K109UI
General Description
The K109UI instrument is a V - mA converter with 3-point galvanic insulation designed
for industrial standard voltage or current signals with passive input and active output.
Analogue/digital conversion takes place at 14 bit on every input range.
The instrument also provides the following functions:
Rejection programmable for 50 or 60 Hz mains frequency.
Additional reading stabilisation filter.
Inversion of the input and inverted output scales
Input Out-of-Range programmable to 2.5% or 5.0%
SQRT function.
Linearisation for horizontal cylindrical tanks.
The module is also characterised by its extremely compact size, coupling to 35 mm DIN
driver, power supply available by bus, quick fit couplings by spring-type terminals, 3-
point insulation, onsite configuration by DIP-switch.
Technical Features
Power supply :
Consumption :
Voltage input (max. 50 V) :
Voltage input (max. 30 V) :
Current input (max. 24 V) :
Permissible max. Input Out-of-
Range :
Voltage output :
Current output :
Maximum applied Voltage :
Permissible max. Output Out-of-
Range:
Current output protection :
Processing :
ADC :
V - mA CONVERTER
WITH 3-POINT GALVANIC INSULATION
19,2 - 30 Vdc
Max 22 mA at 24 Vdc ( 20 mA output )
0 - 15 V, 0 - 30 V, Input Impedance: 325 k
0 - 10 V, 2 - 10 V, 0 - 5 V, 1 - 5 V,
Input Impedance: 110 k
0 - 20 mA, 4 - 20 mA, Input Impedance: 35
± 2,5 or ± 5% depending on setting (see section on
Input Out-of-Range Limits)
0 - 5 Vdc, 1 - 5 Vdc, 0 - 10 Vdc and 10 - 0 Vdc
Minima load resistance: 2 K
0 - 20 mA, 4 - 20 mA, 20 - 0 mA e 20 - 4 mA
Maximum load resistance: 500
± 30 V
Fixed (see section on Output Out-of-Range Limits)
approximately 25 mA
Digital, 32 bit floating-point calculation
14 bit on every input range
MI00096 -E 3 ENGLISH - 1/8
