spEcIfIcATIons

Magnification ............................................... 8x
Intensifier tube ............................................ Gen. 2 or Gen.3
Field of view ................................................ 6.5°
Range of Focus ........................................... 20 m to infinity
Power Supply .............................................. 3 volt, lithium
Battery life (CR123a type) ......................... 50 hours
Operating Temperature .............................. -40°C to +50°C
Storage Temperature ................................. -50°C to +70°C
Dimensions ................................................. 212 x 150 x 133 mm (8.4" x 6" x 5.3")
Weight ......................................................... 1.7 kg (3.75 lbs)
* aTn reserves the right to change the above specifications at any time without notice
fEATUREs
• Available IITs: 2+, CGT, HPT, WPT™, 3 and 3A
• Multi-coated all-glass optics
• Detachable Long Range Infrared Illuminator
• Built-in Flood Infrared Illuminator
• Adjustable Interpupillary Distance
• Rugged and versatile design
• Water and fog resistant
• Tripod Mountable
• Easy to use digital controls
• Limited Two-Year Warranty
ApplIcATIon
The nVB8X is a powerful long rang night vision bi-ocular. Incredible 8x magnification pro-
vides the user high resolution and clarity over extended ranges. They are waterproof and
can withstand the rigors of almost any environment. The nVB8X will give you the range
and clarity that other bi-oculars simply can not touch.
The nVB8X is available with a wide range of image intensifier options to meet a wide array
of specification requirements.
The nVB8X is a complex opticoelectronic system for individual use. The device con-
sists of the objective lens assembly, eyepiece and the body. The body contains a image
intensifier tube assembly with an integrated high voltage power source and the battery
housing.
Objective lens protective cover (not shown) is intended to protect the objective lens from
dust and scratches. It also will act as a daylight filter, allowing you to test the scope in day-
light or other bright light situations. The pinhole in the center of the protective cover allows
the user to check the operation ability of the device in daylight conditions.
NOTE: Do not test the scope in daylight conditions even with the daylight filter/lens cap on
for more than ten (10) minutes.
