Before you begin-Read these instructions completely and carefully.
IMPORTANT: Save these instructions for local inspector's use.
IMPORTANT: OBSERVE ALL GOVERNING CODES AND ORDINANCES.
NOTE TO INSTALLER: Be sure to leave these instructions with the
Consumer.
NOTE TO CONSUMER: Keep these instructions with your Use and Care
Book for future reference.
WARNING
CAUTION
If you have questions concerning the
installation of this product, call the GE
Answer Center
Service at 800.626.2000, 24 hours a day,
7 days a week.
If you received a damaged cooktop, you
should contact your dealer.
CAUTION:
• This cooktop should be installed by a
• Do not store items of interest to
• Never use your cooktop for warming or
• The cooktop should be easy to reach
Design Information
Contents
Models Available ................................................................................................................................. 3
Dimensions and Clearances .............................................................................................................. 3
Advance Planning .............................................................................................................................. 3
Installation Preparation
Tools & Materials Required ............................................................................................................... 4
Electrical Location ............................................................................................................................. 4
Base Cabinet Heat Clearances .......................................................................................................... 4
Step 1: Cut the Opening .................................................................................................................... 5
Installation
Step 2: Install Cooktop ...................................................................................................................... 6
Step 3: Install Hold-down Brackets ................................................................................................... 6
Step 4: Connect Electrical ................................................................................................................. 7
This appliance must be properly grounded. See "Electrical Supply", page 4.
®
Consumer Information
qualified installer or service technician.
children in cabinets above the
cooktop. They could be seriously
burned climbing on the cooktop to
reach them.
heating the room. Prolonged use of the
cooktop without adequate ventilation
can be hazardous.
and lighted by natural light during the
day.
Proper installation is the responsibility of the
installer. Product failure due to improper
installation is not covered under the GE
Appliance Warranty. See the Use & Care
Guide for warranty information.
For Monogram local service in your area,
1-800-444-1845.
For Monogram Service in Canada
1-888-880-3030.
For Monogram Parts and Accessories, call
1-800-626-2002.
• Always disconnect the electrical ser vice to
the unit before repairing or ser vicing the
cooktop. Disconnect the fuse or circuit
breaker. Failure to do so could result in a
dangerous or fatal shock. Know where your
main disconnect switch is located.
Check local building codes for the proper
method of cooktop installation. Local codes
vary. Installation, electrical connections and
grounding must comply with applicable
codes. In the absence of local codes, the
cooktop should be installed in accordance
with National Electrical Code ANSI/NFPA
70-1990.
