About the controls on the air conditioner.
Features and appearance will vary.
Lights next to the touch pads on the air conditioner control panel indicate the selected settings.
Light indicates the unit
is in temperature or
delay time Set mode.
Light indicates the
delay timer is set.
(on some models)
Air Conditioner Controls

Controls

Power Pad
Turns air conditioner on and off. When
turned on, the display will show the room
temperature.
Display
Shows the room temperature or time
remaining on the Delay timer. Shows the Set
temperature while setting the temperature in
Cool or Energy Saver modes. The Set light will
turn on while setting.
NOTE: The display will change to show the
room temperature after settings have been
made. To recall the Set temperature, press the
Temp Increase L or Decrease M pads.
Temp Increase
Use to set temperature when in Cool or Energy
Saver mode. The Set light will turn on while
setting. Hold down both the up and down
pads for 5 seconds to change the display
between Fahrenheit and Celsius.
Delay Timer Increase L / Decrease M Pads
Each touch of the Increase L / Decrease M
pads on the unit or on the remote control will
set the delay time when using the Delay 1–24hr
timer. The Set light will turn on while setting.
Fan Speed Pad
Use to set the fan speed to Low, Med, High
or Auto on the unit. NOTE: On the remote
control, use the Fan button to set the fan
speeds to Low, Med, High or Auto.
4
NOTE: The display always shows the
room temperature except when setting
the Set temperature or the Delay timer.
/ Decrease Pads
L M
Delay timer and
temperature set
Decrease/Increase
Delay 1–24hr
Mode select
Remote Control
Mode Pad
Use to set the air conditioner to Cool, Energy
Saver or Fan mode.
Delay Pads
Delay ON—When the air conditioner is off, it
can be set to automatically come on in 1 to 24
hours at its previous mode and fan settings.
Delay OFF—When the air conditioner is on,
it can be set to automatically turn off in 1 to
24 hours.
How to set:
Press the Delay 1–24hr pad on the unit or on
the remote control. Each touch of the Increase
L / Decrease M pads on the unit or on the
remote control will set the timer in 1/2-hour
intervals until the time reaches 10 hours; then
it will increase in 1-hour intervals. The Set
light will turn on while setting.
To review the remaining time on the Delay
1–24hr timer, press the Delay 1–24hr pad on
the unit or on the remote control. Use the
Increase L / Decrease M pads on the unit or
on the remote control to set a new time if
desired.
To cancel the timer, press the Delay 1–24hr pad
until the light on the Delay 1–24hr pad goes off.
Unit power on/off
Auto Fan on/off and
Decrease/Increase
