- Page 1 INSTRUCTION MANUAL Cordless Screwdriver DFS250 DFS251 Read before use.
-
Page 2: Specifications
SPECIFICATIONS Model: DFS250 DFS251 Fastening Self drilling screw 6 mm capacities Drywall screw 5 mm No load speed (RPM) 0 - 2,500 min Overall With short locator 223 mm length With long locator 239 mm Overall length 217 mm Rated voltage D.C. -
Page 3: General Power Tool Safety Warnings
hearing protection used for appropriate conditions SAFETY WARNINGS will reduce personal injuries. Prevent unintentional starting. Ensure the switch is in the off-position before connecting General power tool safety warnings to power source and/or battery pack, picking up or carrying the tool. Carrying power tools with WARNING: your finger on the switch or energising power tools Read all safety warnings, instruc-... -
Page 4: Cordless Screwdriver Safety Warnings
Keep handles and grasping surfaces dry, Keep hands away from rotating parts. clean and free from oil and grease. Slippery Do not touch the bit or the workpiece immedi- handles and grasping surfaces do not allow for ately after operation; they may be extremely safe handling and control of the tool in unexpected hot and could burn your skin. -
Page 5: Functional Description
Only use genuine Makita batteries. Use of non-genuine Makita batteries, or batteries that have been altered, may result in the battery bursting causing fires, personal injury and damage. It will also void the Makita warranty for the Makita tool and charger. Tips for maintaining maximum battery life Fig.1... -
Page 6: Overload Protection
Indicator lamps Remaining capacity Lighted Blinking 25% to 50% 0% to 25% Charge the battery. The battery may have Fig.3 malfunctioned. ► 1 . Switch trigger 2. Lock button To start the tool, simply pull the switch trigger. Tool NOTE: Depending on the conditions of use and the speed is increased by increasing pressure on the switch ambient temperature, the indication may differ slightly trigger. -
Page 7: Depth Adjustment
NOTE: If the tool does not run for about 8 hours in CAUTION: Always check the direction of push drive mode with the trigger locked on, tool is rotation before operation. shutdown. In such a case, release and pull the trigger CAUTION: Use the reversing switch only after again for restarting. - Page 8 For DFS251 Installing or removing driver bit/ socket bit 3 mm (1/8") For DFS250 Fig.9 ► 1 . Locator Adjust the locator so that the distance between the tip of the locator and the screw head is approximately 3 Fig.11 mm (1/8") as shown in the figures. Drive a trial screw into your material or a piece of duplicate material. If the ► 1 .
-
Page 9: Maintenance
Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. OPTIONAL Fig.15 ► 1 . Groove 2. Hook 3. Screw ACCESSORIES The hook is convenient for temporarily hanging the tool. - Page 12 Makita Europe N.V. Jan-Baptist Vinkstraat 2, 3070 Kortenberg, Belgium Makita Corporation 3-11-8, Sumiyoshi-cho, Anjo, Aichi 446-8502 Japan 885536-224 www.makita.com 20160707...
