- Page 1 Owner’s 5LCR52-Engish-CUL Manual Ceiling Fan Installation Instructions Total fan weight For 5LCR52 Series Fans READ AND SAVE THESE INSTRUCTIONS Quality Ceiling fans...
- Page 2 Installation AFETY WARNING: TO REDUCE THE RISK OF FIRE, ELECTRIC SHOCK, OR INJURY TO PERSONS, OBSERVE THE FOLLOWING: READ AND SAVE THESE INSTRUCTIONS Installation work and electrical wiring must be done by qualified person(s) in accordance with applicable codes and standards (ANSI/NFPA 70- 1999), including fire-rated construction.
- Page 3 Install downrod into yoke. Thread electrical wires and safety Align hole in downrod with hole in cable through downrod. yoke and install cross pin. Raise fan with downrod assembled to the ceil- Tighten 2 downrod set screws. ing bracket and hang fan assembly. Be sure to install cotter pin into cross pin.
- Page 4 Before attaching the blades remove Attach blade brackets to blades using Check the motor for plastic shipping stabilizer the switch housing cap. Save the the blade bracket screws and wash- tabs, and remove them if they are present. The screws, washers and motor pads are pre- ers provided.
- Page 5 Remote Control Transmitter Features: FAN REVERSE LED LIGHT (Press once to change direction of MEDIUM SPEED the fan)Fanmust be running to reverse. HIGH SPEED LOW SPEED FAN OFF SETTING UPLIGHT ON/OFF SET- (Turns fan off only) TING AND DIMMER (Press and hold to dim light infinitively) DOWNLIGHT ON/OFF SETTING AND DIMMER...
- Page 6 Trouble Shooting If you have difficulty operating your new ceiling fan, it may be the result of incorrect assembly, installation, or wiring. In some cases, these installation errors may be mistaken for defects. If you experience any faults, please check this Trouble Shooting Chart. If a problem cannot be remedied, or you are experiencing difficulty in installation, please call our Customer Service Center at the number printed on your parts list insert sheet.
