PC to HDMI 1080p Scaler Box
ID# 612
Operation Manual

Advertisement

loading
Need help?

Need help?

Do you have a question about the 612 and is the answer not in the manual?

Questions and answers

Related Manuals for Converters.TV 612

Summary of Contents for Converters.TV 612

  • Page 1 PC to HDMI 1080p Scaler Box ID# 612 Operation Manual...
  • Page 2 Introduction PC to HDMI 1080p Scaler Box is designed to upscale video from a PC input source to a digital HDMI output at a range of different resolutions up to 1080p/WUXGA. The unit is particularly useful for those who want to display the image from their PC on a high definition TV at a high resolution.
  • Page 3 Operating Functions Controls Front Panel The following sections describe the hardware components of the unit. PC Input: Connect the PC input D-Sub (15-pin) port to the D-Sub output port of your source equipment such like PC. Audio Input: Connect the PC 3.5mm phone jack input port to the analog audio output port of your source equipment.
  • Page 4 Audio Output: Connect the PC 3.5mm phone jack output port to the analog audio input port of your equipment. Menu Button: Press the MENU button to bring up OSD operation menu. (See "OSD Operation" section for reference.) +/- Button: On the first tier of OSD menu, use + and - buttons to move up/down the ●...

  • Page 5: Installation And Connection

    Reset Functionality To reset the unit, press and hold the MENU button then re-plug the DC power into the unit to set the unit back to factory default, with output resolution as NATIVE. This feature is also useful when the output is scaled to a resolution not supported by the connected TV/monitor so no picture is shown, because the NATIVE resolution can guarantee the proper (might not be the best) output.

  • Page 6: Hdmi Output

    Support Resolution PC INPUT HDMI OUTPUT SD/HD 4801/5761 (NTSC/PAL) 480P/576P 720P@(50/60) 10801@(50/60) 1080P@(50/60) VGA@(60/72/75/85) V @60 SVGA@(56/60/72/75/85) V @60 XGA@ (60/70/75/85) V @60 SXGA@(60/75/85) V @60 UXGA@60 WXGA@60(1280x800) WSXGA@60(1680x1050) WUXGA@60(1920x1200) y support@60Hz *VGA/SVGA/XGA/SXGA/output onl...
