Summary of Contents for Ancona WPL436
- Page 1 MODEL: WPL430 & WPL436 IMPORTANT SAFETY INSTRUCTIONS Carefully read the following important information regarding installation safety and maintenance. Keep these instructions for future reference. 2017-03-13 MAAN1174-01...
-
Page 2: Important Safety Notice
IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE The installation in this manual is intended for qualified installers, service technicians or persons ● with similar qualified background. Installation and electrical wiring must be done by qualified professionals and in accordance with all applicable codes and standards, including fire-rated construction. - Page 3 IMPORTANT SAFETY NOTICE READ AND SAVE THESE INSTRUCTIONS READ ALL INSTRUCTIONS BEFORE INSTALLING AND OPERATING THIS APPLIANCE WARNING: TO REDUCE RISK OF A RANGE TOP GREASE FIRE: a) Never leave surface units unattended at high settings. Boilovers cause smoking and greasy spillovers that may ignite.
-
Page 4: Parts Supplied
PARTS SUPPLIED: Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. Please consult your installation specialist regarding the optimal type of mounting screws and wall anchors to suit your home’s construction. -
Page 5: Height & Clearance
VENTING REQUIREMENTS: HEIGHT & CLEARANCE: • Vent system must terminate to the outside Chimney mounting bracket (Roof or side wall). • DO NOT terminate the vent system in an attic Can reach or other enclosed area. 9’ ceiling Upper chimney if installed •... -
Page 6: Calculating Vent System Length
IMPORTANT: • A minimum of 6” round or 3-1/4 x 10” rectangular duct (purchased separately) must be used to maintain maximum airflow efficiency. • Always use rigid type metal/aluminum ducts if available to maximize airflow when connecting to provided duct. •... -
Page 7: Venting Methods
VENTING METHODS: • This range hood is factory set for venting through the roof or wall. • Vent work can terminate either through the roof or wall. To vent through a wall, a 90° elbow is needed. IMPORTANT: NEVER exhaust air or terminate duct work into spaces between walls, crawl spaces, ceiling, •... -
Page 8: Electrical Requirements
ELECTRICAL REQUIREMENTS: IMPORTANT: Observe all governing codes and ordinances. It is the customer’s responsibility to contact a qualified electrical installer. If codes permit and a separate ground wire is used, it is recommended that a qualified electrician determine that the ground path is adequate. A 120-Volt, 60 Hz, AC-only, fused electrical supply is required on a separate 15-amp circuit, fused on both sides of the line. - Page 9 PREPARATIONS: Advanced Preparations: • Be familiar with the controls of the range hood by reading through Range Hood Operations, Page 13. • Place the range hood on a flat, stable surface. Connect the range hood to a designated standard outlet (120-Volt, 60Hz, AC only) and turn on the range hood.
-
Page 10: Installation
INSTALLATION: Installations (refer to Page 4 for parts): NOTE: Use threaded drywall anchors only when mounting the hood on sheet rock. Mounting the hood on wall studs or lumbars is highly recommended. Hardware Note: For safety reasons, range hood mounting screws and anchors will not be included due to the variation of cabinetry constructions and wall material. - Page 11 INSTALLATION CONTINUE: Step 4: Venting • Fix the damper on the top vent of hood with 4 screws (requires screw C). If ventilation system is equipped with an external air duct with a different diameter, apply a reduction fitting. However, for maximum performance and safety, a 6” round ducting is recommended. (See Figure # 2) Step 5: Mounting the hood on the wall •...
- Page 12 INSTALLATION CONTINUE: Step 6: Installing filters • To install filters for the following four steps (See Figure # 6): - Angle the filter into slots at the back of the hood. - Push the button on handle of the filter. - Release the handle once the filter fits into a resting position.
-
Page 13: Control Panel Operation
CONTROL PANEL OPERATION: Control Panel Layout and Buttons Configurations: Lights: Press the light button to turn LED lights on and off. Power Settings: once the motor starts to operate at low speed. Press the Press the again and the motor will reach medium speed. Press the again and the motor will reach high speed. -
Page 14: Mounting Brackets
MOUNTING BRACKETS: Upper Chimney Bracket 5 1/8” (13 cm) 1 3/8” (3.5 cm) 8 21/32 (22 cm) Lower Chimney Bracket 7 7/8” (20 cm) 5 1/8” (13 cm) 1 3/8” (3.5 cm) 8 5/8” (21.9 cm) Mounting Bracket Hook 7 7/8” (20 cm) 3 15/16”... - Page 15 MEASUREMENTS AND DIAGRAMS: Height of range hood: 26” - 41 3/8” (66 cm -105 cm) The range hood can reach a 9’ ceiling if installed at 31” from cooktop. 6.81’’ (173mm) 8.77’’ (223mm) 15.74” - 31.10’’ (400 - 790 mm) 8.85’’...
-
Page 16: Troubleshooting
TROUBLE SHOOTING: 1) If the range hood or LED light does not • Check if the range hood has been plugged in, operate after installation: make sure that all power has been turned back ON,fused not blown and all electrical wiring are properly connected. -
Page 17: Range Hood Assembly
RANGE HOOD ASSEMBLY: Description Air pipe Bracket of inner chimney Inner chimney Bracket of outer chimney Outer chimney Plastic wind block Hook plate Power cord Body assembly (including shell,lamp plate,top plate,wrap angle,bracket of lamp plate) Electronic switch box Electronic switch Bracket of electronic switch box Round LED lamp Front panel... -
Page 18: Specifications
SPECIFICATIONS: Body design Stainless steel 120V / 60Hz (USA & Canada standard) cETLus Certified Power Rating Total input power 235.1W Motor Input Power 230W Total Ampere 1.96A Levels of speed control 3 levels Radio frequency interference protected Interference Protection 400 CFM Air Flow Low speed 50 dBA Noise Level... -
Page 19: Blower Assembly
BLOWER ASSEMBLY: Description Description Blower Aluminum Cover Wind Wheel Nut Plastic Wind Net Wind Wheel Sealing Gasket Motor Incabloc Rubber ELECTRICAL ASSEMBLY: Description Description Electrical box bracket Electrical box base Capacitor Electrical box cover... - Page 20 USE AND CARE INFORMATION: Operations: • Read and understand all instructions and warnings in this manual before operating the appliance. Save these instructions for future reference. • Always leave safety grills and filters in place. Without these components, operating fans could catch on to hair, fingers and loose clothing.
