Page 1: User Manual
USER MANUAL ENGLISH Thank you very much for choosing the iiyama LCD monitor. We recommend that you take a few minutes to read this comprehensive manual carefully before installing and switching on the monitor. Please keep this manual in a safe place for... -
Page 3: Ce Marking Declaration Of Conformity
IIYAMA CORPORATION: Wijkermeerstraat 8, 2131 HA Hoofddorp, The Netherlands We recommend recycling of used product. Please contact your dealer or iiyama service center. Recycle information is obtained via the Internet, using the address: http://www.iiyama.com... -
Page 4: Table Of Contents
SCREEN ADJUSTMENTS ............16 POWER MANAGEMENT FEATURE ..........19 TROUBLE SHOOTING ..............20 RECYCLING INFORMATION .............21 APPENDIX ..................22 SPECIFICATIONS : ProLite T1532MSC ........22 SPECIFICATIONS : ProLite T1732MSC ........23 SPECIFICATIONS : ProLite T1932MSC ........24 DIMENSIONS : ProLite T1532MSC ..........26 DIMENSIONS : ProLite T1732MSC ..........26 DIMENSIONS : ProLite T1932MSC ..........26... -
Page 5: For Your Safety
Do not put any solid objects or liquids such as water into the monitor. In case of an accident, unplug your monitor immediately and contact your dealer or iiyama service center. Using the monitor with any object inside may cause fi re, electric shock or damage. - Page 6 CAUTION INSTALLATION LOCATION Do not install the monitor where sudden temperature changes may occur, or in humid, dusty or smoky areas as it may cause fi re, electric shock or damage. You should also avoid areas where the sun shines directly on the monitor. DO NOT PLACE THE MONITOR IN A HAZARDOUS POSITION The monitor may topple and cause injury if not suitably located.
-
Page 7: Special Notes On Lcd Monitors
Power Switch for hours. Contact your dealer or iiyama service center for the backlight replacement when the screen is dark, fl ickering or not lighting up. Never attempt to replace it by yourself. -
Page 8: Before You Operate The Monitor
BEFORE YOU OPERATE THE MONITOR FEATURES Supports Resolutions up to 1024 × 768 : ProLite T1532MSC Supports Resolutions up to 1280 × 1024 : ProLite T1732MSC / ProLite T1932MSC High Contrast 500:1 (Typical: with Touch panel) / Brightness 225cd/m... -
Page 9: Checking The Contents Of The Package
CHECKING THE CONTENTS OF THE PACKAGE The following accessories are included in your package. Check to see if they are enclosed with the monitor. If anything is missing or damaged, please contact your local iiyama dealer or regional iiyama offi ce. -
Page 10: Controls And Connectors
CONTROLS AND CONNECTORS <Front> <Back> Menu Button ( Scroll Up / Brightness Button ( Scroll Down / Mute Button ( Select / Auto Button ( Power Switch ( Keyhole for Security Lock NOTE You can fasten a security lock and cable to prevent the monitor from being removed without your permission. -
Page 11: Connecting Your Monitor
An incorrect connection may cause serious damage to both the monitor and the computer. The cable supplied with the monitor is for a standard connector. If a special cable is required please contact your local iiyama dealer or regional iiyama offi ce. -
Page 12: Computer Setting
Change to the desired signal timing listed on page 27: COMPLIANT TIMING. Windows 95/98/2000/Me/XP/Vista/7 Plug & Play The iiyama LCD monitor complies with DDC2B of VESA standard. The Plug & Play function runs on Windows 95/98/2000/Me/XP/Vista/7 by connecting the monitor to DDC2B compliant computer with the Signal Cable supplied. -
Page 13: Adjusting The Viewing Angle
ADJUSTING THE VIEWING ANGLE For optimal viewing it is recommended to look at the full face of the monitor. Hold the panel so that the monitor does not topple when you change the monitor’s angle. You are able to adjust the monitor’s angle up to 90 degrees upward, 5 degrees downward. -
Page 14: Operating The Monitor
OPERATING THE MONITOR To create the best picture, your iiyama LCD monitor has been preset at the factory with the COMPLIANT TIMING shown on page 27. You are also able to adjust the picture by following the button operation shown below. For more detailed adjustments, see page 16 for SCREEN ADJUSTMENTS. -
Page 15: Adjustment Menu Contents
ADJUSTMENT MENU CONTENTS CO NTRAST BRIG HTNESS 12 80 x 10 24 F H : 6 3K H z F V: 59. 9H z Adjustment Item Problem / Option Button to Press Too dull CONTRAST Too intense Too dark Direct BRIGHTNESS * Too bright * Adjust the Brightness when you are using the monitor in a dark room and feel the screen is too... - Page 16 A U TO A D J U S T Only Analog Input H- P O S I T I O N V- P O S I T I O N H- S I Z E F I N E Adjustment Item Problem / Option Button to Press Direct...
- Page 17 However it will automatically be selected when just one source is using. In Power Management Mode input switching is disabled. Input source is fi xed, not selected automatically when VGA and DVI which are selected. Available for ProLite T1532MSC-B1X, ProLite T1732MSC-B1X, ProLite T1932MSC-B1X Direct and ProLite T1932MSC-B2X only.
- Page 18 ENGLISH ESPAÑOL FRANÇAIS DEUTSCH ITALIANO Adjustment Item Problem / Option Button to Press ENGLISH English ESPAÑOL Spanish Japanese FRANÇAIS French OSD LANGUAGE DEUTSCH German Traditional Chinese Simplifi ed Chinese ITALIANO Italian 9300 6500 5500 GREEN 7500 BLUE USER Adjustment Item Problem / Option Button to Press 9300...
- Page 19 VOLUME MUTE Adjustment Item Problem / Option Button to Press Too soft VOLUME Too loud Turn off the sound temporarily. Direct MUTE Return the sound volume to the previous level. Direct You can skip the Menu items and display an adjustment scale directly by using the following button operations.
-
Page 20: Screen Adjustments
fl icker or blur for the particular computer in use. ProLite T1532MSC is designed to provide the best performance at resolution of 1024 × 768, but can not provide the best at resolutions of less than 1024 × 768 because the picture is automatically stretched to fi... - Page 21 Press the AUTO Button. (AUTO ADJUST) Adjust the image manually by following procedure below when the screen has a fl icker or blur, or the picture does not fi t in the display area after performing the Auto Adjust. Adjust the V-POSITION so that the top and bottom of the picture frame will fit to the display area.
- Page 22 Adjust the FINE to correct horizontal wavy noise, fl icker or blur in the zebra pattern. In case the strong fl icker or blurs remain on a part of the screen, repeat steps NOTE because the H-SIZE may not be adjusted correctly. If the fl icker or blurs still remain, set the refresh rate of computer to low (60Hz) and repeat steps from again.
-
Page 23: Power Management Feature
POWER MANAGEMENT FEATURE The power management feature of this product complies with power saving requirement of VESA DPMS. When activated, it automatically reduces unnecessary power consumption of the monitor when your computer is not in use. To use the feature, the monitor needs to be connected to a VESA DPMS compliant computer. There is a power management step the monitor takes as described below. -
Page 24: Trouble Shooting
MONITOR or if the problem persists. 3. If you are experiencing a problem which is not described below or you cannot correct the problem, discontinue using the monitor and contact your dealer or iiyama service center for further assistance. Problem Check ... -
Page 25: Recycling Information
RECYCLING INFORMATION For better environment protection please don't dispose your monitor. Please visit our web site: www.iiyama.com/recycle for monitor recycling. RECYCLING INFORMATION 21... -
Page 26: Appendix
APPENDIX Design and specifi cations are subject to change without prior notice. SPECIFICATIONS : ProLite T1532MSC Model Name ProLite T1532MSC-B1 ProLite T1532MSC-B1X Projected capacitive 2pt touch Projected capacitive 10pt touch Touch Technology Screen Light transmission 90% Communication USB serial transfer... -
Page 27: Specifications : Prolite T1732Msc
SPECIFICATIONS : ProLite T1732MSC Model Name ProLite T1732MSC-B1 ProLite T1732MSC-B1X Touch Technology Projected capacitive 2pt touch Projected capacitive 10pt touch Screen Light transmission 90% Communication USB serial transfer system Size Category 17" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 17"... -
Page 28: Specifications : Prolite T1932Msc
SPECIFICATIONS : ProLite T1932MSC Model Name ProLite T1932MSC-B1 ProLite T1932MSC-B1X Projected capacitive 10pt touch Touch Projected capacitive 2pt touch Technology Screen Light transmission 90% Communication USB serial transfer system Size Category 19" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 19"... - Page 29 Model Name ProLite T1932MSC-B2X Projected capacitive 10pt touch Touch Technology Screen Light transmission 90% Communication USB serial transfer system Size Category 19" Driving system a-Si TFT Active Matrix Panel Size Diagonal: 19" (48cm) Pixel pitch 0.294mm H × 0.294mm V Brightness 225cd/m (Typical: with Touch panel)
-
Page 30: Dimensions : Prolite T1532Msc
DIMENSIONS : ProLite T1532MSC 351.0mm/13.8” 54.5mm/2.1” 305.0mm/12.0” 222.5mm/8.7” DIMENSIONS : ProLite T1732MSC 387.0mm/15.2” 54.5mm/2.1” 339.0mm/13.3” 222.5mm/8.7” DIMENSIONS : ProLite T1932MSC 432.0mm/17.0” 54.5mm/2.1” 377.5mm/14.9” 249.5mm/9.8” 26 APPENDIX... -
Page 31: Compliant Timing
800 × 600 75.000Hz 49.500MHz 46.875kHz VESA 72.188Hz 50.000MHz 48.077kHz 60.004Hz 65.000MHz 48.363kHz 1024 × 768 70.069Hz 75.000MHz 56.476kHz 78.750MHz 75.029Hz 60.023kHz 60.020Hz 108.000MHz 63.981kHz SXGA 1280 × 1024 75.025Hz 135.000MHz 79.976kHz NOTE * Not compliant to ProLite T1532MSC. APPENDIX 27 M103G21...
