5. Position single blower with single blower plate
as shown. Be sure to tuck back of single blower
plate into tabs at back of hood. Secure single
removed from step 2.
7. From inside hood body, position top cover plate
to top of hood body. From outside hood body,
attach top cover plate to top of hood body using
6. Attach 8" round duct collar or 3 1/4"x10"
rectangular duct collar to back of hood body
8. Connect blower plug.
