EDGESTONE SLIDE ROCK
Rock Panel Installation Guide
1.
Install White Water slide per installation instruc-
tions prior to attachment of the Edgestone Slide Rock
panels. Legs should be plumb and step should be set at
16 degrees slope.
IMPORT NT: Correct step slope is
critical to ensure proper fit of the Slide Rock Panels.
2B.
Use the relief line along step section to help with panel
positioning.
7900 ES Slide Rock Rev. 09/10
8 0 0 . 7 3 7 . 5 3 8 6
2 .
Front panel installation (toward pool). Position the
front panel along the slide. Make sure the panel does not
extend over the pool edge. Starting at the step, make sure
the panel fits correctly down the length of the flume.
2C.
The rear of the panel has a cut out of the step to
deck mounting bolt head.
3050 S.
LVERNON W Y
TUCSON,
Z 85713
