Description
Channels
Acceleration Range
Acceleration Resolution
Calibrated Accuracy
Sample Rate
Reading Rate
Memory
Required Interface Package
Baud Rate
Typical Battery Life
Operating Environment
-20 °C to +60 °C, 0 to 95%RH (non-condensing)
Material
Dimensions
3.5" x 4.4" x 1.0" (89 mm x 112 mm x 26 mm)
Weight
Approvals
*Shock101 Acceleration Range, Resolution and Accuracy
Range (g)
+5
Accuracy (g)
+0.2
Resolution (g)
0.01
Battery Warning
WARNING: FIRE, EXPLOSION, AND SEVERE BURN HAZARD. DO NOT SHORT CIRCUIT, CHARGE,
FORCE OVER DISCHARGE, DISASSEMBLE, CRUSH, PENETRATE OR INCINERATE. BATTERY MAY
LEAK OR EXPLODE IF HEATED ABOVE 60°C (140°F).
1.800.561.8187
Shock101
Shock (3 axes)
*See Table Below
512 Hz
64Hz to 5 minutes
349,525/axis
IFC200
115,200
7 days
Anodized aluminum
12 oz (340 g)
CE
+50
+100
+250
+1
+2
+4
0.05
0.1
0.2
www.
Product Information Card
Shock101-5
Tri-axial +5g, Shock Data Logger
Shock101-50
Tri-axial +50g, Shock Data Logger
Shock101-100
Tri-axial +100g, Shock Data Logger
Shock101-250
Tri-axial +250g, Shock Data Logger
information@itm.com
.com
Shock101
