Specification
CC-2807WF-20
Model
1/3" SONY Super HAD CCD
Pick up Element
Effective Picture Elements
NTSC:976(H)×494(V) PAL:976(H)x582(V)
(H×V)
Horizontal Resolution
720 TV Line
0.001 Lux/F1.2
Minimum Illumination
0Lux (with IR LED ON)
S/N Ratio
More than 52dB
2:1 interface
Scanning System
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s, PAL: 1/50s~1/100,000s
0.45
Gama Characteristic
20 Meters (with ￠5X24 PCS Infrared LED)
IR Distance
Video Output
1Vpp, 75Ω
Auto Gain Control
Auto
DC12V(+/-10%)/350mA
Power/Current
Board Lens 3.6mm /F2.0
Lens
Dimension (in)
3.8 x 2.8
Weight (oz)
14.5
Storage Temperature
-22~+140°F RH95% MAX
+14~+120°F RH95% MAX
Operating Temperature
Packing List
No
Name
1.
Vandalproof
CC-2807WF-20
IR Dome Color Camera
2.
CC-2807WF-20
User Guide
II
Model
Number
1
1
ALLIANCE DRIVE
GREENSBORO, NC
-
-CREST/
-
-
FAX:
-
-
www.crestelectro ics.co
CC-2807WF-20 Color Camera
Vandalproof IR Dome Color Camera
Effio-A
NOTE:
Please read this guide BEFORE
installing
Advertisement
Related Manuals for Crest Electronics CC-2807WF-20
Summary of Contents for Crest Electronics CC-2807WF-20
-
Page 1: Packing List
Specification CC-2807WF-20 Model CC-2807WF-20 Color Camera 1/3" SONY Super HAD CCD Pick up Element Effective Picture Elements NTSC:976(H)×494(V) PAL:976(H)x582(V) (H×V) Horizontal Resolution 720 TV Line 0.001 Lux/F1.2 Minimum Illumination 0Lux (with IR LED ON) S/N Ratio More than 52dB Vandalproof IR Dome Color Camera... -
Page 2: Troubleshooting
SETTING ● This installation should be made by a qualified service person LCD/CRT touching “ground” and conform to all local codes. Crest Electronics will not be COMMUNICATION responsible for damages or injuries as a result of improper CAMERA ID installation ◆...
