I N S T A L L A T I O N M A N U A L
FIG. B – DURO-SPRING JUMP BOARD
TABLE 4 – BOARD DIMENSIONS AND FULCRUM SETTINGS
Model #
Nominal Length
DS6
6'
DS8
8'
FIG. C – DURO-SPRING JIG
Red Jig Cap (1)
6"
TABLE 5 – JIG DIMENSIONS
Jig Type
6'
8'
NOTE: Both the 6' and 8' stands utilize the same jig.
DS-IM Rev. 12/09 (BK-DS INSTALL)
A
B
70.25"
17.25"
94.00"
17.25"
Yellow Jig Caps (2)
5/8" dia.
A
6"
3.25"
6"
3.25"
C
D
4.50"
8.00"
4.50"
8.00"
6"
A
B
BOLT
5/8" X 6"
5/8" X 6"
7
D U R O - S P R I N G ™
F
DIA.
30.00"
19/32"
36.00"
19/32"
B
3.25"
