INSTALLER: LEAVE THIS MANUAL WITH THE APPLIANCE.
CONSUMER: RETAIN THIS MANUAL FOR FUTURE REFERENCE.
NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE.
CERTIFIED TO CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.22 AND ANSI Z21.50 FOR VENTED GAS FIREPLACES.
FOR INDOOR USE ONLY
SAFETY INFORMATION
WARNING
!
If the information in these instructions
are not followed exactly, a fire or
explosion may result causing property
damage, personal injury or loss of life.
- Do not store or use gasoline or other flammable
vapors and liquids in the vicinity of this or any
other appliance.
- WHAT TO DO IF YOU SMELL GAS:
•
Do not try to light any appliance.
•
Do not touch any electrical switch; do not use
any phone in your building.
•
Immediately call your gas supplier from a
neighbour‟s phone. Follow the gas supplier‟s
instructions.
•
If you cannot reach your gas supplier, call the
fire department.
- Installation and service must be performed by a
qualified installer, service agency or the supplier.
This appliance may be installed in an
aftermarket, permanently located, manufactured
home (USA only) or mobile home, where not
prohibited by local codes.
This appliance is only for use with the type of
gas indicated on the rating plate. This appliance
is not convertible for use with other gases,
unless a certified kit is used.
Phone (705)721-1212 • Fax (705)720-9081 • www.continentalfireplaces.com • ask@continentalfire.on.ca
$10.00
INSTALLATION AND
OPERATING INSTRUCTIONS
Wolf Steel Ltd., 24 Napoleon Rd., Barrie, ON, L4M 0G8 Canada /
103 Miller Drive, Crittenden, Kentucky, USA, 41030
CBHD4N
NATURAL GAS
CBHD4P
PROPANE
DANGER
!
DO NOT TOUCH GLASS UNTIL
NEVER ALLOW CHILDREN TO
A barrier designed to reduce the risk of burns from
the hot viewing glass is provided with this appliance
and shall be installed for the protection of children
and other at-risk individuals.
HOT GLASS WILL CAUSE
BURNS.
COOLED.
TOUCH GLASS.
CE RT IFIE D
1.8F
W415-1283 / E / 12.21.16
EN
FR
PG
65
Advertisement
Table of Contents
Related Manuals for Continental Fireplaces CBHD4N
Summary of Contents for Continental Fireplaces CBHD4N
- Page 1 NEVER LEAVE CHILDREN OR OTHER AT RISK INDIVIDUALS ALONE WITH THE APPLIANCE. INSTALLATION AND OPERATING INSTRUCTIONS CERTIFIED TO CANADIAN AND AMERICAN NATIONAL STANDARDS: CSA 2.22 AND ANSI Z21.50 FOR VENTED GAS FIREPLACES. CBHD4N NATURAL GAS FOR INDOOR USE ONLY CBHD4P...
-
Page 2: Table Of Contents
TABLE OF CONTENTS The camera icon indicates video tutorials are available as additional reference, visit http://mynapoleon.napoleonproducts.com/download/index/44/1 INSTALLATION OVERVIEW INTRODUCTION DIMENSIONS GENERAL INSTRUCTIONS GENERAL INFORMATION RATING PLATE / LIGHTING INSTRUCTION LOCATION VENTING VENTING LENGTHS AND COMPONENTS TYPICAL VENT INSTALLATIONS SPECIAL VENT INSTALLATIONS PERISCOPE TERMINATION REDUCED VENT CLEARANCE TO COMBUSTIBLES CONVERTING FROM 5/8"... -
Page 3: 1.0 Installation Overview
REPLACEMENTS CBHD4P OVERVIEW CBHD4ST OVERVIEW GLASS BURNER ASSEMBLY GLASS BURNER VALVE TRAIN ASSEMBLY LOG BURNER ASSEMBLY LOG BURNER VALVE TRAIN ASSEMBLY 12.0 ACCESSORIES 13.0 TROUBLESHOOTING 14.0 WARRANTY NOTE: Changes, other than editorial, are denoted by a vertical line in the margin. 1.0 INSTALLATION OVERVIEW COMBUSTIBLE MATERIAL Framing, see... -
Page 4: Introduction
INTRODUCTION WARNING • THIS APPLIANCE IS HOT WHEN OPERATED AND CAN CAUSE SEVERE BURNS IF CONTACTED. • ANY CHANGES OR ALTERATIONS TO THIS APPLIANCE OR ITS CONTROLS CAN BE DANGEROUS AND IS PROHIBITED. • Do not operate appliance before reading and understanding operating instructions. Failure to operate appliance according to operating instructions could cause fire or injury. -
Page 5: Dimensions
DIMENSIONS 25 1/8" 638mm 8" 203mm 5" 12 13/16" 325mm 127mm RIGHT LEFT 34 3/16" SIDE SIDE SAFETY BARRIER 868mm 38 1/4" 841mm 2 1/16" 53mm 43 1/4" 1099mm 7 9/16" 7 9/16" 192mm 192mm GAS INLET CBHD4P ELECTRIC BHD4P ILLUSTRATED ILLUSTRATED AL INLET 8"... -
Page 6: General Instructions
GENERAL INSTRUCTIONS WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT, WITH THE GLASS DOOR OPENED OR REMOVED. PROVIDE ADEQUATE CLEARANCE FOR SERVICING AND OPERATING THE APPLIANCE. PROVIDE ADEQUATE VENTILATION. NEVER OBSTRUCT THE FRONT OPENING OF THE APPLIANCE. OBJECTS PLACED IN FRONT OF THE APPLIANCE MUST BE KEPT A MINIMUM OF 48 INCHES (121.9cm) FROM THE FRONT FACE OF THE APPLIANCE. -
Page 7: General Information
GENERAL INFORMATION FOR YOUR SATISFACTION, THIS APPLIANCE HAS BEEN TEST-FIRED TO ASSURE ITS OPERATION AND QUALITY! CBHD4 Altitude (FT) 0-4,500 0-4500 Max. Input (BTU/HR) 30,000 30,000 Max. Output Steady State (BTU/HR) 23,000 23,000 4.5" (11mb) 11" (27mb) Min. Inlet Gas Supply Pressure Water Column Water Column 13"... -
Page 8: Rating Plate / Lighting Instruction Location
PROPANE MODÈLE GAZ NATUREL FILTRES D'AIR. NOT FOR USE WITH SOLID FUEL. UN COMBUSTIBLE SOLIDE NE PAS FOR USE WITH GLASS DOORS BHD4N CBHD4N CBHD4P BHD4P CERTIFIED WITH THIS APPLIANCE ÊTRÉ UTILISÉ AVEC CET APPAREIL. UTILISER AVEC LES PORTE VITRÉES ONLY. -
Page 9: Venting
VENTING WARNING RISK OF FIRE, MAINTAIN SPECIFIED AIR SPACE CLEARANCES TO VENT PIPE AND APPLIANCE. IF VENTING IS INCLUDED WITH SPACERS THE VENT SYSTEM MUST BE SUPPORTED EVERY 3FT (0.9m) FOR BOTH VERTICAL AND HORIZONTAL RUNS. USE SUPPORTS OR EQUIVALENT NON-COMBUSTIBLE STRAPPING TO MAINTAIN THE REQUIRED CLEARANCE FROM COMBUSTIBLES. -
Page 10: Venting Lengths And Components
VENTING LENGTHS AND COMPONENTS Use only Wolf Steel, Simpson Dura-Vent, Selkirk Direct Temp, American Metal Amerivent or Metal-Fab venting components. Minimum and maximum vent lengths, for both horizontal and vertical installations, clearances from vent pipes to combustibles and air terminal locations as set out in this manual apply to all vent systems and must be adhered to. -
Page 11: Typical Vent Installations
TYPICAL VENT INSTALLATIONS 16" MIN (40.6cm) 40 FT (12m) 36" (91.4cm) 24" (61cm) 38 1/4" 43" (109.2c (97.2cm) MIN PLU RISE* When venting, the horizontal run must be kept to a When terminating vertically, the vertical rise is a maximum of 20 feet (6m). If a 20 foot (6m) horizontal minimum 36"... -
Page 12: Special Vent Installations
SPECIAL VENT INSTALLATIONS PERISCOPE TERMINATION Use the periscope kit to locate the air termination above grade. The periscope must be installed so that when final grading is completed, the bottom air slot is located a 12" minimum of 12” (304.8mm) above grade. The maximum allowable vent length (30.5cm) is 10’... -
Page 13: Converting From 5/8" To 4/7" Venting
CONVERTING FROM 5/8" TO 4/7" VENTING USE MILL PAC TO SEAL ADAPTER TO THE APPLIANCE COLLARS. USE MILL PAC TO SEAL ADAPTER TO THE APPLIANCE COLLARS. USE MILL PAC TO SEAL ADAPTER TO THE APPLIANCE COLLARS. W415-1283 / E / 12.21.16... -
Page 14: Vent Terminal Clearances
VENT TERMINAL CLEARANCES COVERED BALCONY APPLICATIONS ††* ≤ 15 feet = 3 feet = 2 x ACTUAL (0.9m) (4.6m) INSTALLATIONS CANADA U.S.A. 12” (30.5cm) 12” (30.5cm) Clearance above grade, veranda porch, deck or balcony. 12” (30.5cm) 9” (229mm) Δ Clearance to windows or doors that open. 12”... -
Page 15: Vent Application Flow Chart
VENT APPLICATION FLOW CHART TOP EXIT Horizontal Termination Vertical Termination Vertical rise is equal Vertical rise is equal Vertical rise is less Vertical rise is less to or greater than to or greater than than horizontal run than horizontal run the horizontal run the horizontal run Horizontal run +... -
Page 16: Horizontal Termination
HORIZONTAL TERMINATION ) < (V Simple venting configuration (only one 45° and 90° elbow) See graph to determine the required vertical rise V for the required horizontal run H 40 (12.2) 39 (11.9) 30 (9.1) REQUIRED VERTICAL 20 (6.1) RISE IN FEET (METERS) V 10 (3.1) 12.5... - Page 17 ) > (V Simple venting configuration (only one 45° and 90° See graph to determine the required vertical elbow) rise V for the required horizontal run H 150 (3810) 147 (3733.8) REQUIRED VERTICAL RISE 100 (2540) IN INCHES (MILLIMETERS) V 57 (1447.8) 50 (1270) (1.5)
-
Page 18: Vertical Termination
VERTICAL TERMINATION ) < (V Simple venting configurations. See graph to determine the required vertical rise V for the required horizontal run H 40 (12.2) 30 (9.1) REQUIRED VERTICAL 20 (6.1) RISE IN FEET (METERS) V 10 (3.1) 3 (0.9) (1.5) (3.1) (6.1) - Page 19 ) > (V Simple venting configurations. See graph to determine the required vertical rise V for the required horizontal run H 20 (6.1) 19 (5.8) REQUIRED VERTICAL RISE IN FEET (3.1) (METERS) V 3 (0.9) (1.5) (3.1) (4.6) (6.1) (7.6) (9.1) HORIZONTAL VENT RUN PLUS OFFSET IN FEET (METERS)H The shaded area within the lines represents acceptable...
-
Page 20: Installation
INSTALLATION WARNING ENSURE TO UNPACK ALL LOOSE MATERIALS FROM INSIDE THE FIREBOX PRIOR TO HOOKING UP THE GAS AND ELECTRICAL SUPPLY. IF YOUR APPLIANCE IS SUPPLIED WITH A REMOTE, ENSURE THE REMOTE RECEIVER IS IN THE “OFF” POSITION PRIOR TO HOOKING UP THE GAS AND ELECTRICAL SUPPLY TO THE APPLIANCE. FOR SAFE AND PROPER OPERATION OF THE APPLIANCE, FOLLOW THE VENTING INSTRUCTIONS EXACTLY. -
Page 21: Horizontal Installation
HORIZONTAL INSTALLATION WARNING THE FIRESTOP ASSEMBLY MUST BE INSTALLED WITH THE VENT SHIELD TO THE TOP. TERMINALS MUST NOT BE RECESSED INTO A WALL OR SIDING MORE THAN THE DEPTH OF THE RETURN FLANGE OF THE MOUNTING PLATE. This application occurs when venting through an exterior wall. Having determined the correct height for the air terminal VENT location, cut and frame a hole in the exterior wall as... - Page 22 ound the pipe. COLLAR VENT PIPE SHIELD 21.1B W415-1283 / E / 12.21.16...
-
Page 24: Using Flexible Vent Components
USING FLEXIBLE VENT COMPONENTS WARNING DO NOT ALLOW THE INNER FLEX PIPE TO BUNCH UP ON HORIZONTAL OR VERTICAL RUNS AND ELBOWS. KEEP IT PULLED TIGHT. SPACERS ARE ATTACHED TO THE INNER FLEX PIPE AT PREDETERMINED INTERVALS TO MAINTAIN AN EVEN AIR GAP TO THE OUTER FLEX PIPE. -
Page 25: Horizontal Air Terminal Installation
HORIZONTAL AIR TERMINAL INSTALLATION Stretch the inner flex pipe to the required length taking into account the additional length needed for the finished wall surface. Apply a heavy bead of the Mill Pac sealant CAULKING (W573-0007) (not supplied) to the inner sleeve of the air terminal. -
Page 26: Vertical Air Terminal Installation
VERTICAL AIR TERMINAL INSTALLATION WARNING MAINTAIN A MINIMUM 2” (51mm) SPACE BETWEEN THE AIR INLET BASE AND THE STORM COLLAR. CONNECTOR Remove nails from the shingles, above and to the sides of the air terminal connector. Place the flashing over the air terminal connector MILL PAC leaving a min. -
Page 27: Gas Installation
GAS INSTALLATION WARNING RISK OF FIRE, EXPLOSION OR ASPHYXIATION. ENSURE THERE ARE NO IGNITION SOURCES SUCH AS SPARKS OR OPEN FLAMES. SUPPORT GAS CONTROL WHEN ATTACHING GAS SUPPLY PIPE TO PREVENT DAMAGING GAS LINE. ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT WITH THE GLASS DOOR OPENED OR REMOVED. -
Page 28: Access Panel For Gas Line Connection
ACCESS PANEL FOR GAS LINE CONNECTION Remove the screen and door from the appliance, see "SIDE SCREEN REMOVAL / DOOR REMOVAL" section. Remove media and media tray from the appliance, see "CRADLE BURNER REMOVAL" section. Unscrew the 2 screws that hold the access panel to the firebox. Remove the gasket (careful not to tear). -
Page 29: Framing
FRAMING When using optional finishing accessories, the framing dimensions and finishing materials may differ from what is outlined in the section below; refer to the leaflet instructions supplied in the accessory kit for specific framing and finishing specifications. WARNING RISK OF FIRE! IN ORDER TO AVOID THE POSSIBILITY OF EXPOSED INSULATION OR VAPOUR BARRIER COMING IN CONTACT WITH THE APPLIANCE BODY, IT IS RECOMMENDED THAT THE WALLS OF THE APPLIANCE ENCLOSURE BE “FINISHED”... -
Page 30: Framing
FRAMING 5.1.1 SEE-THRU FRAMING (CBHD4ST) A: MIN 22 1/8" (56.2cm) 46 1/2" MAX 24 1/8" (61.3cm) [118cm] 45 1/2" [115.6cm] 5.1.2 PENINSULA FRAMING (CBHD4P) A: MIN 22 1/8" (56.2cm) MAX 24 1/8" (61.3cm) 46 1/2" [118cm] B: MIN 42 1/2" (108cm) MAX 43 1/2"... -
Page 31: Minimum Clearance To Combustible Enclosures
MINIMUM CLEARANCE TO COMBUSTIBLE ENCLOSURES IMPORTANT: This appliance requires a minimum inside enclosure height of 50" (127cm), measured from the bottom of the appliance. For temperature requirements, this area must be left unobstructed. NOTE: THIS APPLIANCE IS NOT LOAD BEARING. IMPORTANT: The firestop assembly provided must be used when the vent pipes pass through any walls or are terminated horizontally. -
Page 32: Installing Combustible Board
INSTALLING COMBUSTIBLE BOARD WARNING THE SURFACE ABOVE THE APPLIANCE GETS VERY HOT. IF PROPER FINISHING MATERIALS ARE NOT USED, CRACKING CAN OCCUR. CBHD4ST CBHD4P SIDE WALL 38 1/4" (97.2cm) 38 1/4" 6” (152mm) 43 1/4" 45" (97.2cm) MIN. TO A (109.9cm) (114.3cm) SIDE WALL... -
Page 33: Finishing Support Adjustment
FINISHING SUPPORT ADJUSTMENT Depending on the finishing material we have allowed from 0" (0mm) to 1" (25mm) of adjustment after the 1/2" (13mm) combustible board has been installed. Loosen the 8 screws on each finishing support. Adjust the finishing support to the desired position. NOTE: Peninsula models have one end support that can also be adjusted by loosening the two screws. -
Page 34: Non-Combustible Facing Material
NON-COMBUSTIBLE FACING MATERIAL WARNING: Non-combustible facing material must not project more than 4” (101.6mm) from the face of the door (all four sides). If greater projections are desired, increase the clearance to the sides and top by 2” (50.8mm) for every additional 1” (25.4mm) of projection. If using an optional surround, the same rule applies, starting from the top of the surround. -
Page 35: Alcove Enclosure
ALCOVE ENCLOSURE RECESS OR ALCOVE AREA ENCLOSURE AREA APPLIANCE NOTE: Recesses or alcoves above the appliance can be made as deep as desired provided the minimum clearances to combustibles are maintained. Non-combustible material can be used, provided the minimum clearances to combustible materials are applied The minimum enclosure volume must be increased by no less than the volume of the recess. -
Page 36: Nailing Tab Installation
NAILING TAB INSTALLATION Nailing tabs are provided as part of the frames, as shown. To determine the final location and where to bend the nailing tabs you must first determine the thickness of your finishing material (i.e. drywall). This will determine the dimension from the NAILING front edge of the corner post to the nailing tab. -
Page 37: End Safety Screen Removal / Installation (Bhd4P Only)
END SAFETY SCREEN REMOVAL / INSTALLATION (BHD4P ONLY) NOTE: One of the main safety screens must be removed prior to end screen removal, see "MAIN SAFETY SCREEN REMOVAL / INSTALLATION" section. Remove the 4 securing screws from the top and bottom of the end screen retainer, refer to Figure 1. Pull the safety screen forward and out from the appliance, refer to Figure 2. -
Page 38: Main Door Removal / Installation
MAIN DOOR REMOVAL / INSTALLATION WARNING GLASS MAY BE HOT, DO NOT TOUCH GLASS UNTIL COOLED. IF EQUIPPED WITH DOOR LATCHES THAT ARE PART OF A SAFETY RELIEF SYSTEM, THEY MUST BE PROPERLY ENGAGED. DO NOT OPERATE THE APPLIANCE WITH LATCHES DISENGAGED. FACING AND/OR FINISHING MATERIALS MUST NOT INTERFERE WITH AIR FLOW THROUGH AIR OPENINGS, LOUVRE OPENINGS, OPERATION OF LOUVRES OR DOORS OR ACCESS FOR SERVICE. -
Page 39: End Door Removal / Installation (Cbhd4P Only)
END DOOR REMOVAL / INSTALLATION (CBHD4P ONLY) NOTE: One of the main safety screens and doors must be removed prior to end door removal, see "MAIN SAFETY SCREEN REMOVAL/INSTALLATION" and "MAIN DOOR REMOVAL / INSTALLATION" sections for detailed removal instructions. Remove the 6 screws securing the end door in place, as shown below. -
Page 40: Log Placement
LOG PLACEMENT WARNING FAILURE TO POSITION THE LOGS IN ACCORDANCE WITH THESE DIAGRAMS OR FAILURE TO USE ONLY LOGS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. LOGS MUST BE PLACED IN THEIR EXACT LOCATION IN THE APPLIANCE. DO NOT MODIFY THE PROPER LOG POSITIONS, SINCE APPLIANCE MAY NOT FUNCTION PROPERLY AND DELAYED IGNITION MAY OCCUR. -
Page 41: Glowing Embers
Place log #7 onto the pin located in log #6 and onto the pin in log #5, Fig. 7 as shown in Figure 7. Place log #8 on the log support and let it rest against the notch in the side of log #7, as shown in Figure 8. -
Page 42: Charcoal Embers
CHARCOAL EMBERS WARNING DO NOT BLOCK THE BURNER PORTS. BLOCKED PORTS CAN CAUSE AN INCORRECT FLAME PATTERN, CARBON DEPOSITS AND DELAYED IGNITION. Randomly place the charcoal embers along the front and sides of the log support tray in a realistic manner. Fine dust found in the bottom of the bag should not be used. -
Page 43: Logo Placement
LOGO PLACEMENT 1/2” LOGO (13mm) 1/2” (13mm) WIRING DIAGRAM RECEPTACLE WIRING DIAGRAM CABLE CONNECTOR (BLACK) ELECTRICAL GROUND (GREEN) (WHITE) 3 PRONG WIRE RECEPTACLE NUTS NOTE: Ensure that the transformer is plugged into the receptacle. ELECTRONIC WIRING DIAGRAM WARNING DO NOT USE THIS APPLIANCE IF ANY PART HAS BEEN UNDER WATER. CALL A QUALIFIED SERVICE TECHNICIAN IMMEDIATELY TO HAVE THE APPLIANCE INSPECTED FOR DAMAGE TO THE ELECTRICAL CIRCUIT. -
Page 44: Wiring Requirements
WIRING REQUIREMENTS It is necessary to hard wire this appliance. Permanently framing the appliance with an enclosure, requires the appliance junction box to be hard wired. This appliance must be electrically connected and grounded in accordance with local codes. In the absence of local codes, use the current CSA C22.1 Canadian electrical code in Canada or the ANSI/NFPA national electrical code in the United States. -
Page 45: Battery Back-Up Installation
BATTERY BACK-UP INSTALLATION NOTE: In the event of a power failure, your appliance can be operated using the battery back-up supplied. A. Remove the safety screen and door, refer to the "MAIN SAFETY SCREEN REMOVAL/INSTALLATION" and "MAIN DOOR REMOVAL/INSTALLATION" sections for detailed removal instructions. B. -
Page 46: Operating Instructions
OPERATING INSTRUCTIONS When lit for the first time, the appliance will emit a slight odour for a few hours. This is a normal temporary condition caused by the “burn-in” of internal paints and lubricants used in the manufacturing process and will not occur again. -
Page 47: Anti Condensation Switch
ANTI CONDENSATION SWITCH NOTE: Side safety screen must be removed before accessing the anti-condensation switch, see "SIDE SAFETY SCREEN REMOVAL / INSTALLATION" section for detailed removal instructions. This appliance has the ability to switch from an electronic intermittent pilot ignition (IPI) to a standing pilot (ACS) for cold climates. -
Page 48: 9.0 Adjustment
9.0 ADJUSTMENT PILOT BURNER ADJUSTMENT Adjust the pilot screw to provide properly sized flame. Turn in a clockwise direction to reduce the gas flow. Check Pressure Readings: Inlet pressure can be checked by turning screw (A) counter- clockwise 2 or 3 turns and then placing pressure gauge tubing over the test point. -
Page 49: Flame Characteristics
FLAME CHARACTERISTICS FLAME SENSOR It is important to periodically perform a visual check of the pilot PILOT ELECTRODE 3/8” - 1/2” and burner flames. Compare them to the illustration provided. If BURNER PILOT (9.5mm - ” ” any flames appear abnormal, call a service person. BURNER (9.5mm - 12.7mm) ELECTRO... -
Page 50: Maintenance
MAINTENANCE WARNING TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. DO NOT PAINT THE PILOT ASSEMBLY. This appliance and its venting system should be inspected before use and at least annually by a qualified service person. -
Page 51: Glass / Door Replacement
10.1 ANNUAL MAINTENANCE WARNING THE FIREBOX BECOMES VERY HOT DURING OPERATION. LET THE APPLIANCE COOL COMPLETELY OR WEAR HEAT RESISTANT GLOVES BEFORE CONDUCTING SERVICE. NEVER VACUUM HOT EMBERS. DO NOT PAINT THE PILOT ASSEMBLY. • This appliance will require maintenance which should be planned on an annual basis. •... -
Page 52: Care Of Glass
CARE OF GLASS WARNING DO NOT CLEAN GLASS WHEN HOT! DO NOT USE ABRASIVE CLEANERS TO CLEAN GLASS. HOT GLASS WILL Buff lightly with a clean dry soft cloth to remove accumulated CAUSE BURNS. dust or fingerprints. Clean both sides of the glass after the DO NOT TOUCH GLASS first 10 hours of operation with a recommended fireplace UNTIL COOLED. -
Page 53: Burner Removal
10.5 BURNER REMOVAL LOG BURNER REMOVAL Remove the main door(s) from the appliance see "MAIN DOOR REMOVAL/INSTALLATION" section for detailed removal instructions. Carefully remove the charcoal embers, charcoal lumps, glowing embers and logs from the appliance. Remove the log support from the appliance by lifting it up and out. Remove the 4 screws securing the burner in place. -
Page 54: Valve Train Replacement
VALVE TRAIN REPLACEMENT Remove the safety screen and main door(s). See "MAIN SAFETY SCREEN REMOVAL/INSTALLATION" and "MAIN DOOR REMOVAL/INSTALLATION sections for detailed removal instructions. Remove the burners, see "BURNER REMOVAL" section. Remove the 12 screws holding the valve train in place, as shown below. NOTE: A new gasket may be required when reinstalling the valve train assembly. -
Page 55: Replacements
REPLACEMENTS WARNING FAILURE TO POSITION THE PARTS IN ACCORDANCE WITH THIS MANUAL OR FAILURE TO USE ONLY PARTS SPECIFICALLY APPROVED WITH THIS APPLIANCE MAY RESULT IN PROPERTY DAMAGE OR PERSONAL INJURY. ** THIS IS A FAST ACTING THERMOCOUPLE. IT IS AN INTEGRAL SAFETY COMPONENT. REPLACE ONLY WITH A FAST ACTING THERMOCOUPLE SUPPLIED BY WOLF STEEL LTD. -
Page 56: Cbhd4P Overview
CBHD4P OVERVIEW SAFETY SCREEN SAFETY SCREEN FOR REPLACEMENTS PARTS REFER FOR REPLACEMENTS PARTS SAFETY SCREEN TO: "LOG BURNER" REFER TO: "GLASS BURNER" FOR REPLACEMENTS PARTS REFER TO: FOR REPLACEMENTS PARTS REFER TO: "LOG BURNER VALVE TRAIN ASSEMBLY" "GLASS BURNER VALVE TRAIN ASSEMBLY" ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED REF. -
Page 57: Cbhd4St Overview
CBHD4ST OVERVIEW SAFETY SCREEN SAFETY SCREEN FOR REPLACEMENTS PARTS REFER FOR REPLACEMENTS PARTS TO: "LOG BURNER" REFER TO: "GLASS BURNER" FOR REPLACEMENTS PARTS REFER TO: FOR REPLACEMENTS PARTS REFER TO: 15 16 17 "LOG BURNER VALVE TRAIN ASSEMBLY" "GLASS BURNER VALVE TRAIN ASSEMBLY" ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED REF. -
Page 58: Glass Burner Assembly
GLASS BURNER ASSEMBLY ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED REF. NO. PART NUMBER DESCRIPTION STOCKED W010-2954-SER BURNER ASSEMBLY W080-1400-SER BURNER BRACKET W290-0018 VENTURI GASKET W720-0005 VENTURI... -
Page 59: Glass Burner Valve Train Assembly
GLASS BURNER VALVE TRAIN ASSEMBLY 1 1 1 0 1 1 1 2 1 1 2 3 1 1 3 4 1 1 3 5 1 1 6 3 ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED REF. NO. PART NUMBER DESCRIPTION STOCKED REF. -
Page 60: Log Burner Assembly
LOG BURNER ASSEMBLY ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED PART NUMBER DESCRIPTION STOCKED PART NUMBER DESCRIPTION STOCKED REF. NO. REF. NO. W010-2955 BURNER ASSEMBLY W720-0005 VENTURI W080-1463 BURNER BRACKET W080-1399 BURNER BRACKET W290-0018 VENTURI GASKET... -
Page 61: Log Burner Valve Train Assembly
LOG BURNER VALVE TRAIN ASSEMBLY 1 1 1 0 1 1 1 2 1 1 3 2 1 1 3 4 1 1 5 2 1 1 3 6 ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED REF. NO. PART NUMBER DESCRIPTION STOCKED REF. -
Page 62: Accessories
12.0 ACCESSORIES FRONT SIDE VIEW REAR SIDE VIEW PRPHD4 GD851KT GL-688 ITEMS MAY NOT APPEAR EXACTLY AS ILLUSTRATED REF. NO. PART NUMBER DESCRIPTION STOCKED REF. NO. PART NUMBER DESCRIPTION STOCKED LDAC DESIGNER FIRE ART COIL DESIGN W135-0530 LOG #4 (GL-688) LDNS DESIGNER FIRE ART NICKEL STIX W135-0531... -
Page 63: Troubleshooting
13.0 TROUBLESHOOTING WARNING ALWAYS LIGHT THE PILOT WHETHER FOR THE FIRST TIME OR IF THE GAS SUPPLY HAS RUN OUT, WITH THE GLASS DOOR OPEN OR REMOVED. TURN OFF THE GAS AND ELECTRICAL POWER BEFORE SERVICING THE APPLIANCE. APPLIANCE MAY BE HOT, DO NOT SERVICE UNTIL APPLIANCE HAS COOLED. DO NOT USE ABRASIVE CLEANERS. - Page 64 SYMPTOM PROBLEM TEST SOLUTION Continues to Short or loose Verify all connections. Verify the connections from the pilot spark and pilot connection in sensor assembly are tight; also verify these connections are not lights, but main rod. grounding out to any metal. burner will not Verify the TH wires are connected to the valve.
-
Page 65: Warranty
14.0 WARRANTY CONTINENTAL® products are manufactured under the strict Standard of the world recognized ISO 9001 : 2008 Quality Assurance Certificate. CONTINENTAL® products are designed with superior components and materials assembled by trained craftsmen who take great pride in their work. The burner and valve assembly are leak and test-fired at a quality test station. The complete appliance is again thoroughly inspected by a qualified technician before packaging to ensure that you, the customer, receives the quality product that you expect from CONTINENTAL®. - Page 67 W415-1283 / E / 12.21.16...
