Notifier AFP-200 Manual

AFP-200 Door, Backbox, and
Dress Panel Assembly
Assembly
Carefully unpack the door, backbox, and dress panel and check for shipping damage. The AFP-200 door, backbox, and dress
panel should be assembled as shown in the drawing below. Refer to the following page for backbox dimensions.
The cabinet should be mounted in a clean, dry, vibration-free area where extreme temperatures are not encountered. The area
should be readily accessible with sufficient room to easily install and maintain the panel. Locate the top of the cabinet
approximately five feet above the floor with the hinge mounting on the left. For more information on installation of the AFP-
200, refer to the AFP-200 Analog Fire Panel Instruction Manual, Notifier Document 15511.
