- Page 1 INSTRUCTION MANUAL Angle Grinder GA7070 GA7071 GA9070 GA9071 DOUBLE INSULATION Read before use.
-
Page 2: Specifications
Sound pressure level (L ) : 91 dB(A) Sound power level (L ) : 102 dB (A) Uncertainty (K) : 3 dB(A) Model GA9070 Sound pressure level (L ) : 91 dB(A) DOUBLE INSULATION Sound power level (L ) : 102 dB (A) -
Page 3: Ec Declaration Of Conformity
Vibration emission (a ) : 3.9 m/s h, DS Uncertainty (K) : 1.5 m/s General power tool safety warnings Model GA9070 Work mode: surface grinding with normal side grip Vibration emission (a ) : 4.9 m/s WARNING: Read all safety warnings, instruc-... - Page 4 Do not expose power tools to rain or wet con- Do not let familiarity gained from frequent use ditions. Water entering a power tool will increase of tools allow you to become complacent and the risk of electric shock. ignore tool safety principles. A careless action can cause severe injury within a fraction of a second.
-
Page 5: Grinder Safety Warnings
Keep handles and grasping surfaces dry, Wear personal protective equipment. clean and free from oil and grease. Slippery Depending on application, use face shield, handles and grasping surfaces do not allow for safety goggles or safety glasses. As appro- safe handling and control of the tool in unexpected priate, wear dust mask, hearing protectors, situations. - Page 6 Maintain a firm grip on the power tool and Do not position your body in line with and position your body and arm to allow you to behind the rotating wheel. When the wheel, at the point of operation, is moving away from your resist kickback forces.
-
Page 7: Functional Description
WARNING: DO NOT let comfort or familiarity with product (gained from repeated use) replace GA7070, GA9070 strict adherence to safety rules for the subject product. MISUSE or failure to follow the safety rules stated in this instruction manual may cause serious personal injury. - Page 8 Do not pull the switch trigger hard There are three patterns of the switch action depending without pressing in the lock lever. This can cause on country. switch breakage. GA7070, GA9070 For tool with the lock-on and lock-off switch Country specific CAUTION: Switch can be locked in "ON"...
- Page 9 Indication lamp Soft start feature Soft start feature reduces starting reaction. ASSEMBLY CAUTION: Always be sure that the tool is switched off and unplugged before carrying out any work on the tool. Installing side grip (handle) ► 1. Indication lamp CAUTION: Always be sure that the side grip is installed securely before operation.
- Page 10 The loop handle can be more comfortable than the original side For tool with clamp lever type wheel grip for some applications. To install the loop handle, mount it guard onto the tool as illustrated and tighten two bolts to fix it. To remove the loop handle, follow the installation proce- Optional accessory dure in reverse.
- Page 11 Securely tighten the nut using a spanner, and then To tighten the lock nut, press the shaft lock firmly so close the lever in direction of the arrow to fasten the that the spindle cannot revolve, then use the lock nut wrench and securely tighten clockwise.
- Page 12 Optional accessory Only for tools with M14 spindle thread. Mount inner flange, abrasive wheel and Ezynut onto the spindle so that Makita Logo on Ezynut faces outside. Installing or removing abrasive disc Optional accessory ► 1. Ezynut 2. Abrasive wheel 3. Inner flange 4.
- Page 13 Installing or removing abrasive cut- Installing wire cup brush off / diamond wheel Optional accessory Optional accessory CAUTION: Do not use brush that is damaged, or which is out of balance. Use of damaged brush When using an abrasive cut-off WARNING: could increase potential for injury from contact with / diamond wheel, be sure to use only the special...
-
Page 14: Operation
OPERATION Dust collecting wheel guard for cut-off (for model GA9070 / GA9071) WARNING: It should never be necessary to force the tool. The weight of the tool applies ade- quate pressure. Forcing and excessive pressure could cause dangerous wheel breakage. - Page 15 Usage example: operation with abrasive cut-off Grinding and sanding operation wheel Turn the tool on and then apply the wheel or disc to the Usage example: operation with diamond wheel workpiece. In general, keep the edge of the wheel or disc at an angle of about 15°...
-
Page 16: Brake Maintenance
Discoloration, deformation or cracks may result. To maintain product SAFETY and RELIABILITY, repairs, any other maintenance or adjustment should be performed by Makita Authorized or Factory Service Centers, always using Makita replacement parts. ► 1. Exhaust vent 2. Inhalation vent Brake maintenance... -
Page 17: Optional Accessories
The use of any other accessories or attachments might present a risk of injury to persons. Only use accessory or attachment for its stated purpose. If you need any assistance for more details regarding these accessories, ask your local Makita Service Center. 180 mm... - Page 18 180 mm 230 mm Lock nut wrench Dust cover attachment NOTE: *1 Only for tools with M14 spindle thread. NOTE: *2 In some European countries, when using a diamond wheel, the ordinary guard can be used instead of the special guard covering the both side of the wheel. Follow the regulations in your country. NOTE: *3 Use Inner flange 78 and Outer flange 78 together.
- Page 20 Jan-Baptist Vinkstraat 2, Makita Europe N.V. 3070 Kortenberg, Belgium 3-11-8, Sumiyoshi-cho, Makita Corporation Anjo, Aichi 446-8502 Japan 885878-226 www.makita.com 20210426...
