Technical Specifications - D-Link Web Smart DES-1210-28P Specifications

Technical Specifications
• 24 10/100Mbps
Number of Ports
• 2 10/100/1000BASE-T
• 2 combo 10/100/1000BASE-T/SFP
Port Standards &
• IEEE 802.3 10BASE-T Ethernet (twisted-pair copper)
Functions
• IEEE 802.3ab 1000BASE-T Gigabit Ethernet
(twisted-pair copper)
•
Network Cables
• UTP Cat.5, Cat.5e (100m max)
• EIA/TIA-568 100-ohm STP (100m max)
Full/Half Duplex
• Full/half duplex for 10/100Mbps speeds
• Full duplex for Gigabit speed
Media Interface
Exchange • Auto MDI/MDI-X adjustment for all twisted pair ports
Switching Capacity •
12.8Gbps
Transmission Method • Store-and-forward
MAC Address Table • 8K entries per device
MAC Address Update • Up to 256 static MAC entries
Maximum 64 bytes
• 9.5Mpps
packet forwarding rate
RAM Buffer • 512KB per device
AC Input
• 100 to 240 VAC 50/60 internal universal power supply
Maximum Power
• 17.6W
Consumption
Fan Quantity • 0
Acoustics • 0 dB
Heat Dissipation • 60.05 BTU/hr
Operating Temperature
• 32
Storage Temperature • 14
Operating Humidity • 10% to 95% non-condensing
Emission (EMI) • FCC Class A, CE Class A, VCCI Class A,
b u s i n e s s
DES-1210-28
IEEE 802.3x Flow Control
o o o o
to 104 F (0 to 40 C)
o o o o
to 158 F (-10 to 70 C)
C-Tick
DES-1210-28P
• 24 PoE 10/100Mbps
• 2 10/100/1000BASE-T
• 2 combo 10/100/1000BASE-T/SFP
•
IEEE 802.3u 100BASE-TX Fast Ethernet (twisted-pair copper)
•
IEEE 802.3z Gigabit Ethernet (fiber) ANSI/IEEE 802.3
•
Auto-negotiation
• 12.8Gbps
• Enable/disable auto-learning of MAC addresses
• 9.5 Mpps
• 512KB per device
• 254 N (Power On)
• 26.4 W (Power Off)
• 3 Smart Fans
• 53.9 dB
• 866.65 BTU/hr
•
FCC Class A, CE Class A, VCCI Class A,
C-Tick
D ES -1 2 10 S er ies
DES-1210-52
• 48 10/100Mbps
• 2 10/100/1000BASE-T
• 2 combo 10/100/1000BASE-T/SFP
• 17.6Gbps
• 8K entries per device
• 13.1Mpps
• 1MB per device
• 28.9W
• 0
• 0 dB
• 98.61 BTU/hr
