Notifier AFP-3030 Installation Manual

Fire alarm control panel
Hide thumbs Also See for AFP-3030:
Table of Contents

Advertisement

Quick Links

See also: Programming Manual , Operating Manual
Fire Alarm Control Panel
AFP-3030

Installation Manual

New Zealand Edition
Document DOC-01-037
B
25/08/2016
Rev:
P/N DOC-01-037:B

Advertisement

Table of Contents
loading

Related Manuals for Notifier AFP-3030

Summary of Contents for Notifier AFP-3030

  • Page 1: Installation Manual

    Fire Alarm Control Panel AFP-3030 Installation Manual New Zealand Edition Document DOC-01-037 25/08/2016 Rev: P/N DOC-01-037:B...
  • Page 2 •Topic Title (for online Help) mentation •Page number (for printed manual) Send email messages to: TechPubs@notifier.com.au Please note this email address is for documentation feedback only. If you have any technical issues, please contact Technical Services. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 3: Installation Precautions

    This is a Class A product. In a domestic environment, this product may cause radio interference in which case the user may be required to take adequate measures. Electromagnetic Interference (EMI) tests are performed in accordance with Class A requirements of AS/NZS CISPR 22:2009 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 4: Table Of Contents

    4.1: Operational Checks ............................. 30 4.2: Battery Checks and Maintenance........................ 31 4.2.1: PSI Status ............................32 Appendix A: Electrical Specifications .................. 33 A.1: Operating Power............................33 A.2: SLC Loops ..............................33 A.3: Notification Appliance Circuits ......................... 33 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 5 B.5: CAB 40U Cabinet Mounting Dimensions....................43 B.6: Laying Out Equipment in Cabinet and Chassis..................44 B.7: Installing Replacement Equipment ......................45 B.7.1: Installing a replacement keypad....................... 45 Appendix C: Schematics ....................... 46 Index ............................49 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 6: Section 1: About This Manual

    Document Number Available for download: VeriFire Tools Programming Utilities www.notifier.com.au Fire Alarm Control Panel (FACP) and Main Power Supply Installation Document Number AFP-3030 Installation, Programming, and Operations Manuals (NZ) DOC-01-037 DOC-01-038 DOC-01-038 NPS (Notifier Power Supply) Installation Sheet DOC-03-057 Battery Connection Installation Kit...

  • Page 7: Cautions And Warnings

    INFORMATION ABOUT PROCEDURES THAT COULD CAUSE PROGRAMMING ERRORS, RUNTIME ERRORS, OR EQUIPMENT DAMAGE. WARNING: SUMMARY IN BOLD INDICATES INFORMATION ABOUT PROCEDURES THAT COULD CAUSE IRREVERSIBLE DAMAGE TO THE CONTROL PANEL, IRREVERSIBLE LOSS OF PROGRAMMING DATA OR PERSONAL INJURY. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 8: Section 2: System Overview

    Connections to easily mount from one to ten Signalling Line Circuit (SLC) loops • Network operation • Uses Notifier’s VIEW® early warning fire detection and the FlashScan® or CLIP families of detectors and modules • Alarm, Fault, and Supervisory relays •...

  • Page 9: Specifications

    Noti•Fire•Net (network version 5.0 or higher) or High-Speed Noti•Fire•Net. Annunciators. The AFP-3030 supports ACM-24AT/ACM-48A (and their expanders) with either 64 or 96 points at an address, as well as LDM-32 (and expanders) and Notifier’s other ACS devices. (See Section 2.6 “Compatible Equipment” if looking for specific ACS devices.) NOTE: Annunciators for the AFP-2800 operate on a different baud rate and are not compatible with the AFP-3030.

  • Page 10: 1: Replacement Kits

    Mass Notification Manual. Refer to the AFP-3030 programming and operation manuals for additional information. NOTE: The AFP-3030 does not support Control Active LED. 2.3.1 Replacement Kits The system components that are available as replacement kits for the AFP-3030 are listed in Table 2.1. Model Number Description ASY-02-034 NPS-5CHS 5.6 A Power Supply Replacement Kit...

  • Page 11: Product Diagram

    †Door Holder Power must NOT be run directly to door holders in the field. This power must be fused and must pass through a door holder relay to control when the doors are to be dropped. Figure 2.1 CPU Connections AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 12 System Overview Product Diagram The keyboard/display assembly is shown in Figure 2.3. Figure 2.2 AFP-3030 installed in a CAB650 System Fault LED Fire LED Fault Scroll Button and LED System Normal LED Mute Alarm Devices Button Supervisory Scroll Button and...

  • Page 13: 1: Main Power Supply

    2.6 Compatible Equipment Compatible Notifier and System Sensor equipment that connects directly to the CPU is listed below. These are the most common devices at time of publishing; the most complete list of compatible intelligent SLC loop devices is provided in the SLC Wiring Manual; for conventional non-addressable equipment see the Device Compatibility Document.
  • Page 14 Detectors (Clip) FDX-851AUS Intelligent Thermal Sensor FDX-851RAUS Intelligent Thermal Sensor IDX-751AE Intrinsically Safe Addressable Photoelectric Detector SDX-851AUS Intelligent Photo Sensor NOTE: This system is not intended for use by detectors incorporating eutectic alloys. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 15: Section 3: Installation

    Section 3.12 “Wiring a Signalling Line Circuit (SLC)” and the (Notification Appliance Circuits and SLC Wiring Manual Initiating Device Circuits) Calculate the proper battery rating. Main Power Supply Manual Table 3.1 Installation Checklist (1 of 2) AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 16: 1: Memory-Backup Battery

    IF MISTREATED. DO NOT RECHARGE, DISASSEMBLE, HEAT ABOVE 100°C, OR INCINERATE. A REPLACEMENT CR2477 LITHIUM BATTERY CAN BE ORDERED FROM NOTIFIER BY QUOTING THE PART NUMBER FG-65-016. USE OF ANY OTHER BATTERY MAY PRESENT A RISK OF FIRE OR EXPLOSION.

  • Page 17: Attaching Option Boards

    If mounting the option board in the door behind a blank dress plate, see Figure 3.2. This dress plate is suitable for option boards, which do not need to be visible or accessible when the door is closed. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 18 Mount option board plate onto the door. onto stand-offs (included) to the blank plate Fasten option board to the plate with four screws (included). Figure 3.2 Door-Mounting Option Boards with a Single-space Blank Plate AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 19: Connecting The Network Communications Module

    If using loop control and expander modules in CHS-4L see Figure 3.6. NOTE: Mounting two pairs of loop control and expander modules in one chassis position may cause intermittent electrical interference. If this occurs, move one pair to a separate chassis position. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 20: 2: Setting Slc Loop Number

    Bring the module back down so that the lower board edges slip into the bottom slots. Secure the module to the chassis with the two module screws. Tighten securely. Connect the ribbon cable to the module. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 21 PLUG CAN FAIL TO MAKE A SECURE CONNECTION WHEN PLUGGED THROUGH THE LOOP CONTROL MODULE. Loop Expander Module mounted behind Loop Control Module Figure 3.5 Connecting Loop Control Modules with Loop Expander Modules AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 22 J1 on LCM-320 J3 on LCM-320 3030LCMchainrv2.wmf “Data in” “Data out” Figure 3.7 Connecting Multiple Pairs of Loop Control and Expander Modules Figure 3.7 Connecting Multiple Pairs of Loop Control and Expander Modules AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 23: Form-C Relays On The Cpu

    Affix two 3/4” 4-40 stand-offs to an empty slot on the CHS chassis. Insert the tab at the bottom of the SGD assembly into the corresponding slot along the bottom of the CHS chassis, and slide the assembly into place. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 24: Installing A Replacement Zone Mimic (Acm-Zm)

    Set the address of the replacement card using the address wheels on the ACM-ZM. Figure 3.11 Setting the ACM-ZM address wheels Connect the replacement ACM-ZM to the fire panel as per the relevant drawing in Appendix C, “Schematics”, on page 46. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 25: 1: Installing A Zone Mimic Expansion Card (Aem-Zm)

    Screw the AEM-ZM to the vacant threaded spacers beneath the ACM-ZM card on the NPS Mounting Bracket, as shown in Figure 3.14. Connect the replacement ACM-ZM to the fire panel as per the relevant drawing in Appendix C, “Schematics”, on page 46. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 26: Installing Replacement Bulgin Switches

    Unscrew the nut on the outside of the outer door, and the hex nut on the inside of the outer door, to remove the Bulgin switches. Figure 3.15 Bulgin switches and nuts, as viewed from inside the outer door Remove the wires running from the Bulgin switches to the ACM-ZM. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 27: Connecting Power Sources And Outputs

    Some installers may find it convenient to remove the insulator before mounting all equipment. NOTE: If using multiple power supplies with one set of batteries, refer to main power supply documentation for connection requirements. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 28: 2: Connecting Local And Remotely Powered Devices

    Figure 3.16 Connecting a Locally Powered CPU to power Main CPU (Locally Powered) Red (+) Remote CPU Black (-) Red (+) Black (-) Figure 3.17 Connecting a Remotely Powered CPU to the Main CPU AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 29: 3: Checking Ac Power

    NOTE: The Remote/Secondary CPU must be programmed with the Main PS Node number of the CPU from which it is drawing power. This node number must be separate from its own node number. Refer to the ‘SUPERVISION’ section of the AFP-3030 Programming Manual for more information.

  • Page 30: 4: Auxiliary Power Supply Connections

    Refer to printer manual for detailed connection information. Tighten clamp on connector to secure cable. Connect the four open leads of the custom cable to the TB5 terminal block on the CPU as shown in Figure 3.20. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 31 Uninterruptible Power Supply (UPS). Plug the DB-25 connector end of the custom cable into the EIA-232 port of your printer. Tighten securely. Configure the printer as described in Section 3.11.2 “Configuring the Printer”. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 32: 2: Configuring The Printer

    For electrical specifications, see Appendix A.2 “SLC Loops”. For additional notes on SLC resistance values, see Section 4.1 “Operational Checks”. 3.12.2 SLC Capacity The AFP-3030 supports up to five pairs of LCM-320 and LEM-320 modules, providing from one to ten SLC loops. Loop capacity depends on operating mode: •...

  • Page 33: 3: Slc Installation

    Loop B+ A+ B- A- B+ A+ B- A- Expander and Closed Wiring (Style 6/7) Open Wiring (Style 4) Control Modules SLC Loops SLC Loops Figure 3.21 SLC Loop Connections and Wiring AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 34: Connecting A Faast Intelligent Aspiration Detector

    J15 USB Connection, J1 Network/Service Connection (NUP) or to the second Network/Service connection on an attached wire or fibre version of the NCM or HS-NCM. Refer to the VeriFire® Tools CD for instructions. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 35: Section 4: Testing The System

    24 hours before testing.  Return all circuits to their pretest condition.  Check that all status LEDs are off and the green POWER LED is on. continued… AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 36: Battery Checks And Maintenance

    SHORTING THE BATTERY LEADS CAN DAMAGE THE BATTERY, EQUIPMENT, AND COULD CAUSE INJURY TO PERSONNEL. CAUTION: RISK OF EXPLOSION IF BATTERY IS REPLACED WITH INCORRECT TYPE. DISPOSE OF BATTERY ACCORDING TO MANUFACTURER’S INSTRUCTIONS. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 37: 1: Psi Status

    P A N E L R U N N I N G F R O M P S I S U P P L Y S T A R T B A T T E R Y T E S T B A C K Figure 4.2 PSI Status Screen AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 38: Appendix A: Electrical Specifications

    NOTE: If running an SLC in conduit with Notification Appliance Circuits, you can reduce problems by exclusively using electronic sounders (such as the MA/SS-24 Series) instead of more electronically noisy notification appliances (such as electromechanical bells or horns). AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 39: A.6: Power Supply Calculations

    The NPS does not need to provide enough current to run the panel when in the alarm condition, if the panel needs more current than the NPS can supply during alarm, the extra current AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 40: A.6.2: How To Use The Calculating Tables

    If the system provides power for Notification Appliance Circuits, refer to the Device Compatibility Document for 24 V DC notification appliances. NOTE: A current calculation tool can also be found in the Download Centre on the Notifier website: http://www.notifier.com.au/ AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 41: A.6.3: Calculation For Main Supply Current

    Total device current cannot exceed 200 mA. † Refer to manual and/or Device Compatibility Document. ‡ Value represents battery size in amp hours. Refer to Appendix A.7, “Calculating the Battery Requirements”, on page 38 to determine battery size. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 42: A.6.4: Calculating The Maximum Secondary Power Quiescent Current Draw

    Alarm Total Device Quantity Current Current/Type (in amps) Alarm Current, from Table A.2, col 2 Additional Load Sum Column for Secondary Fire Alarm Load Table A.4 Maximum Secondary Power Fire Alarm Current Draw AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 43: A.7: Calculating The Battery Requirements

    Olympic, 33 AH 12 V Battery - 1.51 BATT/33 (CJ12-33) Olympic 40 AH 12 V Battery - 1.83 BATT/40 (CJ12-40) Olympic 85 AH 12 V Battery - 3.89 BATT/85 (CJ12-85) Table A.5 Recommended Battery Specifications AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 44: Appendix B: Cabinet And Mounting Information

    Appendix B: Cabinet and Mounting Information B.1 CAB650 Mounting Details NOTE: All dimensions in Millimeters Figure B.1 CAB650 Mounting Details and Dimensions AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 45: B.2: Cab900 Mounting Details

    CAB900 Mounting Details Cabinet and Mounting Information B.2 CAB900 Mounting Details NOTE: All dimensions in Millimeters Figure B.2 CAB900 Mounting Details and Dimensions AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 46: B.3: Cab 18U Cabinet Mounting Dimensions

    Cabinet and Mounting Information CAB 18U Cabinet Mounting Dimensions B.3 CAB 18U Cabinet Mounting Dimensions NOTE: All dimensions in Millimeters Figure B.3 CAB 18U Mounting Details and Dimensions AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 47: B.4: Cab 28U Cabinet Mounting Dimensions

    380.0 343.0 70.0 376.0 25.0 Laser cut Knockout 1210.0 175.1 1260.0 1330.0 10.0 Mounting Holes 50.0 Laser cut Knockout NOTE: All dimensions in Millimeters Figure B.4 CAB 28U Cabinet Mounting Details and Dimensions AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 48: B.5: Cab 40U Cabinet Mounting Dimensions

    610.0 550.0 380.0 343.0 70.0 376.0 50.0 10.0 Laser cut Knockout 25.0 Laser cut Knockout 1745.0 707.5 1795.0 1865.0 NOTE: All dimensions in Millimeters Figure B.5 CAB 40U Cabinet Mounting Details and Dimensions AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 49: B.6: Laying Out Equipment In Cabinet And Chassis

    Cabinet and Mounting Information B.6 Laying Out Equipment in Cabinet and Chassis The AFP-3030 allows for flexible system design. It mounts in a CAB650 or CAB900 backbox using the CHS-3L or in a U-Series backbox using the CHS-4L. Follow these guidelines when deciding where to locate equipment in the backbox.

  • Page 50: B.7: Installing Replacement Equipment

    Flanged nuts Ribbon cable connecting the keypad to the fire panel CPU. Figure B.8 Removing the fire panel keypad Replace keypad on door studs. Replace the Flanged nuts, fastening the keypad to the door. AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 51: Appendix C: Schematics

    Appendix C: Schematics The table below lists the relevant schematics found in this appendix. Title Drawing Number ACM-ZM Schematic DWG0919 SGD Schematic DWG0937 Table C.1 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...

  • Page 54: Index

    Supervisory Relays, also see Relays 18 Supplemental Documentation 1 System Features 3 Main Power Supply 8 Limitations 3 Maintenance 31 Options 3 Manual Pull Station 27 System Description 3 Memory-Backup Battery – System Current Draws 33 Insulator 11 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 55 Index T–W Testing 30 Trouble Relays, also see Relays 18 Upload/Download Software 29 VeriFire® Tools 29 Wiring, also see SLC 27 Wire Requirements 33 AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 56 Notes AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 57 Notes AFP-3030 Installation Manual — P/N DOC-01-037:B 25/08/2016...
  • Page 58 New South Wales New Zealand (Head Office) 264 Mt Eden Rd 9 Columbia Way Mt Eden Baulkham Hills NSW 1064 2153 ph +61 (0)2 9899-4155 ph +64 (0)9 623-5050 fax +61 (0)2 9899-4156 fax +64 (0)9 623 5060...
