Summary of Contents for Gefen HDTV-241N
- Page 1 2x1 HDTV Switcher U S E R M A N U A L www.gefen.com...
- Page 2 Chatsworth, CA 91311 www.gefen.com support@gefen.com Gefen Inc. reserves the right to make changes in the hard ware, packaging and any accompanying doc u men ta tion without prior written notice. HDTV Switcher is a trademark of Gefen Inc. © 2007 Gefen Inc., All Rights Reserved...
-
Page 3: Table Of Contents
Introduction Features Panel Descriptions Connecting and Operating the HDTV Switcher RMT2-IR Installation IR Code Confl icts IR-Extender Installation Specifi cations Warranty TABLE OF CONTENTS... -
Page 4: Introduction
Our Commitment Gefen will always offer the fi nest quality product at the best possible price. Included in that price is a lifetime of support from a team of outstanding engineers. The ex•tend•it HDTV Switcher allows two HDTV DVI devices to be switched easily in to one HDTV DVI compatible monitor or projector. -
Page 5: Features
FEATURES Features • Switches easily between any two HDTV sources • Maintains 480i, 480p, 720p, 720i, 1080i, and 1080p (1920x1200) resolutions • Extends any DVI compliant device by regenerating the DVI signal • Maintains highest DVI single link video resolution •... -
Page 6: Panel Descriptions
PANEL DESCRIPTIONS... -
Page 7: Connecting And Operating The Hdtv Switcher
EQ associated with the particular input with the pixels. How to Operate the HDTV Switcher 1 Use the front panel push button to switch between sources. 2 Alternatively, use the RMT2-IR remote control port to remotely toggle between sources. -
Page 8: Rmt2-Ir Installation
1. Remove battery cover from the back of the RMT2-IR remote. 2. Verify that dip switches 1 & 2 are in the down (OFF) position. 3. Insert the battery, hold the battery so that you can see the positive side facing up. The side that is not marked must be facing down. -
Page 9: Ir Code Confl Icts
There are matching pairs of dip switches underneath the Switcher unit and under the remote battery cover. Switch 1 & 2 on the Remote and Switch 3 & 4 underneath the unit are the matching switches. These switches need to be matched for the remote to communicate with the switcher. -
Page 10: Ir-Extender Installation
IR EXTENDER INSTALLATION How to Connect the IR Extender 1 Plug the IR extender into the Remote port on the front of the Switcher Unit 2 Flip the Dip Switch 1 underneath the unit to the ON position... -
Page 11: Specifi Cations
SPECIFICATIONS Video Amplifi er Bandwidth ... 1.65 Gbps Input Video Signal ... 1.2 volts p-p Input DDC Signal ... 5 volts p-p (TTL) Single Link Range ... 1920 x 1200 DVI Input/Output Connector Type ... DVI-I (29 pin) female (digital only) Power Consumption ... -
Page 12: Warranty
If equipment fails because of such defects and Gefen Inc. is notifi ed within two (2) year from the date of shipment, Gefen Inc. will, at its option, repair or replace the equipment, provided that the equipment has not been subjected to mechanical, electrical, or other abuse or modifi...
