Crest Electronics CC-4807XS-21 User Manual

Specification
Model CC-4807XS-21
1/3" SONY Super HAD CCD II EFFIO V
Pick up Element
Effective Picture Elements
NTSC: 976(H)×494(V)
(H×V)
720 TV Line
Horizontal Resolution
Minimum Illumination 0.001 Lux
S/N Ratio More than 52dB
Scanning System 2:1 interface
Synchronous System Internal, Negative sync.
Auto Electronic Shutter NTSC: 1/60s~1/100,000s
Gama Characteristic 0.45
65 Feet
IR Distance
(with 5X21 Unit Infrared LED)
Video Output 1Vpp, 75Ω
Auto
Auto Gain Control
YES
UTC
24VAC/12VDC(+/-10%)/500mA
Power/Current
Lens 2.8-12mm Manual Zoom Lens
5.7X4.25(H) in
Dimension (mm)
2.65
Weight (lbs)
Storage Temperature -4°F~140°F RH95% MAX
14°F~122°F RH95% MAX
Operating Temperature
Packing List
No
Name
1.
Vandalproof IR Dome Camera CC-4807XS-21
2.
User Guide CC-4807XS-21
Model Number
1
1
ALLIANCE DRIVE
GREENSBORO, NC
-
- -CREST/ - -
FAX:
- -
www.crestelectro ics.co
CC-4807XS-21 Color Camera
User Guide
Vandalproof IR Dome w/
3-Axis Bracket
NOTE:
Please read this guide BEFORE
installing
