- Page 1 BNC04124B v.1.0 BNC 13,8V/4x1A/7Ah Switch mode buffer power supply unit for CCTV. Edition: 1 from 26.11.2013 Supersedes the edition: ------...
-
Page 2: Table Of Contents
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B PSU features: • • DC 13,8V/4x1A uninterruptible power supply Voltage control at the AUX1 ÷ AUX8 outputs • • battery housing for one 7Ah/12V battery FPS technical output – indication of the • output fuse activation– relay and OC type wide range of supply voltage: 176÷264V AC... -
Page 3: Block Diagram
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B 1.2. Block diagram. Figure 1. Block diagram of the PSU. 1.3. The description of components and connectors of the PSU. Table 1. Component No. Description [Figure 2] LED optical indication: green L – indication of voltage at the IN input... - Page 4 GREEN POWER CCTV BNC www.pulsar.pl BNC04124B Figure 2. Components arrangement. Figure 3. The view of the PSU. Component No. Description [Figure 3] The module of the switch mode PSU LED light indicating correct operation of the switch mode PSU ADJ potentiometer – regulation of the power supply output voltage...
-
Page 5: Technical Parameters
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B TAMPER – microswitch (contacts) of antisabotage protection (NC) Connectors for connecting the batteries: +BAT = red, - BAT = black Table 2. Components of the PSU (see Figure 3). 1.4. Technical parameters. - electrical parameters (Table 3) -
Page 6: Installation
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B Safety of use (Table 5). Protection class PN-EN 60950-1:2004 I (first) Protection grade PN-EN 60529: 2002 (U) IP20 Insulation electrical strength: - between input (network) circuit and the output circuits of the PSU (I/P-O/P) 3000 V/AC min. -
Page 7: Power Supply Operation Indication
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B - connect the video signals from the cameras and the DVR to the BNC sockets Figure 4. Connecting the camera and DVR to the BNC module. 5. Use the F1/PTC1 ÷ F4/PTC4 jumpers to select the type of short circuit / overload protection of individual circuits. -
Page 8: Technical Outputs
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B RED LED: • on – The PSU supplied with 230V AC voltage • off – no 230V AC mains supply RED LED: • on – DC voltage at the output of the switch mode PSU •... -
Page 9: Service And Operation
GREEN POWER CCTV BNC www.pulsar.pl BNC04124B • TAMPER – output indicating enclosure opening: - volt free contact input indicating the status of the power supply doors, PSU closed: contacts closed (NC), PSU open: contacts open (NO). 4. Service and operation. - Page 10 GENERAL WARRANTY CONDITIONS 1. Pulsar K. Bogusz Sp.j. (manufacturer) grants a two-year quality warranty for the equipment, starting from the production date. The warranty includes free-of-charge repair or replacement with an appropriate equivalent (selected by the manufacturer) if the malfunction is due to the manufacturer.
