Range Hood UCDI430 User Manual & Installation Instructions IMPORTANT SAFETY INSTRUCTIONS Carefully read the important information regarding installation, safety and maintenance. Keep these instructions for future reference. MAAN1252-01 2019-07-19...
Before You Begin INSTALLERS - Start Here Safety Instructions are on pages 4 and 5 and Installation Instructions are on pages 8 to 15. Please perform these steps: 1. Read the safety instructions. 2. Read all instructions in the Installation section of this manual BEFORE installing the range hood.
Table of Contents Before You Begin ..........................2 Table of Contents ..........................3 Important Safety Information ......................4 Included Parts ........................... 6 Range Hood Dimensions ........................7 Specifications ............................ 7 Installation ............................8 Step 1 - Read the Safety Instructions .................... 8 Step 2 - Unpack Range Hood and Prepare Tools ................
Important Safety Information READ ALL INSTRUCTIONS BEFORE USE Read and follow all instructions before using the range hood to prevent the risk of fire, electric shock, personal injury, or damage when using the range hood or appliances with the range hood. This guide does not cover all possible conditions that may occur.
Page 5
Important Safety Information WARNING: TO REDUCE RISK OF A RANGE To reduce the risk of injury to persons in the TOP GREASE FIRE: event of a gas leaks: a) Never leave surface units unattended at high • Extinguish any open flame. settings. Boilovers cause smoking and greasy • DO NOT turn on the lights or any type of appliance.
Included Parts Range Hood Rectangular Vent/Damper Round vent/damper 3.25 x 10 in. (8.3 x 25.4 cm) 6 in. (15.3 cm) 2 Filters 4 + 1 pieces mounting screws for vent/damper Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material.
Range Hood Dimensions 9 ¼ in. (235 mm) 9 ¾ in. (247 mm) 20 5/8 in. (525 mm) 9 ¼ in. (235 mm) 9 ¾ in. (247 mm) 20 5/8 in. (525 mm) Specifications Body Design Stainless Steel Power Rating 120 V / 60 Hz (cULus Certified) Total Input Power 215 W (210 W + 2 x 2.5 W)
Installation STEP 1 Read the Safety Instructions • It is very important to read the safety instructions on pages 4 and 5. IMPORTANT: It is the installer’s responsibility to comply with installation clearances. STEP 2 Unpack Range Hood and Prepare Tools • Carefully unpack the range hood and parts.
Installation STEP 5 Venting Installation Guidelines • The following steps are for exterior ventilation. IMPORTANT: For the most efficient and quiet operation: • Vent system must terminate to the outside (roof or side wall). • It is recommended that the range hood be vented • DO NOT terminate the vent system in an attic or other vertically through the roof through 6 in.
Page 10
Installation IMPORTANT: for gas stove tops and no higher than 30-inch (76.2 cm) • A minimum of 6 in. (15.3 cm) round or 3-1/4 x 10 in. (8.3 for electric cook tops. cm x 25.4 cm) rectangular duct must be used to maintain • It is important to install the hood at the proper mounting maximum airflow efficiency.
Installation STEP 6 Preparations NOTE: To avoid damage to your hood, prevent debris from entering the vent opening. • Determine and mark the centre line on the ceiling or wall where the range hood will be installed. • Make sure there is proper clearance within the ceiling or wall for exhaust vent. • Due to the weight and size of this unit, please make sure that the support system or framework being used is stable and secure in the ceiling or wall.
Installation Remove rear vent back plate • Position the unit face down on a flat non-abrasive surface with rear of product facing you. • Remove the back plate by removing the 4 screws (See Figure #5) SAFETY WARNING: Risk of electrical shock. This range hood must be properly grounded. Make sure this is done by a qualified electrician in accordance with all applicable national and local electrical codes.
Installation STEP 9 Install top vent plate and rear damper (For rear venting only) • Re-install the plate removed in step 7 to block top venting hole. • Put plate in position and put in 4 screws from step 7 (See Figure #10). • Install rectangular air damper outlet on the rear vent location (See Figure #11).
Installation Method 2: attach the ducting to the rear rectangular damper and exhaust outdoors. Fig #13 Fig #13 STEP 11 Fig #13 Attaching the unit under the kitchen cabinets • Mark or drill a small hole on the mounting position according to the space and dimensions cited on the following drawings.
Installation STEP 12 Connect to AC 3-Pronged Plug • Connect AC plug into a grounded AC outlet having 120V, 60Hz. Place the outlet at a maximum distance of 33-1/2 in. (851 mm) from where the cord exits on the hood. Ground Plug 3-Prong Receptacle IMPORTANT:...
Maintenance Replacing the Light Pucks IMPORTANT: ALWAYS SWITCH OFF THE ELECTRICITY SUPPLY AT THE MAIN PANEL BEFORE CARRYING OUT ANY OPERATION ON THE APPLIANCE. Make sure the range hood is unplugged or turn OFF Replace with a 10.2 Volt, 2.5 Watt max, LED lights. breaker.
Maintenance Cleaning Filters IMPORTANT: Drain oil from baffles, spacers, filters, oil tunnels, oil containers before oil and residue overflow! • Remove all baffles, spacers, filters, grease tray, and oil containers and discard oil and residue. • Wash with warm soapy water. NOTE: Stainless steel baffles, spacers and oil tunnel are top rack dishwasher safe. • Dry thoroughly before replacing and follow directions for installation in reverse. • Filters should be cleaned after every 30 hours of use. • Should filters wear out due to age and prolonged use, replace with a new filter.
Range Hood Assembly Number Part Power cord Round duct or valve (Exhaust) Rear vent back plate Housing assembly Bracket of switch Switch plastic box Switch board Base of electronic box Capacitor Cover of electronic box Blower assembly (includes motor) Light panel LED puck lights Aluminum filter (2 pieces) Damper flap (rectangle)
Motor Assembly AC 120V 60Hz Motor Capacitor Circuit Diagram Motor AC 120V 60Hz Main PCB Capacitor AC 120V 60Hz _ _ _ Main PCB CH B LED Pucks Capacitor MAX 10.2V 250mA 2.5W _ _ _ LED Pucks CH B Temperature / Humidity Sensor Main PCB...
Use and Care Information Operations • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing.
