booting. The Ignition state will be latched for 60 more seconds so that the motherboard will
have a change to come up in a clean manner.
3) Ignition=ON. Your computer will remain ON.
4) Ignition=OFF. M2-ATX waits for "OFFDELAY" in seconds (see jumper chart) and then it turns
the motherboard OFF by sending a signal to the motherboard's ON/OFF switch. Your
computer should turn off gracefully (shutdown procedure). After shutdown, 5VSB will still be
provided for another "HARDOFF" seconds. In the event where the shutdown process is
longer than "HARDOFF" (Operating System gets frozen, etc), power will be shut down hard,
turning off all power rails. During the HARDOFF procedure, the battery levels will be
constantly monitored to prevent deep discharge situations.
5) M2-ATX will go to step 1, if ignition is tuned ON again.
3.0 M2-ATX Characteristics
Minimum Input Operating. voltage 6V
Maximum input Operating voltage 24V (clamping will occur at 25-27V)
Deep-Discharge shutdown
threshold
Input current limit (fuse protected) 15A (15A mini-blade fuse)
Max Output Power
Operating temperature
Storage temperature
MTBF
Efficiency (Input 9-16V)
PCB size
Input connectors
Output Connector
*Units starts failing at ~115 Celsius. Operating at temperatures above 85C / 185F will drastically reduce the MTBF. When
operating at high temperatures or fanless operation, must reduce PSU load by 25%.
99
96
93
90
87
84
81
78
75
6 8 10
Maximum Power Characteristics
Output Rail
5V
3.3V
5VSB
-12V
12V
Total power = 169.9 Watts
When operating at 24V or extreme temperatures, de-rate by 30-50%, ventilation will be required.
M2-ATX User Guide
Iout = 5A
Iout = 6A
Iout = 8A
12 14 16 18
Vin (V)
Current (Max) Current Peak
(<60 seconds)
8A 10A
8A 10A
1.5A 2A
0.15A 0.2A
8A* (see below) 10A
11.2V
160 Watts
-40 to +85* degrees Celsius
-55 to +125 degrees Celsius
192,000 hrs @ 50C, 96,000 hrs @65C
>94%, all rails combined, 50% load.
160x45mm
Faston 0.25" terminal
ATX Power 20 pin (Molex P/N 39-01-2200
Regulation
1.5%
1.5%
1.5%
5-%
2%
Page 4
