- Page 1 USER MANUAL SPATOUCH 2...
-
Page 2: Table Of Contents
Contents Hot tub performance specifications . . . . . . . . . . . . . . . . . . . . . . . . Preparation for the installation of the hot tub . -
Page 3: Hot Tub Performance Specifications
Hot tub performance specifications For your own safety and the safety of your product, please observe the following instructions . Read the following information carefully and follow the user manual exactly when using the hot tub to avoid damaging the product or the risk of injury . This appliance is intended for use by children 8 years of age or older with reduced physical, sensory or mental capabilities, or lack of experience and knowledge, provided they are under supervision or have been instructed on the use of the... -
Page 4: Preparation For The Installation Of The Hot Tub
Preparation for the installation of the hot tub Recommended Type C circuit breaker Hot tubs with two massage motors: 3× 16 A /C or D Hot tubs with three massage motors: 3× 20 A/C or D !!!THE HOT TUB MUST ONLY BE CONNECTED BY A PERSON WITH PROFESSIONAL ELECTRICAL QUALIFICATION IN ACCORDANCE WITH DECREE NO . -
Page 5: Preparation For The Interior Hot Tub Installation
Preparation Installation of the hot tub 2 .2 Preparation for the interior hot tub installation If the hot tub is installed in an interior space, it is necessary to comply with safety instructions. The basic safety requirements are mainly non-skid floors and drainage in the place of the installation in case of a water overflow. -
Page 6: Filling The Hot Tub With Water
Installation of the hot tub/Audio system Aquatic 3 .2 Filling the hot tub with water Fill the hot tub with a sufficient amount of water. The level of water in the hot tub cannot ever fall under the skimmer level. If you notice a water leak, stop the water until the defect is fixed. -
Page 7: Control Panel
Control panel Control panel (BALBOA SpaTouch 2) 5 . 1 Main information on display display rotation lock active WiFi time units °C / °F ozone filtration cycle heating mode temperature range light non-active button system notification temperature setting heating indication... -
Page 8: Time
Control panel Filter cycle 2 Filter cycle 2 is off by default. If you want to turn it on, simply go to the line Filter Cycle 2 and set it in the same way as Filter Cycle 1. Filter 00:00 00:00 Settings Filter... -
Page 9: Blower
Control panel Heating mode ready in this mode the whirlpool heats the water to the set temperature economical in this mode the whirlpool only heats the water at the time of filtration Temperature range high 79 .88 –104 °F 50 – 98 .6 °F 5 .6 Blower Select the nozzle button on the main screen. -
Page 10: Jets
Control panel 5 .8 Jets Select the jets button on the main screen. Select the jets in the following menu (the number and function of the buttons depends on the settings of the control unit and the whirlpool equipment). If the function is active, the button is highlighted. The intensity at which the pump is on is represented by the wheels that circulate the button around the wheel. -
Page 11: Lock
Control panel press the setup button, then press the right arrow. In this menu, you can set, for example, the temperature and time units, the language, or the control panel sleep timer. Settings Settings Units Language Info Tools setting the temperature screen off (timing) and units °C or °... -
Page 12: 5 . 1 2 Hold-On Mode
Control panel /Trouble shooting 5 . 1 2 Hold-on mode The hold mode is used to disconnect the pumps during servicing, such as cleaning or filter replacement. Hold mode will last for 1 hour unless canceled manually. If it takes more time to service the spa, it is better to turn off the power to the spa. - Page 13 Trouble shooting Show up when conditions of possible water freezing are detected or the conditions AUX freeze switch has turned off while the circulation pumps and jets are of possible turned on. In some cases the circulation pumps can turn on and off and freezing the heater can run in the freeze protection mode.
- Page 14 Trouble shooting Checking the water flow Check whether the water flow is not too low, whether there is an obstacle in the area of water suction, whether the valves are not closed, check for air pockets and too many closed jets. Some devices can occasionally turn on by themselves to enable temperature monitoring or requested freeze protection, even when the hot tub is turned off.
- Page 15 Trouble shooting Configuration failure (the hot tub will not turn on) hot tub will not turn on Contact your seller or repair services. The circulation pump appears stuck The water can be too hot. DISCONNECT THE HOT TUB FROM THE M034 POWER SUPPLY. DO NOT ENTER THE HOT TUB. Contact your seller or repair services.
-
Page 16: Upkeep Of The Hot Tub
Trouble shooting Upkeep of the hot tub treat the Shows up regularly, for example once every 180 days. The cabinet wooden and wooden equipment of the hot tub should be cleaned and treated surface according to the producer instructions to keep their maximum longevity. Shows up regularly, for example once every 365 days. -
Page 17: Maintaining The Quality Of The Water In The Hot Tub
Adjust the water pH level accordingly by suitable water chemicals (the HANSCRAFT SPA – pH PLUS and pH MINUS is recommended). Adjust the Cl (chlorine) level with suitable water chemicals (HANSCRAFT SPA – MULTI MINI 3 in 1 tablets are recommended). Follow the instructions on the chemicals‘... -
Page 18: Replacing The Water
Upkeep of the hot tub Ideal chemical levels 0.7–1.0 mg/l Free chlorine concentration (10–15 mg/l) (active oxygen concentration) pH level 7.0–7.6 Calcium 100–180 mg/l Overall alkalinity 80–120 mg/l 7 .4 Replacing the water It is important to keep the hot tub water fresh and clean. We recommend you to replace the water at least every 3 months unless the water quality drops sooner. -
Page 19: Upkeep Of The Thermo Cover And Upkeep Instructions
Upkeep of the hot tub Winter and summer time WARNING: For safety and damage prevention reasons, do not sit, stand or lie on top of the cover . Do not place any objects on top of it . The thermo cover does not serve as a fence around the bathing area either . -
Page 20: Winter Time - Using The Hot Tub, All Year Operation (Slp)
Winter and summer time/Final establishments If you decide to use our professional services, it is necessary to order them sufficient amount of time in advance. In case of winterizing the hot tub by yourself, it is crucial to do it when the air temperature is still above zero. If the winterizing is done in tem- peratures below zero, it can be very difficult because water in the motors could have frozen already and damaged some parts of the hot tub. -
Page 21: 10 Repair Services Chart
Repair services chart/Supplements 10 Repair services chart A TABLE FOR YOUR NOTES, PLEASE FILL OUT THE FOLLOWING INFORMATION . You will need the filled out information in case of a repair requested through the customer service line . Purchase date Delivery date Model name Serial number... -
Page 22: Notes
Notes 12 Notes... - Page 23 Notes...
- Page 24 14. 7. 2022 HANSCRAFT, s .r .o . Safety K Vodojemu 140 Regular 252 19 Chrášťany u Prahy Production CZECH REPUBLIC Surveillance w w w . H A N S C R A F T .eu w w w.tuv.com ID 0000073072...
