- Page 1 UL Model No. 5LLR54XXD ’ wner anual Ceiling Fan Installation Instructions For 5llr54XXd series Fans read and save These InsTrucTIOns Total fan weight with light kit...
- Page 2 Installation aFeTy warnInG: TO reduce The rIsK OF FIre, elecTrIc shOcK, Or InJury TO persOns, OBserve The FOllOwInG: read and save These InsTrucTIOns Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70-1999), including fire-rated construction.
- Page 3 Thread leadwires and safety cable Loosen the 2 screws on the yoke to Insert down rod into yoke on top of through the downrod allow down rod to slip into yoke. the fan body. Align the hole in the down rod with the hole in the yoke. Insert the Pin through the yoke and down rod until the point appears on the other side.
- Page 4 Make wire connections to power source using wire nuts provided. Make sure that no filiments are outside of the wirenut. After making the wire connections, the wires should be spread apart with the grounded con- Lift canopy and install knurled nuts as Check motor for shipping stabilizers and ductor and the equipment-grounding conductor on one shown.
- Page 5 HAND HELD INSTALL WALL MOUNT INSTALL Place face plate over battery compartment and Remove battery cover. Install 12V battery into buttons. Place remote over 2 pins on front wall remote. Duracell MN21 / Eveready A23 / GP 23A all 12V.Attach cover of remote by placing cover.
- Page 6 remote control Transmitter Features: LED LIGHT MEDIUM SPEED HIGH SPEED LOW SPEED FAN OFF SETTING LIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) Fan speed Depress “l dot” for low speed, “2 dots” for medium or “3 dots” for high.
- Page 7 ROUBLE HOOTING If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart.
