MODEL: RTLS-314
16' Extra Wide Deluxe Single Man Ladderstand
• Always Wear a Safety Harness with this Product
• Weight Limit: 300 lbs.
HARDWARE BOX P/N 314H
T
1 Horiz. Jaw Assembly Strap..... Part # HJA-310
U
1 Adjustment Knob.................... Part # AK-100
V
4 M6 Quickclips......................... Part # 1615
W
1 Jaw Ratchet Strap................... Part # JRS-310
X
1 Jaw Assembly Vertical Strap... Part # AVS-310
Y
1 Jaw Assembly Tree Buckle ....
Z
1 Stabilizer Buckle Strap............
AA
2 Installation Straps....................Part # IS-310
BB
1 Ratchet Strap......................... Part # RA-310
CC 2 Slide Brackets..........................Part # RSB110
DD
2 Adjustment Knob......................Part # RAK-110
25 2 M6 x 25mm Bolt..................... Part # 1025
40 4 M6 x 40mm Bolt......................Part # 1040
55 2 M6 x 55mm Bolt......................Part # 1055
86 2 M6 x 85mm Bolt w/spacer...... Part # 1085
45 3 M8 x 45mm Bolt..................... Part # 1245
55 9 M8 x 55mm Bolt..................... Part # 1255
56 2 M8 x 55mm Bolt w/spacer...... Part # 1260
60 6 M8 x 60mm Bolt..................... Part # 1260
2 M8 x 65mm Bolt..................... Part # 1265
65
100 2 M8 x 100mm Bolt w/spacer....
1 Harness................................... Part # 2021
= NOT PICTURED IN THIS MANUAL
Tools Required
Adjustable Wrench
Distributed by Acheson Harriman Swan, LLC, 2407 W. Euclid Ave., Littleton, CO 80120
Customer Service Department 1-866-972-6168
• Practice Using at Ground Level
• Tree Size: 9"-18" diameter
T Horizontal Jaw Assembly
Strap (1)
.. Part # ATB-310
Jaw Ratchet
W
Part # PXBS-555
Strap (1)
Z
Part # 1275
CC
Slide Brackets (2)
U
X Jaw Assembly
Vertical Strap (1)
Stabilizer Buckle AA Installation
Strap (1) Straps (2)
DD
Adjustment Knobs (2)
Adjustment V M6
Knob (1) Quickclip (4)
Jaw Assembly
Y
Tree Buckle (1)
Ratchet
BB
Strap (1)
