Summary of Contents for Inter-fab Zoomerang
- Page 1 INSTALLATION MANUAL 3050 S. Alvernon Way Tucson, AZ 85713 (800) 737-5386 / (520) 790-7040 (520) 790-7127 Fax www.inter-fab.com...
-
Page 2: Table Of Contents
TABLE OF CONTENTS Product Safety……………………………………………………………3 Slide Placement & Positioning…………………………………………..3 Slide Components………………………………………………………..4 Step 1: Flume Assembly………………………………………….……...5 Step 2: Ladder & Handrail Assembly to Flume………………….……6 Step 3: Slide Anchoring; Wooden Deck/Concrete Deck….…………...7 Step 4: Water Supply Hook-up………………...………….…………….8 Care & Maintenance……………….…………………………………….9 Limited Warranty & Registration…………………………………..10... -
Page 3: Product Safety
(particularly those associated with water) there are some common sense rules that apply to enjoy the Zoomerang™ in a safe manner. As the owner of this product, it is your responsibility to read and strictly enforce the guidelines listed below. -
Page 4: Slide Components
SLIDE COMPONENTS • Flume • Ladder Treads (3) • Flume support base • Ladder rails (2) • Plumbing Kit (Hose, slide adapter fitting, pool adapter fitting) • Grab Rails (2) • Hardware packs (2) When unpacking box, please note treads are located in stapled side pocket. -
Page 5: Step 1: Flume Assembly
ASSEMBLY Tools Hammer, drill, hammer drill (for masonry deck), socket wrench with 7/16” and 9/16” sockets, 7/16” open-end wrench, ½” open-end wrench, pencil or marker. Flume Support to Flume Flatten product box to use as a protective work platform. This prevents possible scratching of the acrylic slide parts during assembly. -
Page 6: Step 2: Ladder & Handrail Assembly To Flume
Ladder Rails & Grab Rails to Flume 1. Slide acrylic escutcheon (looks like a doughnut – it’s used to cover the ladder flange and hardware at the base of the ladder) over the open rail end. Installed correctly it will cover the flanged end of the rail. -
Page 7: Step 3: Slide Anchoring; Wooden Deck/Concrete Deck
Note: Be sure holes are not located over seams in the decking or directly ove r deck support joists. If either of these conditions are present re-position the Zoomerang™ as necessary to remedy and mark the new holes. Use a 5/16” wood drill bit to drill the holes in the de 4. -
Page 8: Step 4: Water Supply Hook-Up
Tighten by hand only. You will want to be able to remove the Zoomerang™ fitting/hose from your wall return fitting when the Zoomerang™ is not in use. -
Page 9: Care & Maintenance
CARE & MAINTENANCE General Cleaning • Use nonabrasive soap and water when possible. • Review cleaner’s label instructions before applying to acrylic surface. • Avoid harsh chemicals and disinfectants. You may safely use: * • Chlorox • Spic & Span Powder •... -
Page 10: Limited Warranty & Registration
Limited Warranty Inter-Fab Inc. warrants the Zoomerang™ to be free of defects in manufacturing, materials or workmanship for a period of (1) year from date of end user purchase. Products which fail or become defective during the warranty period, except as a result of improper installation, improper use or care, negligence or natural accidents (acts of God) will be repaired or replaced at Inter-Fab’s option at no charge.
