Installation Instructions
Over the Range Microwave Oven
BEFORE YOU BEGIN
Read these instructions completely and carefully.
IMPORTANT –
•
local inspector's use.
IMPORTANT –
•
and ordinances.
• Note to Installer – Be sure to leave these
instructions with the Consumer.
READ CAREFULLY. KEEP THESE INSTRUCTIONS.
Save these instructions for
Observe all governing codes
• Note to Consumer – Keep these instructions for
future reference.
• Skill level – Installation of this appliance requires
basic mechanical and electrical skills.
• Proper installation is the responsibility of the
installer.
• Product failure due to improper installation is not
covered under the Warranty.
Felix Storch, Inc.
Summit Appliance Division
770 Garrison Avenue
Bronx, New York 10474
www.summitappliance.com
Advertisement
Table of Contents
Related Manuals for Summit OTRSS30
Summary of Contents for Summit OTRSS30
- Page 1 Felix Storch, Inc. Summit Appliance Division 770 Garrison Avenue Bronx, New York 10474 www.summitappliance.com Installation Instructions Over the Range Microwave Oven BEFORE YOU BEGIN Read these instructions completely and carefully. • Note to Consumer – Keep these instructions for IMPORTANT –...
-
Page 2: Table Of Contents
Installation Instructions CONTENTS General information Recirculating ........... 20–22 Attach Mounting Plate to Wall ....20 Important Safety Instructions .....3 Preparation of Top Cabinet ..... 20 Electrical Requirements ......3 Mount the Microwave Oven....21, 22 Hood Exhaust ...........4, 5 Installing the Charcoal Filter ....22 Damage –... -
Page 3: Important Safety Instructions
Installation Instructions IMPORTANT SAFETY INSTRUCTIONS This product requires a three-prong grounded outlet. You should have the wall receptacle and circuit The installer must perform a ground continuity check checked by a qualified electrician to make sure on the power outlet box before beginning the the receptacle is properly grounded. -
Page 4: Hood Exhaust
Installation Instructions HOOD EXHAUST NOTE: Read these next two pages only if you plan to vent your exhaust to the outside. If you plan to recirculate the air back into the room, proceed to page 6. OUTSIDE TOP EXHAUST (EXAMPLE ONLY) The following chart describes an example of one possible ductwork installation. - Page 5 Installation Instructions Maximum duct length: NOTE: If you need to install ducts, note that the total duct length of 3¼" x 10" rectangular or 6" diameter For satisfactory air movement, the total duct length of round duct should not exceed 140 equivalent feet. 3¼"...
-
Page 6: Damage - Shipment/Installation
Installation Instructions DAMAGE – SHIPMENT/ PARTS INCLUDED INSTALLATION HARDWARE PACKET • If the unit is damaged in shipment, return the unit to the store in which it was bought for repair or replacement. Wood Screws • If the unit is damaged by the customer, repair (1/8"... -
Page 7: Tools You Will Need
Installation Instructions TOOLS YOU WILL NEED Ruler or tape measure and straight edge Carpenter square (optional) Pencil # 1 and #2 Phillips screwdriver Tin snips (for cutting Scissors Electric drill with ", ½" damper, if required) Filler blocks or scrap wood (to cut template, if necessary) "... -
Page 8: Placement Of Mounting Plate
Installation Instructions 1. PLACEMENT OF THE MOUNTING PLATE REMOVING THE MICROWAVE FINDING THE WALL STUDS OVEN FROM THE CARTON/ ASSEMBLE THE MOUNTING PLATE Remove the installation instructions, filters, glass tray and the small hardware bag. Do not remove Wall Studs the Styrofoam protecting the front of the oven. -
Page 9: Determining Wall Plate Location
Installation Instructions DETERMINING WALL PLATE LOCATION UNDER YOUR CABINET Plate position – beneath framed recessed Plate position – beneath flat bottom cabinet cabinet bottom Mounting Plate Tabs Touching the Cabinet Bottom Mounting Plate Tabs Touching the Back Frame 30" to Cooktop Your cabinets may have decorative trim that Plate position –... -
Page 10: Aligning The Wall Plate
Installation Instructions ALIGNING THE WALL PLATE Draw a Vertical Line on Wall from Center of Hole A Centerline Top Cabinet notches Area E Hole C Hole B CAUTION: Wear gloves to avoid cutting fingers on sharp edges. NOTE: Holes A,B and C are inside area E. If none of Draw a vertical line on the wall at the center of the A,B and c is in a stud, find a stud somewhere in area 30"... -
Page 11: Installation Types
Installation Instructions 2. INSTALLATION TYPES (Choose A, B or C) This microwave oven is designed for adaptation to NOTE: This microwave is shipped assembled for the following three types of ventilation: Recirculating． A. Outside Top Exhaust (Vertical Duct) B. Outside Back Exhaust (Horizontal Duct) C. -
Page 12: Attach Mounting Plate To Wall
Installation Instructions OUTSIDE TOP EXHAUST (Vertical Duct) INSTALLATION OVERVIEW A1. Attach Mounting Plate to Wall A2. Prepare Top Cabinet A3. Check Microwave Assembly A4. Check Damper Operation A5. Mount Microwave Oven A6. Adjust Exhaust Adaptor Connect Ductwork To use toggle bolts: ATTACH THE MOUNTING PLATE TO THE WALL Spacing for Toggles More... -
Page 13: Preparation Of Top Cabinet
Installation Instructions USE TOP CABINET TEMPLATE Roll the blower unit 90° so that fan blade FOR PREPARATION OF TOP openings are facing out the up of the CABINET microwave. After Rolling Before Rolling You need to drill holes for the top support screws, a hole large enough for the power cord to fit through, and a cutout large enough for the exhaust adaptor. -
Page 14: Checking For Proper Damper Operation
Installation Instructions MOUNT THE MICROWAVE OVEN CHECK FOR PROPER DAMPER OPERATION Exhaust Adaptor (absent on models shipped for recirculation exhaust) Blower Plate Damper FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THAT TWO PEOPLE INSTALL THIS MICROWAVE OVEN. Back of IMPORTANT: Do not grip or use handle during Microwave installation. -
Page 15: Adjust The Exhaust Adaptor
Installation Instructions MOUNT THE MICROWAVE OVEN ADJUST THE EXHAUST ADAPTOR (cont.) Open the top cabinet and adjust the exhaust adaptor to connect to the house duct. Cabinet Front Cabinet Bottom Shelf Back of Damper Filler Block Microwave Blower Plate Equivalent to Depth of Cabinet Recess For Front-to-Back or... -
Page 16: Outside Back Exhaust
Installation Instructions OUTSIDE BACK EXHAUST (Horizontal Duct) INSTALLATION OVERVIEW B1. Prepare Rear Wall B2. Attach Mounting Plate to Wall B3. Prepare Top Cabinet B4. Adjust Blower B5. Mount the Microwave Oven PREPARING THE REAR WALL FOR OUTSIDE BACK EXHAUST You need to cut an opening in the rear wall for outside exhaust. -
Page 17: Attach Mounting Plate To Wall
Installation Instructions ATTACH THE MOUNTING PLATE USE TOP CABINET TEMPLATE FOR PREPARATION OF TOP CABINET You need to drill holes for the top support screws and a hole large enough for the power cord to fit through. Attach the plate to the wall using toggle bolts. At least one wood screw must be used to attach the plate to a wall stud. - Page 18 Installation Instructions ADAPTING MICROWAVE BLOWER Place the blower unit back into the opening. FOR OUTSIDE BACK EXHAUST (cont.) AFTER : Fan Blade Openings Facing Back End A Openings Facing Back Remove “Parts A”with Nipper or Scissors. End B Part”A” CAUTION: Do not pull or stretch the blower unit wiring.
-
Page 19: Mount The Microwave Oven
Installation Instructions MOUNT THE MICROWAVE OVEN Cabinet Front Cabinet Bottom Shelf Filler Block Equivalent to Depth of Cabinet Recess FOR EASIER INSTALLATION AND PERSONAL SAFETY, WE RECOMMEND THAT TWO PEOPLE Self-Aligning Screw INSTALL THIS MICROWAVE OVEN. Microwave Oven Top IMPORTANT: Do not grip or use handle during installation. -
Page 20: General Information C Recirculating
Installation Instructions RECIRCULATING (Non-Vented Ductless) INSTALLATION OVERVIEW C1. Attach Mounting Plate to Wall C2. Prepare Top Cabinet C3. Mount the Microwave Oven C4. Install Charcoal Filter ATTACH THE MOUNTING PLATE Place the mounting plate against the wall and TO THE WALL insert the toggle wings into the holes in the wall to mount the plate. -
Page 21: Mount The Microwave Oven
Installation Instructions MOUNT THE MICROWAVE OVEN NOTE: When mounting the microwave oven, thread power cord through hole in bottom of top cabinet. Keep it tight throughout Steps 1–3. Do not pinch cord or lift oven by pulling cord. Lift microwave, tilt it forward, and hook slots at back bottom edge onto four lower tabs of... -
Page 22: Installing The Charcoal Filter
Installation Instructions MOUNT THE MICROWAVE OVEN INSTALLING THE CHARCOAL (cont.) FILTER Insert 2 self-aligning screws Remove screws on top of grille using a #1 Phillips through outer top cabinet holes. screwdriver. Turn two full turns on each screw. Open the door. Remove the grille. -
Page 23: Before You Use Your Microwave
Installation Instructions BEFORE YOU USE YOUR MICROWAVE Make sure the microwave oven has been installed according to instructions. Read the Owner’s Manual. Remove all packing material from the microwave KEEP INSTALLATION INSTRUCTIONS FOR oven. THE LOCAL INSPECTOR’S USE. Install turntable and ring in cavity. Replace house fuse or turn breaker back on.
