Instruction Manual
Bed Frame For Twin Mattress
Model SEMITR-19
Due to the presence of small parts during assembly, keep
out of reach of children until assembly is complete.
Model SEMITR-19 Semi Truck Bed Frame
Read all instructions before assembly and use.
Keep instructions for future use.
ADULT ASSEMBLY REQUIRED
Lancaster, PA 17601
tradecraftspecialties@gmail.com
www.tradecraftspecialties.com
Revised 01/02/2016
1900 Alfa Drive
(717) 269-8934
Page
1 of 7
Advertisement
Table of Contents
Related Manuals for Tradecraft Specialties SEMITR-19
Summary of Contents for Tradecraft Specialties SEMITR-19
- Page 1 Due to the presence of small parts during assembly, keep out of reach of children until assembly is complete. 1900 Alfa Drive Lancaster, PA 17601 (717) 269-8934 tradecraftspecialties@gmail.com www.tradecraftspecialties.com Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 1 of 7...
- Page 2 Excess space may result in entrapment which may lead to serious injury or death. General Specifications Assembled dimensions (approximate): 89" long, 39.5" wide, 24" high. Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 2 of 7...
- Page 3 The smell should completely dissipate within several days. The smell may be stronger on products with areas of exposed unpainted material. Disassembly To disassemble, reverse order of steps for assembly. Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 3 of 7...
- Page 4 Parts List Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 4 of 7...
- Page 5 Step 2 - A: Loosely fasten side assemblies [A] to rear shelf support [G] using lag bolts [E] and flat washers [F], (1) lag bolt per side with a washer on each lag bolt. Do not yet fully tighten lag bolts. Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 5 of 7...
- Page 6 (1) screw at each end of support bar. Make sure support bar end is tight and perpendicular with side of bed. Start at rear of bed and work towards front. Leave 4.5” gaps between each support bar (approximately 7” center-to-center). Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 6 of 7...
- Page 7 Step 4: Tighten all hardware. Make sure all assembled parts are tight and secure. Page Model SEMITR-19 Semi Truck Bed Frame Revised 01/02/2016 7 of 7...
