in Chapter 1.
  • Page 49 The JTPM1 header is used to connect a Trusted Platform Module (TPM)/Port 80, which is available from Supermicro. A TPM/Port 80 connector is a security device that supports encryption and authentication in hard drives. It allows the motherboard to deny access if the TPM associated with the hard drive is not installed in the system.

  • Page 50: Input/Output Ports

    SuperServer 5039MD(8/18)-H8TNR User's Manual 4.3 Input/Output Ports Rear I/O Ports The rear of each node offers two Gb Ethernet ports, control switches and a KVM port. Figure 4-2. Rear I/O Ports Description KVM Connector Power Switch UID Switch Figure 1-5. Adapter to Provide USB, COM, and VGA Ports KVM port With a KVM dongle, each node offers two USB 2.0 ports, one VGA port and one COM port.

  • Page 51: Jumpers

    Chapter 4: Motherboard Connections 4.4 Jumpers Explanation of Jumpers To modify the operation of the motherboard, jumpers are used to choose between optional settings. Jumpers create shorts between two pins to change the function associated with it. Pin 1 is identified with a square solder pad on the printed circuit board. See the motherboard layout page for jumper locations.
  • Page 52 SuperServer 5039MD(8/18)-H8TNR User's Manual Watch Dog JWD1 controls the Watch Dog function. Watch Dog is a monitor that can reboot the system when a software application hangs. Jumping pins 1-2 will cause Watch Dog to reset the system if an application hangs. Jumping pins 2-3 will generate a non-maskable interrupt signal for the application that hangs.

  • Page 53: Led Indicators

    Chapter 4: Motherboard Connections 4.5 LED Indicators LAN LEDs The Ethernet ports each have two LEDs. One LED indicates activity when flashing, while the other LED may be green, amber or off to indicate the speed of the connection. LAN LED (Connection Speed Indicator) LED Color...

  • Page 54: Chapter 5 Software

    USB/SATA DVD drive, or a USB flash drive, or the IPMI KVM console. 2. Retrieve the proper RST/RSTe driver. Go to the Supermicro web page for your motherboard and click on "Download the Latest Drivers and Utilities", select the proper driver, and copy it to a USB flash drive.
  • Page 55 Chapter 5: Software 4. During Windows Setup, continue to the dialog where you select the drives on which to install Windows. If the disk you want to use is not listed, click on “Load driver” link at the bottom left corner. Figure 5-2.

  • Page 56: Driver Installation

    The Supermicro website contains drivers and utilities for your system at https://www. supermicro.com/wftp/driver. Some of these must be installed, such as the chipset driver. After accessing the website, go into the CDR_Images (in the parent directory of the above link) and locate the ISO file for your motherboard. Download this file to to a USB flash drive or a DVD.

  • Page 57: Superdoctor ® 5

    5.3 SuperDoctor ® The Supermicro SuperDoctor 5 is a program that functions in a command-line or web-based interface for Windows and Linux operating systems. The program monitors such system health information as CPU temperature, system voltages, system power consumption, fan speed, and provides alerts via email or Simple Network Management Protocol (SNMP).

  • Page 58: Ipmi

    Health drop-down menu. To access the other nodes within the same enclosure, click the IP address of the other nodes. In IPMI CLI view, typing the command "SMCIPMITool -tp info", allows the MCU information of all eight nodes to be displayed. For general documentation and information on IPMI, please visit our website at: http://www.supermicro.com/products/nfo/IPMI.cfm.

  • Page 59: Chapter 6 Bios

    Chapter 6: BIOS Chapter 6 BIOS 6.1 Introduction This chapter describes the AMI BIOS setup utility for the X11SDD-8C-F and provides the instructions on navigating the setup screens. The BIOS is stored in a Flash EEPROM and can be updated. Note: Due to periodic changes to the BIOS, some settings may have been added or deleted since this manual was published.
  • Page 60 HH:MM:SS format. Note: The time is in the 24-hour format. For example, 5:30 P.M. appears as 17:30:00. The date's default value is 01/01/2016 after RTC reset. Supermicro X11SDD-8C-F (Motherboard model) BIOS Version Build Date (of the BIOS) CPLD (Complex Programmable Logic Device) Version: This item displays the CPLD version used in the system.

  • Page 61: Advanced Setup Configurations

    Chapter 6: BIOS 6.3 Advanced Setup Configurations Use the arrow keys to select the Advanced tab and press <Enter> to access the submenu items. Caution: Take caution when changing the Advanced settings. An incorrect value, a very high DRAM frequency, or an incorrect DRAM timing setting may make the system unstable. If this occurs, revert to the manufacture default settings.
  • Page 62 SuperServer 5039MD(8/18)-H8TNR User's Manual Wait For "F1" If Error This feature forces the system to wait until the F1 key is pressed if an error occurs. The options are Disabled and Enabled. Interrupt 19 Capture Interrupt 19 is the software interrupt that handles the boot disk function. When this feature is set to Immediate, the ROM BIOS of the host adaptors will "capture"...
  • Page 63 Chapter 6: BIOS CPU Configuration  The following CPU information will display: • Processor BSP Revision • Processor Socket • Processor ID • Processor Frequency • Processor Max Ratio • Processor Min Ratio • Microcode Revision • L1 Cache RAM •...
  • Page 64 SuperServer 5039MD(8/18)-H8TNR User's Manual Hardware Prefetcher If set to Enable, the hardware prefetcher will prefetch streams of data and instructions from the main memory to the L2 cache to improve CPU performance. The options are Disabled and Enabled. Adjacent Cache Line Prefetch The CPU prefetches the cache line for 64 bytes if this feature is set to Disabled.
  • Page 65 Chapter 6: BIOS SpeedStep (Pstates) Intel SpeedStep Technology allows the system to automatically adjust processor voltage and core frequency to reduce power consumption and heat dissipation. The options are Disable and Enable. EIST PSD Function This feature allows the user to choose between Hardware and Software to control the processor's frequency and performance (P-state).
  • Page 66 SuperServer 5039MD(8/18)-H8TNR User's Manual Enhanced Halt State (C1E) Select Enable to use Enhanced Halt State technology, which will significantly reduce the CPU's power consumption by reducing its clock cycle and voltage during a Halt state. The options are Disable and Enable. Package C State Control Package C State This feature allows the user to set the limit on the C State package register.
  • Page 67 Chapter 6: BIOS tCCD_L Relaxation Select Auto to get TCDD settings from SPD (Serial Presence Detect) and implement into memory RC code to improve system reliability. Select Disable for TCCD to follow Intel POR. The options are Auto, Disable, and Enable. tRWSR Relaxation Select Enable to override the tRWSR timing with optimized values.
  • Page 68 SuperServer 5039MD(8/18)-H8TNR User's Manual Memory Rank Sparing Select Enable to enable memory-sparing support for memory ranks to improve memory performance. The options are Disable and Enable. Correctable Error Threshold Use this feature to specify the threshold value for correctable memory error logging, which sets a limit on the maximum number of events that can be logged in the memory error log at a given time.
  • Page 69 Chapter 6: BIOS Socket 0 PcieBr0D00F0 - Port 0/DMI   Socket 0 PcieBr1D00F0 - Port 1A Socket 0 PcieBr1D01F0 - Port 1B  Socket 0 PcieBr1D02F0 - Port 1C  Socket 0 PcieBr2D00F0 - Port A2  Socket 0 PcieBr4D00F0 - MCP 0 ...
  • Page 70 SuperServer 5039MD(8/18)-H8TNR User's Manual Intel® VT for Directed I/O (VT-d)  Intel VT for Directed I/O (VT-d) ® Select Enable to use Intel Virtualization Technology for Direct I/O VT-d support by reporting the I/O device assignments to the VMM (Virtual Machine Monitor) through the DMAR ACPI tables.
  • Page 71 Chapter 6: BIOS *If the feature above is set to Enable, the following features will become avail- able for configuration: VMD port 1A/1B/1C/1D Select Enable to use the Intel Volume Management Device Technology for this spe- cific root port. The options are Disable and Enable. Hot Plug Capable (Available when the device is detected by the system) Use this feature to enable hot plug support for PCIe root ports 1A~1D.
  • Page 72 SuperServer 5039MD(8/18)-H8TNR User's Manual Hot Plug Capable (Available when the device is detected by the system) Use this feature to enable hot plug support for PCIe root ports 1A~1D. The options are Disable and Enable. CfgBar size Use this feature to set up the VMD config BAR size. The default value is 25. CfgBar attribute Use this feature to set up the VMD config BAR attribute.
  • Page 73 Chapter 6: BIOS CfgBar attribute Use this feature to set up the VMD config BAR attribute. The default option is 64-bit prefetchable. MemBar1 size Use this feature to set up the VMD Memory BAR1 size. The default value is 25. MemBar1 attribute Use this feature to set up the VMD config BAR attribute.
  • Page 74 SuperServer 5039MD(8/18)-H8TNR User's Manual Port 60/64 Emulation This feature allows legacy I/O support for USB devices like mice and keyboards. The options are Enabled and Disabled. PCIe PLL SSC Use this feature to enable or disable PCIe PLL SSC. The options are Disabled and Enabled. Install Window 7 USB Support Enable this feature to use the USB keyboard and mouse during the Windows 7 installation, since the native XHCI driver support is unavailable.
  • Page 75 Chapter 6: BIOS SATA HDD Unlock This feature allows the user to remove any password-protected SATA disk drives. The options are Enable and Disable. Aggressive Link Power Management When this feature is enabled, the SATA AHCI controller manages the power usage of the SATA link.
  • Page 76 SuperServer 5039MD(8/18)-H8TNR User's Manual sSATA Configuration  When this submenu is selected, the AMI BIOS automatically detects the presence of the SATA devices that are supported by the Intel PCH chipset and displays the following items: sSATA Controller Use this feature to enable or disable the onboard SATA controller supported by the Intel PCH chipset.
  • Page 77 Chapter 6: BIOS PCIe/PCI/PnP Configuration  PCI Bus Driver Version PCI Devices Common Settings Above 4G Decoding (Available if the system supports 64-bit PCI decoding) Select Enabled to decode a PCI device that supports 64-bit in the space above 4G Address. The options are Disabled and Enabled.
  • Page 78 SuperServer 5039MD(8/18)-H8TNR User's Manual Onboard NVME 2 OPROM Use this feature to select which firmware to be loaded for the add-on card in this slot. The options are Disabled, Legacy, and EFI. CPU MICRO-LP PCI-E 3.0 X8 Use this feature to select which firmware to be loaded for the add-on card in this slot. The options are Disabled, Legacy, and EFI.
  • Page 79 Chapter 6: BIOS Media detect count Use this option to specify the number of times media will be checked. Press "+" or "-" on your keyboard to change the value. The default setting is 1. Super IO Configuration  Super IO Configuration Super IO Chip AST2500 Serial Port 1 Configuration Serial Port...
  • Page 80 SuperServer 5039MD(8/18)-H8TNR User's Manual Serial Port 2 Attribute Use this feature to select the serial port 2 mode. The options are SOL and COM. Serial Port Console Redirection  COM1 Console Redirection Select Enabled to enable COM1 for Console Redirection, which will allow a client machine to be connected to a host machine at a remote site for networking.
  • Page 81 Chapter 6: BIOS Stop Bits A stop bit indicates the end of a serial data packet. Select 1 Stop Bit for standard serial data communication. Select 2 Stop Bits if slower devices are used. The options are 1 and 2. Flow Control Use this feature to set the flow control for Console Redirection to prevent data loss caused by buffer overflow.
  • Page 82 SuperServer 5039MD(8/18)-H8TNR User's Manual and function key support. Select ANSI to use the Extended ASCII Character Set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes. The options are VT100, VT100+, VT-UTF8, and ANSI. Bits per second Use this feature to set the transmission speed for a serial port used in Console Redirection.
  • Page 83 Chapter 6: BIOS Putty KeyPad This feature selects Function Keys and KeyPad settings for Putty, which is a terminal emulator designed for the Windows OS. The options are VT100, LINUX, XTERMR6, SCO, ESCN, and VT400. Legacy Console Redirection Legacy Console Redirection Settings ...
  • Page 84 SuperServer 5039MD(8/18)-H8TNR User's Manual Terminal Type Use this feature to select the target terminal emulation type for Console Redirection. Select VT100 to use the ASCII character set. Select VT100+ to add color and function key support. Select ANSI to use the extended ASCII character set. Select VT-UTF8 to use UTF8 encoding to map Unicode characters into one or more bytes.
  • Page 85 Chapter 6: BIOS Trusted Computing  *This motherboard supports TPM 1.2 and 2.0. The following Trusted Platform Module (TPM) information will display if a TPM 2.0 module is detected: • Vendor • Firmware Version Security Device Support If this feature and the TPM jumper on the motherboard are both set to Enabled, onboard security devices will be enabled for TPM support to enhance data integrity and network security.
  • Page 86 SuperServer 5039MD(8/18)-H8TNR User's Manual PH Randomization Use this feature to disable or enable Platform Hiearchy (PH) Randomization. The options are Disabled and Enabled. TXT Support Intel Trusted Execution Technology (TXT) helps protect against software-based attacks and ensures protection, confidentiality, and integrity of data stored or created on the system. Use this feature to enable or disable TXT Suppport.
  • Page 87 Chapter 6: BIOS  Delete Certification Use this feature to delete certification. Intel® Virtual RAID on CPU  This submenu displays RAID volumes, if detected by the system. All Cpu Information  The following CPU information will display: • Total CPU Number •...

  • Page 88: Ipmi

    SuperServer 5039MD(8/18)-H8TNR User's Manual 6.4 IPMI Use this tab page to configure Intelligent Platform Management Interface (IPMI) settings. The following items will be displayed: • IPMI Firmware Revision • Status of BMC System Event Log Enabling/Disabling Options SEL Components Select Enabled for all system event logging at boot up. The options are Disabled and Enabled.
  • Page 89 Chapter 6: BIOS to keep all system event logs after each system reboot. The options are No, Yes, On next reset, and Yes, On every reset. When SEL is Full This feature allows the user to determine what the BIOS should do when the system event log is full.
  • Page 90 SuperServer 5039MD(8/18)-H8TNR User's Manual VLAN This feature is configurable if the Update IPMI LAN Configuration feature is set to Yes. Use this feature to enable or disable the IPMI VLAN function. The options are Disable and Enable. *If the feature above is set to Enable, the VLAN feature below is available for configuration: VLAN Use this feature to select a value for VLAN ID.

  • Page 91: Security

    Chapter 6: BIOS 6.5 Security Use this tab page to configure Security settings. Administrator Password Use this feature to set the administrator password which is required to enter the BIOS setup utility. The length of the password should be from 3 to 20 characters long. User Password Use this feature to set a user password.
  • Page 92 SuperServer 5039MD(8/18)-H8TNR User's Manual Secure Boot Select Enable for secure boot support to ensure system security at boot up. The options are Disabled and Enabled. Secure Boot Mode This feature allows the user to select the desired secure boot mode for the system. The options are Standard and Custom.
  • Page 93 Chapter 6: BIOS  Restore DB defaults Select Yes to restore all DBs to the default settings. The options are Yes and No. Secure Boot variable  Platform Key (PK) Details Select this feature to view the details of the Platform Key. Export Select Yes to export a PK from a file on an external media.
  • Page 94 SuperServer 5039MD(8/18)-H8TNR User's Manual Append Select Yes to add the db from the manufacturer's defaults list to the existing db. Select No to load the db from a file. The options are Yes and No. Delete Select Ok to remove the db and then the system will reset to Setup/Audit Mode. ...

  • Page 95: Event Logs

    Chapter 6: BIOS 6.6 Event Logs Use this tab page to configure Event Log settings. Change SMBIOS Event Log Settings  Enabling/Disabling Options Smbios Event Log Change this feature to enable or disable all features of the SMBIOS Event Logging during system boot.

  • Page 96: Boot

    SuperServer 5039MD(8/18)-H8TNR User's Manual Smbios Event Log Standard Settings Log System Boot Event Select Enabled to log system boot events. The options are Enabled and Disabled. MECI (Multiple Event Count Increment) Enter the increment value for the multiple event counter. Enter a number between 1 to 255. The default setting is 1.
  • Page 97 Chapter 6: BIOS Setup Prompt Timeout Use this feature to specify the length of time (the number of seconds) for the BIOS to wait before rebooting the system when the setup activation key is pressed. Enter the value of 65535 (0xFFFF) for the BIOS to wait indefinitely. The default setting is 1. Boot mode select Use this feature to select the boot mode.

  • Page 98: Save & Exit

    SuperServer 5039MD(8/18)-H8TNR User's Manual 6.8 Save & Exit Use this tab page to configure Save & Exit settings. Save Options Discard Changes and Exit Select this feature to quit the BIOS Setup without making any permanent changes to the system configuration and reboot the computer. Select Discard Changes and Exit from the Exit menu and press <Enter>.
  • Page 99 Chapter 6: BIOS Default Options Restore Defaults To set this feature, select Restore Optimized Defaults and press <Enter>. These are factory settings designed for maximum system performance but not for maximum stability. Save as User Defaults To set this feature, select Save as User Defaults from the Exit menu and press <Enter>. This enables the user to save any changes to the BIOS setup for future use.

  • Page 100: Appendix A Bios Error Codes

    When BIOS performs the Power On Self Test, it writes checkpoint codes to I/O port 0080h. If the computer cannot complete the boot process, a diagnostic card can be attached to the computer to read I/O port 0080h (Supermicro p/n AOC-LPC80-20). For information on AMI updates, please refer to http://www.ami.com/products/.

  • Page 101: Appendix B Standardized Warning Statements For Ac Systems

    Supermicro's Technical Support department for assistance. Only certified technicians should attempt to install or configure components. Read this appendix in its entirety before installing or configuring components in the Supermicro chassis. These warnings may also be found on our website at http://www.supermicro.com/about/...
  • Page 102 Appendix B: Standardized Warning Statements Warnung WICHTIGE SICHERHEITSHINWEISE Dieses Warnsymbol bedeutet Gefahr. Sie befinden sich in einer Situation, die zu Verletzungen führen kann. Machen Sie sich vor der Arbeit mit Geräten mit den Gefahren elektrischer Schaltungen und den üblichen Verfahren zur Vorbeugung vor Unfällen vertraut. Suchen Sie mit der am Ende jeder Warnung angegebenen Anweisungsnummer nach der jeweiligen Übersetzung in den übersetzten Sicherheitshinweisen, die zusammen mit diesem Gerät ausgeliefert wurden.
  • Page 103 SuperServer 5039MD(8/18)-H8TNR User's Manual . ٌ ‫ا ك ً ف حالة و ٌ يك أى تتسبب ف اصابة جسذ ة ٌ هذا الزهز ع ٌ خطز !تحذ ز‬ ‫قبل أى تعول عىل أي هعذات،يك عىل علن بالوخاطز ال ا ٌجوة عي الذوائز‬ ٍ...
  • Page 104 Appendix B: Standardized Warning Statements Warnung Vor dem Anschließen des Systems an die Stromquelle die Installationsanweisungen lesen. ¡Advertencia! Lea las instrucciones de instalación antes de conectar el sistema a la red de alimentación. Attention Avant de brancher le système sur la source d'alimentation, consulter les directives d'installation. .‫יש...
  • Page 105 SuperServer 5039MD(8/18)-H8TNR User's Manual Warnung Dieses Produkt ist darauf angewiesen, dass im Gebäude ein Kurzschluss- bzw. Überstromschutz installiert ist. Stellen Sie sicher, dass der Nennwert der Schutzvorrichtung nicht mehr als: 250 V, 20 A beträgt. ¡Advertencia! Este equipo utiliza el sistema de protección contra cortocircuitos (o sobrecorrientes) del edificio.
  • Page 106 Appendix B: Standardized Warning Statements Power Disconnection Warning Warning! The system must be disconnected from all sources of power and the power cord removed from the power supply module(s) before accessing the chassis interior to install or remove system components. 電源切断の警告...
  • Page 107 SuperServer 5039MD(8/18)-H8TNR User's Manual ‫يجب فصم اننظاو من جميع مصادر انطاقت وإ ز انت سهك انكهرباء من وحدة امداد‬ ‫انطاقت قبم‬ ‫انىصىل إىن امنناطق انداخهيت نههيكم نتثبيج أو إ ز انت مكىناث الجهاز‬ 경고! 시스템에 부품들을 장착하거나 제거하기 위해서는 섀시 내부에 접근하기 전에 반드시 전원 공급장치로부터...
  • Page 108 Appendix B: Standardized Warning Statements Attention Il est vivement recommandé de confier l'installation, le remplacement et la maintenance de ces équipements à des personnels qualifiés et expérimentés. !‫אזהרה‬ .‫צוות מוסמך בלבד רשאי להתקין, להחליף את הציוד או לתת שירות עבור הציוד‬ ‫واملدربيه...
  • Page 109 SuperServer 5039MD(8/18)-H8TNR User's Manual Warnung Diese Einheit ist zur Installation in Bereichen mit beschränktem Zutritt vorgesehen. Der Zutritt zu derartigen Bereichen ist nur mit einem Spezialwerkzeug, Schloss und Schlüssel oder einer sonstigen Sicherheitsvorkehrung möglich. ¡Advertencia! Esta unidad ha sido diseñada para instalación en áreas de acceso restringido. Sólo puede obtenerse acceso a una de estas áreas mediante la utilización de una herramienta especial, cerradura con llave u otro medio de seguridad.
  • Page 110 Appendix B: Standardized Warning Statements Battery Handling Warning! There is the danger of explosion if the battery is replaced incorrectly. Replace the battery only with the same or equivalent type recommended by the manufacturer. Dispose of used batteries according to the manufacturer's instructions 電池の取り扱い...
  • Page 111 SuperServer 5039MD(8/18)-H8TNR User's Manual ‫هناك خطر من انفجار يف حالة اسحبذال البطارية بطريقة غري صحيحة فعليل‬ ‫اسحبذال البطارية‬ ‫فقط بنفس النىع أو ما يعادلها مام أوصث به الرشمة املصنعة‬ ‫جخلص من البطاريات املسحعملة وفقا لحعليامت الرشمة الصانعة‬ 경고! 배터리가 올바르게 교체되지 않으면 폭발의 위험이 있습니다. 기존 배터리와 동일하거나 제 조사에서...
  • Page 112 Appendix B: Standardized Warning Statements ¡Advertencia! Puede que esta unidad tenga más de una conexión para fuentes de alimentación. Para cortar por completo el suministro de energía, deben desconectarse todas las conexiones. Attention Cette unité peut avoir plus d'une connexion d'alimentation. Pour supprimer toute tension et tout courant électrique de l'unité, toutes les connexions d'alimentation doivent être débranchées.
  • Page 113 SuperServer 5039MD(8/18)-H8TNR User's Manual Backplane Voltage Warning! Hazardous voltage or energy is present on the backplane when the system is operating. Use caution when servicing. バックプレーンの電圧 システムの稼働中は危険な電圧または電力が、 バックプレーン上にかかっています。 修理する際には注意く ださい。 警告 当系统正在进行时，背板上有很危险的电压或能量，进行维修时务必小心。 警告 當系統正在進行時，背板上有危險的電壓或能量，進行維修時務必小心。 Warnung Wenn das System in Betrieb ist, treten auf der Rückwandplatine gefährliche Spannungen oder Energien auf.
  • Page 114 Appendix B: Standardized Warning Statements ‫هناك خطز مه التيار الكهزبايئ أوالطاقة املىجىدة عىل اللىحة‬ ‫عندما يكىن النظام يعمل كه حذ ر ا عند خدمة هذا الجهاس‬ 경고! 시스템이 동작 중일 때 후면판 (Backplane)에는 위험한 전압이나 에너지가 발생 합니다. 서비스 작업 시 주의하십시오. Waarschuwing Een gevaarlijke spanning of energie is aanwezig op de backplane wanneer het systeem in gebruik is.
  • Page 115 SuperServer 5039MD(8/18)-H8TNR User's Manual ‫תיאום חוקי החשמל הארצי‬ !‫אזהרה‬ .‫התקנת הציוד חייבת להיות תואמת לחוקי החשמל המקומיים והארציים‬ ‫تركيب املعدات الكهربائية يجب أن ميتثل للقىاويه املحلية والىطىية املتعلقة‬ ‫بالكهرباء‬ 경고! 현 지역 및 국가의 전기 규정에 따라 장비를 설치해야 합니다. Waarschuwing Bij installatie van de apparatuur moet worden voldaan aan de lokale en nationale elektriciteitsvoorschriften.
  • Page 116 Appendix B: Standardized Warning Statements Attention La mise au rebut ou le recyclage de ce produit sont généralement soumis à des lois et/ou directives de respect de l'environnement. Renseignez-vous auprès de l'organisme compétent. ‫סילוק המוצר‬ !‫אזהרה‬ .‫סילוק סופי של מוצר זה חייב להיות בהתאם להנחיות וחוקי המדינה‬ ‫التخلص...
  • Page 117 SuperServer 5039MD(8/18)-H8TNR User's Manual Warnung Gefährlich Bewegende Teile. Von den bewegenden Lüfterblätter fern halten. Die Lüfter drehen sich u. U. noch, wenn die Lüfterbaugruppe aus dem Chassis genommen wird. Halten Sie Finger, Schraubendreher und andere Gegenstände von den Öffnungen des Lüftergehäuses entfernt.
  • Page 118 Verbindungskabeln, Stromkabeln und/oder Adapater, die Ihre örtlichen Sicherheitsstandards einhalten. Der Gebrauch von anderen Kabeln und Adapter können Fehlfunktionen oder Feuer verursachen. Die Richtlinien untersagen das Nutzen von UL oder CAS zertifizierten Kabeln (mit UL/CSA gekennzeichnet), an Geräten oder Produkten die nicht mit Supermicro gekennzeichnet sind.
  • Page 119 ‫.قيرح وأ لطع يف ببستي دق ىرخأ تالوحمو تالباك يأ مادختسا .ميلسلا سباقلاو لصوملا مجح‬ ‫ لبق نم ةدمتعملا تالباكلا مادختسا تادعملاو ةيئابرهكلا ةزهجألل ةمالسلا نوناق رظحي‬UL ‫ وأ‬CSA ‫( ةمالع لمحت يتلاو‬UL/CSA) ‫ لبق نم ةددحملاو ةينعملا تاجتنملا ريغ ىرخأ تادعم يأ عم‬Supermicro.
  • Page 120 사항을 준수하여 제공되거나 지정된 연결 혹은 구매 케이블, 전원 케이블 및 AC 어댑터를 사용하십시오. 다른 케이블이나 어댑터를 사용하면 오작동이나 화재가 발생할 수 있습니다. 전기 용품 안전법은 UL 또는 CSA 인증 케이블 (코드에 UL / CSA가 표시된 케이블)을 Supermicro 가 지정한 제품 이외의 전기 장치에 사용하는 것을 금지합니다. Stroomkabel en AC-Adapter...

  • Page 121: Appendix C System Specifications

    Appendix C: System Specifications Appendix C System Specifications Processors (per node) For 5039MD8-H8TNR single Intel Xeon D-2141I processor, 8 Core, 16 Threads, 65W, System on Chip For 5039MD18-H8TNR single Intel Xeon D-2191 processor, 18 Core, 36 Threads, 86W, System on Chip Note: Please refer to the motherboard specifications pages on our website for updates to supported processors.
  • Page 122 SuperServer 5039MD(8/18)-H8TNR User's Manual Regulatory Compliance Electromagnetic Emissions: FCC Class A, EN 55032 Class A, EN 61000-3-2/3-3, CISPR 32 Class A Electromagnetic Immunity: EN 55024/CISPR 24, (EN 61000-4-2, EN 61000-4-3, EN 61000-4-4, EN 61000-4-5, EN 61000-4-6, EN 61000-4-8, EN 61000-4-11) Other: VCCI-CISPR 32 and AS/NZS CISPR 32 Environmental: Directive 2011/65/EU and Delegated Directive (EU) 2015/863 and Directive 2012/19/EU Safety: CSA/EN/IEC/UL 60950-1 Compliant, UL or CSA Listed (USA and Canada), CE Marking (Europe)

  • Page 123: Appendix D Uefi Bios Recovery

    Warning: Do not upgrade the BIOS unless your system has a BIOS-related issue. Flashing the wrong BIOS can cause irreparable damage to the system. In no event shall Supermicro be liable for direct, indirect, special, incidental, or consequential damages arising from a BIOS update.
  • Page 124 USB device or a writable CD/DVD. Note 1: If you cannot locate the "Super.ROM" file in your drive disk, visit our website at www.supermicro.com to download the BIOS package. Extract the BIOS binary image into a USB flash device and rename it "Super.ROM" for the BIOS recovery use.
  • Page 125 Appendix D: UEFI BIOS Recovery 3. After locating the healthy BIOS binary image, the system will enter the BIOS Recovery menu as shown below. Note: At this point, you may decide if you want to start the BIOS recovery. If you decide to proceed with BIOS recovery, follow the procedures below.
  • Page 126 SuperServer 5039MD(8/18)-H8TNR User Manual 5. After the BIOS recovery process is complete, press any key to reboot the system. 6. Using a different system, extract the BIOS package into a USB flash drive. 7. Press <Del> continuously during system boot to enter the BIOS Setup utility. From the top of the tool bar, select Boot to enter the submenu.
  • Page 127 Appendix D: UEFI BIOS Recovery 8. When the UEFI Shell prompt appears, type fs# to change the device directory path. Go to the directory that contains the BIOS package you extracted earlier from Step 6. Enter flash.nsh BIOSname.### at the prompt to start the BIOS update process. Note: Do not interrupt this process until the BIOS flashing is complete.

  • Page 128: Appendix E Ipmi Crash Dump

    In the event of a processor internal error (IERR) that crashes your system, you may want to provide information to support staff. You can download a crash dump of status information using IPMI. The IPMI manual is available at https://www.supermicro.com/solutions/IPMI.cfm. Check IPMI Error Log 1.
  • Page 129 Appendix E IPMI Crash Dump Downloading the Crash Dump File 1. In the IPMI interface, click the Miscellaneous tab, then the Trouble Shooting option. 2. Click the Dump button and wait five minutes for the file to be created. (No confirm ation message will appear.) 3.

  • Page 130: Appendix F Cpu-Based Raid For Nvme

    SuperServer 5039MD(8/18)-H8TNR User's Manual Appendix F CPU-Based RAID for NVMe Intel Virtual RAID on CPU (Intel VROC) is an enterprise RAID solution for NVMe SSDs ® directly attached to Intel Xeon Scalable processors. Intel Volume Management Device (VMD) is an integrated controller inside the CPU PCI-E root complex. •...
  • Page 131 Appendix F CPU-Based RAID for NVMe Additional Information Additional information is available on the product page for the Supermicro add-on card and the linked manuals. www.supermicro.com/products/accessories/addon/AOC-VROCxxxMOD.cfm F.1 Hardware Key The Intel VROC hardware key is a license key that detects the Intel VROC SKU and activates the function accordingly.
  • Page 132 SuperServer 5039MD(8/18)-H8TNR User's Manual F.2 Enabling NVMe RAID RAID for NVMe SSDs must be enabled through the UEFI BIOS. 1. Install the patch as described in the Restrictions and Requirements section on a previous page. 2. Reboot the server. 3. Press [DEL] key to enter BIOS. 4.
  • Page 133 Appendix F CPU-Based RAID for NVMe Figure F-3. Created Volume without Figure F-4. Created Volume with enabling RAID spanned over VMD enabling RAID spanned over VMD controller controller 12. Select specific disks for RAID with an [X]. • RAID0: Select at least two [2 - 24] disks •...
  • Page 134 SuperServer 5039MD(8/18)-H8TNR User's Manual F.4 Hot Swap Drives Intel VMD enables hot-plug and hot-unplug for NVMe SSDs, whether from Intel or other manufacturers. Under vSphere ESXi, several steps are necessary to avoid potential stability issues. See the information at link [1] below. Hot-unplug 1.

This manual is also suitable for:

Superserver 5039md18-h8tnr

Table of Contents
