- Page 1 USER MANUAL...
- Page 2 Chauvet reserves the right to revise the content of this document without any obligation to notify any person or company of such revision, however, Chauvet has no obligation to make, and does not commit to make, any such revisions. Download the latest version from www.chauvetprofessional.com.
-
Page 3: Table Of Contents
Static Mode ........................10 Master/Slave ........................10 Dimmer Curve ........................ 10 Dimmer Profiles......................10 LED Frequency ......................10 Fan Mode ........................11 Back Light ........................11 System Information ......................11 Zoom Reset........................11 Factory Reset......................... 11 Ovation F-145WW User Manual Rev. 5... - Page 4 Table of Contents 5. Technical Information ..............Product Maintenance ..................6. Technical Specifications ............Returns.................... Contact Us ..................Ovation F-145WW User Manual Rev. 5...
-
Page 5: Before You Begin
If the box or the contents (the product and included accessories) appear damaged from shipping, or show signs of mishandling, notify the carrier immediately, not Chauvet. Failure to report damage to the carrier immediately may invalidate your claim. In addition, keep the box and contents for inspection. -
Page 6: Safety Notes
• In the event of a serious operation problem, stop using this product immediately! If your Chauvet product requires service, contact Chauvet Technical Support. Expected LED Lifespan LEDs gradually decline in brightness over time, primarily because of heat. LEDs that are arranged in clusters experience higher operating temperatures than single LEDs. -
Page 7: Introduction
2. Introduction Description The Ovation F-145WW is a warm white Fresnel-style LED lighting fixture with 16-bit dimming resolution for smooth fades. It delivers a beautiful, flat, even field of light. Its motorized zoom, with a range between 25° and 65°, can be controlled either manually or via DMX. Simple and complex DMX channel profiles offer programming versatility. -
Page 8: Product Dimensions
Product Dimensions 11.13 in 282.9 mm 15.03 in 11.69 in 382 mm 297 mm 6.87 in 175 mm 15.9 in 404.4 mm 6.32 in 161 mm 9.4 in 241.1 mm Page 4 of 15 Ovation F-145WW User Manual Rev. 5... -
Page 9: Setup
Chauvet for purchase. DMX Linking You can link the Ovation F-145WW to a DMX controller using a 3- or 5-pin DMX connection. If using other DMX-compatible products with this product, you can control each individually with a single DMX controller. -
Page 10: Mounting
Procedure The Ovation F-145WW comes with a bracket to which you can attach a mounting clamp directly. You must supply the mounting clamps. Make sure the clamps are capable of supporting the weight of this product. Use at least one mounting point per product. For the CHAUVET Professional line of mounting clamps, go to http://www.trusst.com/products. -
Page 11: Operation
Knob 1 Push then turn to increase or decrease the dimmer Knob 2 Push then turn to increase or decrease the zoom Control Options Set the Ovation F-145WW starting address in the 001–512 DMX range. This enables control of up to 102 products in the 6-channel 6Ch: 16bit-Full personality. Programming Refer to the Menu Map to understand the menu options. -
Page 12: Menu Map
_ _ _ _ _ _ _ _ Shows product UID Reset Zoom Resets zoom setting when product is w/ Power turned off Factory Resets the product to factory default Reset settings Page 8 of 15 Ovation F-145WW User Manual Rev. 5... -
Page 13: Dmx Values
2Ch: 16bit Dim Channel Function Value Percent/Setting Dimmer 000 255 0–100% Dimmer fine 000 255 0–100% 1Ch: 8bit Dim Channel Function Value Percent/Setting Dimmer 000 255 0–100% Ovation F-145WW User Manual Rev. 5 Page 9 of 15... -
Page 14: Configuration (Standalone)
Select the desired option (Linear, Square, I Square, or SCurve). Dimmer Profiles This setting determines how fast the output of the Ovation F-145WW changes when you modify the output value. This setting provides four different options to simulate the dimming curve of an incandescent lighting product. -
Page 15: Fan Mode
Keep a safe distance from flammable objects. Back Light This setting allows for selection of the amount of time the backlight on the Ovation F-145WW’s display stays on after the last button is pressed on the control panel. Go to the Back Light main level. -
Page 16: Technical Information
Gently polish the transparent surfaces until they are free of haze and lint. Always dry the transparent surfaces carefully after cleaning them. Do not spin the cooling fan using compressed air because you could damage it. Page 12 of 15 Ovation F-145WW User Manual Rev. 5... -
Page 17: Technical Specifications
113 °F (45 °C) Fan-assisted convection I/O Connector Channel Range 3- and 5-pin XLR 1, 2, 2, or 6 Ordering Product Name Item Name Item Code UPC Number Ovation F-145WW OVATIONF145WW 03031464 781462218126 Ovation F-145WW User Manual Rev. 5 Page 13 of 15... -
Page 18: Returns
Send the merchandise prepaid, in its original box, and with its original packing and accessories. Chauvet will not issue call tags. Clearly label the package with the RMA number. Chauvet will refuse any product returned without an RMA number. Write the RMA number on a properly affixed label. DO NOT write the RMA number directly on the box. -
Page 19: Contact Us
