Ocean Matrix OMX-01HMBT0010 Installation & Specifications page 3

Ocean Matrix OMX—01HMBT0010
RS232 STANDARD SERIAL CONTROLLER TERMINAL
Download the control software. Find the download on the Ocean Matrix website on the
1. Copy the control software file to the control PC
2. Set the following parameters:
 COM Number
 Baud Rate: 2400, 4800, 9600, 19200, 38400, 57600 or 115200
 Data Bit: 8
 Stop Bit: 1
 Parity Bit: None
RS232 COMMAND
TRANSMITTER CONTROL
Set the following Commands:
 Baud Rate: 9600
 Data Bit: 8
 Stop Bit: 1
 Parity Bit: None
Signal Switching
Command Function
50701% Switch to HDMI IN 1 input.
50702% Switch to HDMI IN 2 input.
50710% Enable auto-switching mode.
50711% Disable auto-switching mode.
50712% Get the signal switching mode.
CEC Command—Display must Support CEC
Note: Not all displays/monitors with CEC adhere fully to all command functions.
Command Function
50730% Volume Up on Display
50731% Volume Down on Display
50732% Mute
50733% Display ON
50734% Display OFF
HDCP Command
Command Function
50709% HDCP Mode
50713% HDCP Status
Factory Default
Command Function
50617% Restore Factory Default
50699% Firmware Version
Feedback Example
SWITCH TO HDMI1
SWITCH TO HDMI2
AUTO SWITCHING
MANUAL SWITCHING
AUTO SWITCHING or MANUAL SWITCHING
Feedback Example
CEC VOLUME INCREASE
CEC VOLUME DECREASE
CEC VOLUME MUTE
CEC DISPLAY ON
CEC DISPLAY OFF
Feedback Example
HDCP: ON
HDCP: OFF
HDCP 2.2
NO HCDP
Feedback Example
FACTORY RESET
VERSION Vx.x.x
Ocean Matrix
www.oceanmatrix.com
product page.
OMX-01HMBT0010
4
