Summary of Contents for Iiyama ProLite T1532MSC-B1AG
- Page 1 USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for...
- Page 3 IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com...
-
Page 4: Table Of Contents
TABLE OF CONTENTS FOR YOUR SAFETY ................1 SAFETY PRECAUTIONS..............1 SPECIAL NOTES ON LCD MONITORS .........3 CUSTOMER SERVICE ..............3 CLEANING ..................3 BEFORE YOU OPERATE THE MONITOR ..........4 FEATURES..................4 CHECKING THE CONTENTS OF THE PACKAGE ......5 SPECIAL NOTES ON TOUCH PANEL..........5 WALL MOUNTING ................5 BUILT-IN EQUIPMENT ..............5 CONTROLS AND CONNECTORS..........6 CONNECTING YOUR MONITOR ...........7... -
Page 5: For Your Safety
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 7: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself. -
Page 8: Before You Operate The Monitor
VESA Mounting Standard (100mm×100mm) Compliant Keyhole for Security Lock IP54 Standard Compliant (Only front face) Glass with AG coating : ProLite T1532MSC-B1AG / ProLite T1732MSC-B1AG Windows8/8,1/10 touch environment Basic touch operations can be performed under Windows 8/8,1/10. -
Page 9: Checking The Contents Of The Package
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. -
Page 10: Controls And Connectors
CONTROLS AND CONNECTORS <Front> <Back> Menu Button ( Scroll Up / Brightness Button ( Scroll Down / Mute Button ( Select / Auto Button ( Power Switch ( Keyhole for Security Lock NOTE You can fasten a security lock and cable to prevent the monitor from being removed without your permission. -
Page 11: Connecting Your Monitor
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. -
Page 12: Computer Setting
Change to the desired signal timing listed on page 30: COMPLIANT TIMING. Windows XP/Vista/7/8/8.1/10 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows XP/Vista/7/8/8.1/10 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 13: Adjusting The Viewing Angle
ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor. Hold the panel so that the monitor does not topple when you change the monitor’s angle. You are able to adjust the monitor’s angle up to 90 degrees upward, 5 degrees downward. -
Page 14: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 30. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 16 for SCREEN ADJUSTMENTS. -
Page 15: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS CO NTRAST BRIG HTNESS 12 80 x 10 24 F H : 6 3K H z F V: 59. 9H z Adjustment Item Problem / Option Button to Press Too dull CONTRAST Too intense Too dark Direct BRIGHTNESS * Too bright * Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too... - Page 16 A U TO A D J U S T Only Analog Input H- P O S I T I O N V- P O S I T I O N H- S I Z E F I N E Adjustment Item Problem / Option Button to Press Direct...
- Page 17 O SD H - P OS ITIO N O S D V- P OS ITIO N O SD TI MEO U T R E SE T IN P U T SE LEC T Adjustment Item Problem / Option Button to Press OSD is too left OSD H-POSITION OSD is too right...
- Page 18 ENGLISH ESPAÑOL FRANÇAIS DEUTSCH ITALIANO Adjustment Item Problem / Option Button to Press ENGLISH English ESPAÑOL Spanish Japanese FRANÇAIS French OSD LANGUAGE DEUTSCH German Traditional Chinese Simplifi ed Chinese ITALIANO Italian 9300 6500 5500 GREEN 7500 BLUE USER Adjustment Item Problem / Option Button to Press 9300...
- Page 19 VOLUME MUTE Adjustment Item Problem / Option Button to Press Too soft VOLUME Too loud Turn off the sound temporarily. Direct MUTE Return the sound volume to the previous level. Direct You can skip the Menu items and display an adjustment scale directly by using the following button operations.
-
Page 20: Screen Adjustments
If the screen has a flicker or blur, or the picture does not fit in the display area after performing the Auto Adjust, manual adjustments are required. Both adjustments should be made by using the screen adjustment pattern (Test.bmp) obtained via the IIYAMA web site (http://www.iiyama. com). - Page 21 Press the Button. (AUTO ADJUST) Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. Adjust the V-POSITION so that the top and bottom of the picture frame will fit to the display area.
- Page 22 Adjust the FINE to correct horizontal wavy noise, fl icker or blur in the zebra pattern. In case the strong fl icker or blurs remain on a part of the screen, repeat steps NOTE because the H-SIZE may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again.
-
Page 23: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 24: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check ... -
Page 25: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. RECYCLING INFORMATION 21... -
Page 26: Appendix
APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite T1532MSC Model Name ProLite T1532MSC-B1 ProLite T1532MSC-B1AG Projected capacitive 2pt touch Projected capacitive 10pt touch Touch Technology Screen Light transmission 90% Communication USB serial transfer... - Page 27 Model Name ProLite T1532MSC-B1X Technology Projected capacitive 10pt touch Touch Screen Light transmission 90% Communication USB serial transfer system Size Category 15" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 15" (38cm) Pixel pitch 0.297mm H × 0.297mm V 250cd/m (Typical: without Touch panel), Brightness...
- Page 28 Model Name ProLite T1532MSC-B3X Projected capacitive 10pt touch Touch Technology Screen Light transmission 90% Communication USB serial transfer system Size Category 15" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 15" (38cm) Pixel pitch 0.297mm H × 0.297mm V 350cd/m (Typical: without Touch panel), Brightness...
-
Page 29: Specifications : Prolite T1732Msc
SPECIFICATIONS : ProLite T1732MSC Model Name ProLite T1732MSC-B1 ProLite T1732MSC-B1AG Touch Technology Projected capacitive 2pt touch Projected capacitive 10pt touch Screen Light transmission 90% Communication USB serial transfer system Size Category 17" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 17"... - Page 30 Model Name ProLite T1732MSC-B1X Touch Technology Projected capacitive 10pt touch Screen Light transmission 90% Communication USB serial transfer system Size Category 17" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 17" (43cm) Pixel pitch 0.264mm H × 0.264mm V Brightness 250cd/m (Typical: without Touch panel),...
-
Page 31: Specifications : Prolite T1932Msc
SPECIFICATIONS : ProLite T1932MSC Model Name ProLite T1932MSC-B1 ProLite T1932MSC-B1X Projected capacitive 10pt touch Touch Projected capacitive 2pt touch Technology Screen Light transmission 90% Communication USB serial transfer system Size Category 19" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 19"... - Page 32 Model Name ProLite T1932MSC-B2X Projected capacitive 10pt touch Touch Technology Screen Light transmission 90% Communication USB serial transfer system Size Category 19" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 19" (48cm) Pixel pitch 0.294mm H × 0.294mm V Brightness 250cd/m (Typical: without Touch panel),...
-
Page 33: Dimensions : Prolite T1532Msc
DIMENSIONS : ProLite T1532MSC 351.0mm/13.8” 54.5mm/2.1” 305.0mm/12.0” 222.5mm/8.7” DIMENSIONS : ProLite T1732MSC 387.0mm/15.2” 54.5mm/2.1” 339.0mm/13.3” 222.5mm/8.7” DIMENSIONS : ProLite T1932MSC 432.0mm/17.0” 54.5mm/2.1” 377.5mm/14.9” 249.5mm/9.8” APPENDIX 29... -
Page 34: Compliant Timing
COMPLIANT TIMING Horizontal Vertical Dot Clock Video Mode Frequency Frequency 59.940Hz 25.175MHz 31.469kHz 640 × 480 75.000Hz 31.500MHz 37.500kHz 72.809Hz 31.500MHz 37.861kHz 36.000MHz 56.250Hz 35.156kHz 60.317Hz 40.000MHz 37.879kHz SVGA 800 × 600 75.000Hz 49.500MHz 46.875kHz VESA 72.188Hz 50.000MHz 48.077kHz 60.004Hz 65.000MHz 48.363kHz 1024 ×...
