Acer U5200 Manual page 51

Are there any personal firewalls enabled?
Due to your network or firewall settings, the client application may not be
able to connect to the projector server. Please make sure the settings allow
the application to be able to communicate with the server.
To enable wireless projection, your personal firewall needs to allow the
APG application to pass through.
Due to your firewall settings, the client application may not be able to
establish a connection for video streaming. Please make sure the firewall
settings allow the application to communicate with the server (inbound
TCP port: 1041).
• What are the possible connection combinations?
APG
System
connection
WLAN WLAN
WLAN WLAN +
Wired
WLAN + WLAN
Wired
WLAN + WLAN +
Wired Wired
Wired Wired
Wired Other access
point
• How do I register the APG on the firewall exceptions list for Windows XP
SP2?
1. Click Start > Control Panel.
2. Click Security Center > Windows Firewall when the Control Panel
window opens.
3. Click the Exceptions tab and then Add Program... when the Windows
Firewall window opens.
4. Click Acer Projector Gateway to allow connection with external devices
under Programs when the Add a Program window opens.
• What is the Gatekeeper?
The Gatekeeper is designed to ensure enterprise network security for the
APG.
All Block blocks guest users from wireless access to the office LAN.
Projector Internet Remark
V X 192.168.100.10
V V 192.168.100.10
Please execute the application
first if you need to access the
Internet.
V V By LAN DHCP address
Please enter the IP address on
the welcome screen.
V V By LAN DHCP address
Please enter the IP address on
the welcome screen.
V V By LAN DHCP address
Please enter the IP address on
the welcome screen.
V V By LAN DHCP address
Please enter the IP address on
the welcome screen.
51
