Realtree RTLS-314 Instruction & Safety Manual page 7

Assembly Instructions Page 1
1
D
2
Lay the two Foot Platforms
1
(grate side down). Fasten the Foot Platforms
together using 3-M8x55mm bolts
3
L
E
1
I
Attach the Ladder Yokes
3
E using 2-M6x40mm bolts
Left Handle Rail
to the Back Rest Supports
2-M8x65mm bolts
