Crest Electronics CCA-7910WS-40 User Manual

Specification

CCA-7910WS-40
Model
1/4" Aptina 1.0MP CMOS Sensor
Pick up Element
Effective Picture Elements
NTSC: 1280(H)×720(V)
(H×V)
720p
Resolution
0.01 Lux/F1.2
Minimum Illumination
0Lux (with IR LED ON)
S/N Ratio More than 50dB
Scanning System 2:1 interface
Internal, Negative sync.
Synchronous System
NTSC: 1/30s~1/60,000s
Auto Electronic Shutter
Gama Characteristic 0.45
131 Feet (with ￠5X42 PCS Infrared LED)
IR Distance
Video Output 1Vp-p, 75Ω (AHD or 960H)
Auto Gain Control Auto
Power/Current 12VDC(+/-10%)/700mA
2.8-12mm Manual Zoom Lens
Lens
Dimension (in) 11.5(W) x 3.6(H) x 3.7(D)
Weight (lb) 3.43
Storage Temperature -22°F~140°F RH95% MAX
Operating Temperature 14°~122°F RH95% MAX

Packing List

No
Name
1.
Weatherproof IR Bullet Camera
CCA-7910WS-40
w/mount
2.
CCA-7910WS-40
User Guide
Model Number
1
1
ALLIANCE DRIVE
GREENSBORO, NC
-
- -CREST/ - -
FAX:
- -
www.crestelectro ics.co
CCA-7910WS-40 Color Camera
Weatherproof IR Bullet Camera
AHD/960H Analog
NOTE:
Please read this guide BEFORE
installing
