INSTRUCTIONS AND ADVICE FOR THE
USE, INSTALLATION AND MAINTENANCE
OF BUILT-IN ELECTRIC HOBS
Dear Customer,
Thank you for having purchased one of our products.
We are certain that this new, modern, functional and practical appliance, built with the very
highest quality materials, will meet your requirements in the best possible way. This hob is easy
to use. It is, however, important to thoroughly read the instructions in this handbook in order to
obtain the best results.
The manufacturer shall not be held responsible for any damages to persons or property
caused by incorrect installation or use of the appliance.
TIPO: PAZ04
MOD.: SE435S
The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or
transcription errors; the designs in the figures are purely indicative. The Manufacturer also reserves the right
to make any modifications to the products as may be considered necessary or useful, also in the interests
of the user, without jeopardizing the main functional and safety features of the products themselves. This
cook top was designed to be used exclusively as a cooking appliance: any other use (such as
heating rooms) is to be considered improper and dangerous.
SMEG S.p.A.
Via Leonardo da Vinci, 4
42016 GUASTALLA - ITALIA
(01075UK)
Advertisement
Related Manuals for Smeg SE435S
Summary of Contents for Smeg SE435S
- Page 1 42016 GUASTALLA - ITALIA TIPO: PAZ04 MOD.: SE435S The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors; the designs in the figures are purely indicative. The Manufacturer also reserves the right to make any modifications to the products as may be considered necessary or useful, also in the interests of the user, without jeopardizing the main functional and safety features of the products themselves.
- Page 2 WARNING: The appliance and its accessible parts become hot during use. Care should be taken to avoid touching heating elements. Children less than 8 years of age shall be kept away unless continuously supervised. This appliance can be used by children aged from 8 years and above and persons with reduced physical, sensory or mental capabilities or lack of experience and knowledge if they have been given supervision or instruction concerning use of the appliance in a safe way and...
- Page 3 DESCRIPTION OF THE HOT PLATES TYPE: PAZ04 1 Normal plate Ø 14,5 cm of 1000 W 2 Normal plate Ø 18,0 cm of 1500 W 3 Rapid plate Ø 14,5 cm of 1500 W 4 Rapid plate Ø 18,0 cm of 2000 W 5 Thermostat plate Ø...
- Page 4 1) SWITCHING ON THE ELECTRIC diagram indicates to which electric plate the knob in question corresponds (see fig. 1 - 2). PLATES A red warning light will come on to indicate that the The hobs may be equipped with three types of plate has been ignited.
- Page 5 WARNINGS: - Containers wider than the unit are not when the plate is switched on for the first time, or recommended. if it has remained unused for a long period, it - The appliance must not be operated with an should be dried for 30 minutes on switch position external timer or a separate remote-control n°...
- Page 6 CLEANING IMPORTANT: WARNINGS: always disconnect the appliance from the - correctly preserve the plate after use by electricity main before carrying out any cleaning treating it with special products, easily operation. available on the market. This will keep the surface of the plate clean and bright. The 3) HOTPLATE operation will also prevent the formation of If you want to preserve the surface clean and bright,...
-
Page 7: Installation
INSTALLATION Installation and maintenance must only be - Overturn the hob and correctly position seal “E” carried out by a qualified installer. (fig. 6) under the edge of the hob itself, so that The appliance must be correctly installed in the outer part of the seal itself perfectly matches conformity with current law and the the outer perimetral edge of the hob. -
Page 8: Electrical Connections
INSTALLATION 6) ELECTRICAL CONNECTIONS - install an omnipolar cutout between the appliance itself and the main. This circuit-breaker should be sized according to the rating of the IMPORTANT: the appliance must be appliance and the opening between its contacts installed following the manufacturer's should be at least 3 mm. - Page 9 CONVERSIONS Disconnect the appliance from the mains b) Shift connecting plate on terminal according to supply prior to any conversions being carried the following chart. This chart is also affixed to the out. hob. c) Insert a supply cable of adequate section (see 7) CHANGING THE TYPE OF POWER chart par.
- Page 10 SERVICING Always disconnect the appliance from the N.B. In case of substitution of the input cable, electricity main before proceeding with any the installer must keep the “earth” conductor servicing operation. longer than “live” ones, and must respect the cautions in paragraph “Electrical connection”. 8) REPLACING THE ELECTRICAL To reassemble the appliance repeat the inverse COMPONENTS...
-
Page 11: Technical Data
TECHNICAL DATA MODEL WITH 2 RAPID PLATES + 2 THERMOSTAT PLATES VOLTAGE 230 - 240 V~ FREQUENCY 50/60 Hz TOT. RATING 7000 W MODEL WITH 2 RAPID PLATES + 2 NORMAL PLATES (with protector) VOLTAGE 230 - 240 V~ FREQUENCY 50/60 Hz TOT. -
Page 12: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS This appliance, before leaving the factory, has been carefully tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention.
