INSTRUCTIONS AND ADVICE FOR THE
USE, INSTALLATION AND MAINTENANCE
OF BUILT-IN ELECTRIC HOBS
Dear Customer,
Thank you for having purchased one of our products.
We are certain that this new, modern, functional and practical appliance, built with the very
highest quality materials, will meet your requirements in the best possible way. This hob is easy
to use. It is, however, important to thoroughly read the instructions in this handbook in order to
obtain the best results.
The manufacturer shall not be held responsible for any damages to persons or property
caused by incorrect installation or use of the appliance.
TIPO: PFZ 02
MOD.: SE32X
The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or
transcription errors; the designs in the figures are purely indicative. The Manufacturer also reserves the right
to make any modifications to the products as may be considered necessary or useful, also in the interests
of the user, without jeopardizing the main functional and safety features of the products themselves.
SMEG S.p.A.
Via Leonardo da Vinci, 4
42016 GUASTALLA - ITALIA
COD. 0101SMN1 (0101UK) - 24.10.2006
Advertisement
Related Manuals for Smeg SE32X
Summary of Contents for Smeg SE32X
- Page 1 TIPO: PFZ 02 MOD.: SE32X The Manufacturer shall not be held responsible for any inaccuracies in this handbook due to printing or transcription errors; the designs in the figures are purely indicative. The Manufacturer also reserves the right to make any modifications to the products as may be considered necessary or useful, also in the interests of the user, without jeopardizing the main functional and safety features of the products themselves.
- Page 2 DESCRIPTION OF THE HOT PLATES 4 Plate Ø 145 5 Plate Ø 180 11 Control knob for electric plate n° 4 12 Control knob for electric plate n° 5 13 Warning light indicating that one or more plates are operating TYPE: PFZ 02 of 1000 ÷...
- Page 3 1) SWITCHING ON THE ELECTRIC PLATES The hobs may be equipped with two types of electric plates: normal and rapid plates indicated by a red mark. The normal plates and the rapid plates are controlled by a 7 - position switch (see fig. 1). Switch on the plates by turning the knob to the required position.
- Page 4 WARNINGS: when the plate is switched on for the first time, or if it has remained unused for a long period, it should be dried for 30 minutes on switch position n° 1. This will eliminate any moisture that may have been absorbed by the insulating material.
- Page 5 IMPORTANT: always disconnect the appliance from the electricity main before carrying out any cleaning operation. 3) HOTPLATE If you want to preserve the surface clean and bright, periodically wash the hot plate with lukewarm soapy water. Following this, all parts should be thoroughly rinsed and dried.
-
Page 6: Installation
Installation and maintenance must only be carried out by a qualified installer. Incorrect installation could cause damage to persons, animals and property for which the manufacturer cannot be held responsible. 4) INSTALLING THE HOT PLATE Check that the appliance is in a good condition after having removed the outer packaging and internal wrappings from around the various loose parts. -
Page 7: Electrical Connections
6) ELECTRICAL CONNECTIONS Electrical connection must be carried out in compliance with the specifications and provisions in force. Before proceeding with the connections, check that: - the voltage rating of the appliance and the current sockets suits the maximum power draw of the appliance (see data label affixed to the lower part of the appliance itself). - Page 8 Always disconnect the appliance from the electricity main before proceeding with any servicing operation. 7) REPLACING THE ELECTRICAL COMPONENTS For access to the various parts, remove the hotplate from the top of the cabinet. Then overturn it, unscrew screw and remove under part. After these actions is possible to work on the plates, commutators, clamps and input cable.
-
Page 9: Technical Data
VOLTAGE FREQUENCY TOT. RATING VOLTAGE FREQUENCY TOT. RATING TECHNICAL DATA MODEL WITH 2 NORMAL PLATES MODEL WITH 2 RAPID PLATES 230 - 240 V~ 50/60 Hz 2500 W 230 - 240 V~ 50/60 Hz 3500 W... -
Page 10: Technical Assistance And Spare Parts
TECHNICAL ASSISTANCE AND SPARE PARTS This appliance, before leaving the factory, has been carefully tested and regulated by expert and specialized personnel in order to guarantee the best performances. Any repairs or adjustments which may be subsequently required may only be carried out by qualified personnel with the utmost care and attention.
