Specification
Model
CC-4707XS-21
1/3" SONY Super HAD CCD II EFFIO V
Pick up Element
Effective Picture Elements
NTSC: 976(H)×494(V)
(H×V)
720 TV Line
Horizontal Resolution
Minimum Illumination
0.001 Lux
S/N Ratio
More than 52dB
Scanning System
2:1 interface
Synchronous System
Internal, Negative sync.
Auto Electronic Shutter
NTSC: 1/60s~1/100,000s
Gama Characteristic
0.45
65 Feet
IR Distance
(with 5X21 Unit Infrared LED)
Video Output
1Vpp, 75Ω
Auto
Auto Gain Control
YES
UTC
12VDC(+/-10%)/500mA
Power/Current
Lens
2.8-12mm Manual Zoom Lens
5.8X3.9(H) in
Dimension (mm)
1.7
Weight (lbs)
Storage Temperature
-4°F~140°F RH95% MAX
14°F~122°F RH95% MAX
Operating Temperature
Packing List
No
Name
1.
Indoor Dome Camera
CC-4707XS-21
2.
User Guide
CC-4707XS-21
Model
Number
1
1
ALLIANCE DRIVE
GREENSBORO, NC
-
- -CREST/
-
-
FAX:
-
-
www.crestelectro ics.co
CC-4707XS-21 Color Camera
User Guide
Indoor Dome w/
3-Axis Bracket
NOTE:
Please read this guide BEFORE
installing
Advertisement
Table of Contents
Related Manuals for Crest Electronics CC-4707XS-21
Summary of Contents for Crest Electronics CC-4707XS-21
-
Page 1: Packing List
Specification Model CC-4707XS-21 CC-4707XS-21 Color Camera 1/3" SONY Super HAD CCD II EFFIO V Pick up Element Effective Picture Elements NTSC: 976(H)×494(V) (H×V) 720 TV Line User Guide Horizontal Resolution Minimum Illumination 0.001 Lux S/N Ratio More than 52dB Scanning System... -
Page 2: Troubleshooting
Check to make sure the ● This installation should be made by a qualified service person LANGUAGE FRANCAIS/DEUISCH ROLLING PICTURE and conform to all local codes. Crest Electronics will not be re- coax shield AUTO LEVEL1/LEVEL2/AUTO sponsible for damages or injuries as a result of improper installa- touching “ground”...
