Enterasys SecureStack A2 A2H124-24 Datasheet page 5

Switch Model Specifications (cont.)
A2H124-24
Performance
Throughput Capacity 9.5 Mpps / 76.2 Mpps
wire-speed Mpps
(switch / stack)
Switching Capacity 12.8 Gbps / 102.4 Gbps
(switch / stack)
Stacking Capacity No dedicated stacking ports
(switch / stack) on A2; 10/100/1000 can be
used for stacking or uplinks
Aggregate Throughput 12.8 Gbps / 102.4 Gbps
Capacity (switch / stack)
PoE Specifications
802.3af Compliance N/A
System Power N/A
Physical Specifications
Dimensions (H x W x D) H: 4.4 cm (1.73")
W: 44.1 cm (17.36")
D: 21.0 cm (8.27")
Net Weight 2.61 kg (5.75 lb)
MTBF 124,279 hours
Physical Ports • (24) 10/100 auto-sensing,
• (2) mini-GBIC ports
• (2) 10/100/1000 stacking/
• (1) DB9 console port
• (1) RPS port
Power Requirements
Nominal Input Voltage 100 – 240 VAC
Input Frequency 50 – 60 Hz
Input Current 1.0 A Max
Power Consumption 29 watts
Temperature
IEC 6-2-1 0° to 50° C
Standard Operating (32° to 122° F)
Temperature
IEC 6-2-14 -40° to 70° C
Non-Operating (-40° to 158° F)
Temperature
Heat Dissipation 98 BTUs/Hr
Humidity
Operating Humidity 5% - 95% non-condensing
Vibration
IEC 68-2-6, IEC68-2-36
Shock
IEC 68-2-29
Drop
IEC 68-2-32
A2H124-24P
9.5 Mpps / 76.2 Mpps
12.8 Gbps / 102.4 Gbps
No dedicated stacking ports on
A2; 10/100/1000 can be used
for stacking or uplinks
12.8 Gbps / 102.4 Gbps
Yes
360 watts per switch with up
to 15.4 watts per port
Per-port switch power monitor:
• Enable/disable
• Priority safety
• Overload & short circuit
H: 4.4 cm (1.73")
W: 44.1 cm (17.36")
D: 36.85 cm (14.51")
5.78 kg (12.73 lb)
201,377 hours
• (24) 10/100 PoE auto-
auto-negotiating, MDI/
MDI-X, RJ45 ports
• (2) mini-GBIC ports
• (2) 10/100/1000 stacking/
uplink RJ45 ports
• (1) DB9 console port
• (1) RPS port
100 – 240 VAC
50 – 60 Hz
5.0 A Max
444 watts
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
166 BTUs/Hr
5% - 95% non-condensing
IEC 68-2-6, IEC68-2-36
IEC 68-2-29
IEC 68-2-32
protection
sensing, auto-negotiating,
MDI/MDI-X, RJ45 ports
uplink RJ45 ports
A2H124-48
13.1 Mpps / 104.8 Mpps
17.6 Gbps / 140.8 Gbps
No dedicated stacking ports on
A2; 10/100/1000 can be used
for stacking or uplinks
17.6 Gbps / 140.8 Gbps
N/A
N/A
H: 4.4 cm (1.73")
W: 44.1 cm (17.36")
D: 36.85 cm (14.51")
4.73 kg (10.42 lb)
115,219 hours
• (48) 10/100 auto-sensing,
auto-negotiating, MDI/MDI-X,
RJ45 ports
• (2) mini-GBIC ports
• (2) 10/100/1000 stacking/
uplink RJ45 ports
• (1) DB9 console port
• (1) RPS port
100 – 240 VAC
50 – 60 Hz
1.0 A Max
50 watts
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
170 BTUs/Hr
5% - 95% non-condensing
IEC 68-2-6, IEC68-2-36
IEC 68-2-29
IEC 68-2-32
A2H124-48P
13.1 Mpps / 104.8 Mpps
17.6 Gbps / 140.8 Gbps
No dedicated stacking ports on
A2; 10/100/1000 can be used
for stacking or uplinks
17.6 Gbps / 140.8 Gbps
Yes
360 watts per switch with up
to 15.4 watts per port
Per-port switch power monitor:
• Enable/disable
• Priority safety
• Overload & short circuit
protection
H: 4.4 cm (1.73")
W: 44.1 cm (17.36")
D: 36.85 cm (14.51")
6.39 kg (14.08 lb)
169,150 hours
• (48) 10/100 PoE auto-
sensing, auto-negotiating,
MDI/MDI-X, RJ45 ports
• (2) mini-GBIC ports
• (2) 10/100/1000 stacking/
uplink RJ45 ports
• (1) DB9 console port
• (1) RPS port
100 – 240 VAC
50 – 60 Hz
5.0 A Max
462 watts
0° to 50° C
(32° to 122° F)
-40° to 70° C
(-40° to 158° F)
284 BTUs/Hr
5% - 95% non-condensing
IEC 68-2-6, IEC68-2-36
IEC 68-2-29
IEC 68-2-32
