- Page 1 DVI to PC Converter ID# 662 Operation Manual...
- Page 2 Introduction Converts a DVI-D Digital signal input to Analog PC/RGB or HD YPbPr output. It enables you to connect a digital DVI source to an analog PC monitor, projector or TV. Its high bandwidth capability supports a wide range of PC and HDTV resolutions.
- Page 3 Operation Controls and Functions Front Panel 1. DVI input: Connect the DVI-D input port to the DVI output port of your source equipment such as DVD player or set-top-box. It supports only DVI-D signal via a DVI-1 connector. 2. Power: Plug the 5VDC power supply into the unit and connect the adaptor to AC wall outlet.
- Page 4 Connection and Installation Pin Configuration...
- Page 5 Specifications Operation frequency Up to 165MHz Input port 1 x DVI (only DVI-D supported) Input signal Digital RGB or YPbPr bistream Output port 1 x HD-15 D-Sub (RGBHV or YPbPr) Output signal RGB: 0.7Vp-p 75ohm H+V: 3 to 5 Vp-p Or Y: 1 Vp-p 75ohm PB/Pr: 0.7 Vp-p 75ohm Input/Output resolution...
