- Page 1 USER MANUAL TP 80 0...
-
Page 2: Table Of Contents
Contents Hot tub performance specifications Preparation for the installation of the hot tub Preparation of the place for installation and connection to electricity ..Preparation for the interior hot tub installation ....Preparation for the exterior hot tub installation . -
Page 3: Hot Tub Performance Specifications
Hot tub performance specifications For your own safety and the safety of your product, please observe the following instructions Read the following information carefully and follow the user manual exactly when using the hot tub to avoid damaging the product or the risk of injury This appliance is intended for use by children 8 years of age or older with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, provided they are under supervision or have been... -
Page 4: Preparation For The Installation Of The Hot Tub
Preparation for the installation of the hot tub a Type C or Type D circuit breaker with a rated current of 16 A (motor circuit breaker) downstream of the Residual Current protective Device. Recommended Type C circuit breaker Hot tubs with two massage motors: 3×... -
Page 5: Preparation For The Interior Hot Tub Installation
Preparation/Installation of the hot tub Preparation for the interior hot tub installation If the hot tub is installed in an interior space, it is necessary to comply with safety instructions. The basic safety requirements are mainly non-skid floors and drainage in the place of the installation in case of a water overflow. -
Page 6: Filling The Hot Tub With Water
Installation of the hot tub/Audio system Aquatic Filling the hot tub with water Fill the hot tub with a sufficient amount of water. The level of water in the hot tub cannot ever fall under the skimmer level. If you notice a water leak, stop the water until the defect is fixed. -
Page 7: Control Panel
Control panel Control panel (BALBOA TP800) Main displayed data circulation pump and heating water temperature temperature scale 102°F High Range Set: 104 °F 8:32 PM Shortcuts Ozone Settings Filter 1 Ready in Rest Mode Heating messages menu status desired temperature lock indicator Navigation Navigating through the whole menu is done by 5 control panel buttons. -
Page 8: Hot Tub Settings
Control panel Navigational buttons serve for the purpose of selecting individual functions. A selected function is highlighted by a white outline and the text turns white. Once the function is selected, you can control it by pressing the middle button. Some functions can have more than one operational mode. -
Page 9: Time
Control panel Time The time setting is important for the proper functionality of the hot tub. The display will show set time if no time setting is saved in the memory. Select the time option in the menu. Change the clock setting by the up and down arrow buttons. Set the hours, minutes and 12/24 mode. -
Page 10: Blower
Control panel Blower Turn on the blower by pressing the AUX button on the left side of the control panel. Lighting Turn on the lights by pressing the LIGHT button on the left side of the control panel. Jets Massage jets control buttons JETS 1 and JETS 2 are located on the left side of the con- trol panel. - Page 11 Control panel To unlock the display, press the middle button to enter the menu first. Then press the middle button twice and the down arrow button once to unlock the display. To unlock a setting, select the desired item in the menu and follow by the same com- bination of buttons as for the display unlock.
-
Page 12: Standby Mode
Control panel 5 13 Hold The hold mode is used to disconnect the circulation pumps during repair service work such as cleaning or filter replacement. The mode lasts approximately 1 hour if it is not cancelled manually first. If the repair service work requires more time than that, it is best to turn off the hot tub power supply completely. -
Page 13: Scene Settings
Control panel/ Trouble shooting 5 16 Scenes (only for hot tubs equipped with said settings) Scenes are packages of function presets. They can be used to save preferred hot tub settings of different users. How to create a scene setting Turn on the preferred hot tub functions you would like to save to a scene setting. - Page 14 Trouble shooting The water flow through the heater has failed This report says that not enough water flows through the heater for the M017 warmth from the heater to get effectively distributed thus the heater has turned off. After resolving the problem, press any button to reset the heater and turn it on again.
- Page 15 Trouble shooting NON-CLASSIFIABLE REPORTS communication The control panel does not receive reports from the system. Call the failure repair service. Test software is installed test Both the control system and the test system are running at the same software time. Call the repair service. °F or °C are replaced by °T degrees °T degrees The control system is running in a test mode.
- Page 16 Trouble shooting REMINDER MESSAGES General upkeep help Reminder messages can be suppressed in the PREF. menu. See pg. 14. Reminder messages can be individually selected by the producer. They general upkeep can be cancelled altogether or a restricted amount of reminders is allowed for a specific model.
-
Page 17: Upkeep Of The Hot Tub
Upkeep of the hot tub Upkeep of the hot tub General information Do not expose the hot tub to sun without water inside or a cover on top. The direct sunlight can cause fading and deformation of the surface material. When you are not using the hot tub, cover it with the thermo cover, regardless of whether it is empty or full. - Page 18 Adjust the water pH level accordingly by suitable water chemicals (the HANSCRAFT SPA – pH PLUS and pH MINUS is recommended). Adjust the Cl (chlorine) level with suitable water chemicals (HANSCRAFT SPA – MULTI MINI 3 in 1 tablets are recommended). Follow the instructions on the chemicals‘...
-
Page 19: Replacing The Water
Upkeep of the hot tub Calcium 100–180 mg/l Overall alkalinity 80–120 mg/l Replacing the water It is important to keep the hot tub water fresh and clean. We recommend you to replace the water at least every 3 months unless the water quality drops sooner. The hot tub water can be used for watering the garden for example, given that it has not been chemically treated at least one week prior. -
Page 20: Upkeep Of The Thermo Cover And Upkeep Instructions
Upkeep of the hot tub/ Winter and summer time Upkeep of the thermo cover and upkeep instructions It is important to take a proper care of the thermo cover: clean it when necessary and treat it with a product intended especially for an eco-leather or fake leather. The guarantee does not cover damages caused by an inappropriate cleaning product. -
Page 21: Winter Time - Using The Hot Tub, All Year Operation (Slp)
Winter and summer time/Final establishments Winter time – using the hot tub, all year operation (SLP) If you decide to keep using the hot tub during the winter time, it is necessary to keep checking the hot tub for cases of for example: circuit break failure, motor not work- ing, heating not working, filter cartridge getting clogged. -
Page 22: 10 Repair Services Chart
Repair services chart/ Supplements 10 Repair services chart A TABLE FOR YOUR NOTES, PLEASE FILL OUT THE FOLLOWING INFORMATION You will need the filled out information in case of a repair requested through the customer service line Purchase date Delivery date Model name Serial number Seller information... -
Page 23: 12 Notes
Notes 12 Notes... - Page 24 7. 7. 2021 HANSCRAFT, s r o Safety K Vodojemu 140 Regular 252 19 Chrášťany u Prahy Production CZECH REPUBLIC Surveillance w w w H A N S C R A F T eu w w w.tuv.com ID 0000073072...
