Microwave Oven
User manual
NQ50K5137 **
NQ50K5137KB_EU_DE68_04356H-00_EN.indd 1
2016-12-26
4:51:14

Advertisement

Table of Contents
loading
Need help?

Need help?

Do you have a question about the NQ50K5137 Series and is the answer not in the manual?

Questions and answers

Subscribe to Our Youtube Channel

Related Manuals for Samsung NQ50K5137 Series

Summary of Contents for Samsung NQ50K5137 Series

  • Page 1 Microwave Oven User manual NQ50K5137 ** NQ50K5137KB_EU_DE68_04356H-00_EN.indd 1 2016-12-26 4:51:14...

  • Page 2: Table Of Contents

    Contents Operations Safety instructions Control panel Important safety instructions Types of heating Correct Disposal of This Product (Waste Electrical & Electronic Equipment) Microwave mode Cooking instructions Auto mode Installation Cooking Smart What’s included Auto cooking Installation instructions Microwave cooking guide Install in the Built-in cabinet Troubleshooting Maintenance...

  • Page 3: Safety Instructions

    Safety instructions • by clients in hotels, motels and other residential IMPORTANT SAFETY INSTRUCTIONS environments; READ CAREFULLY AND KEEP FOR FUTURE REFERENCE. • bed and breakfast type environments. MICROWAVE FUNCTION ONLY Only use utensils that are suitable for use in microwave ovens. WARNING: If the door or door seals are damaged, the oven When heating food in plastic or paper containers, keep an eye on the oven due to the possibility of ignition.
  • Page 4 Safety instructions Eggs in their shell and whole hard-boiled eggs should not be This appliance can be used by children aged from 8 years and heated in microwave ovens since they may explode, even after above and persons with reduced physical, sensory or mental microwave heating has ended.
  • Page 5 OVEN FUNCTION ONLY - OPTIONAL Children less than 8 years of age shall be kept away unless continuously supervised. WARNING: When the appliance is operated in the combination This appliance can be used by children aged from 8 years and mode, children should only use the oven under adult above and persons with reduced physical, sensory or mental supervision due to the temperatures generated.
  • Page 6 While the oven is operating, do not turn it off by unplugging the power cord. Do not insert fingers or foreign substances. If foreign substances enter the oven, unplug the power cord and contact a local Samsung service centre. 6 English NQ50K5137KB_EU_DE68_04356H-00_EN.indd 6...
  • Page 7 Microwave operation precautions Microwave oven precautions Only use microwave-safe utensils. Do not use metallic containers, gold or silver Failure to observe the following safety precautions may result in harmful exposure trimmed dinnerware, skewers, etc. to microwave energy. Remove wire twist ties. Electric arcing may occur. •...
  • Page 8 Limited warranty Product group definition Samsung will charge a repair fee for replacing an accessory or repairing a cosmetic This product is a Group 2 Class B ISM equipment. The definition of group 2 which defect if the damage to the unit or accessory was caused by the customer. Items...

  • Page 9: Correct Disposal Of This Product (Waste Electrical & Electronic Equipment)

    IMPORTANT: Always remember that cooking instructions are intended only as a For information on Samsung’s environmental commitments and product specific guide. If you have followed the instructions and the food is still not piping hot regulatory obligations e.g.

  • Page 10: Installation

    The following accessory is provided with your microwave oven. Make sure all parts and accessories are included in the product package. If you have a problem with the oven or accessories, contact a local Samsung customer centre or the retailer. Oven at a glance Ceramic tray (Useful for microwave mode.)

  • Page 11: Installation Instructions

    Install in the Built-in cabinet Kitchen built-in cabinets in contact with the oven must be General Technical Information heatresistant up to 100 °C. Samsung will take no responsibility Electrical Supply 230 V ~ 50 Hz for damage of built-in cabinets from the heat.
  • Page 12 Installation Under-sink built-in cabinet (mm) 3. Fasten the oven using the two screws (4 x 25 mm) provoded. Min. 550 Min 564 / Max. 568 Min. 446 / Max 450 200 cm 4. Make the electrical connection. Check that the appliance works.

  • Page 13: Maintenance

    Rinse and dry well. centre for technical assistance. • If you want to replace the light bulb, contact a local Samsung To remove stubborn impurities with bad smells from inside the oven service centre.

  • Page 14: Before You Start

    Before you start When the appliance is first plugged in, the display lights up. After three seconds, Setting the energy save mode the clock symbol and “12:00” blink on the display. Energy save mode saves electricity when the oven is not being used. Clock settings Standby mode 1.

  • Page 15: About Microwave Energy

    About microwave energy Cookware for microwave Microwaves are high-frequency electromagnetic waves. The oven uses the prebuilt Cookware used for Microwave Mode must allow microwaves to pass through magnetron to generate microwaves which are used to cook or reheat food without and penetrate food.

  • Page 16: Operations

    Operations Control panel Microwave- Material Description safe The front panel comes in a wide range of materials and colours. For improved quality, the actual appearance of the oven is subject to change without notice. Microwave-safe unless Oven-to-table ware decorated with metal trims. Delicate glassware may break Glassware Fine glassware...

  • Page 17: Types Of Heating

    Types of heating Microwave mode The following chart summarizes the various heating modes and settings available Step 1. Select mode on your oven. Use the Cooking Guides in the pages that follow to determine the Press the Mode button once. appropriate mode and setting for all your recipes.
  • Page 18 Operations To change the cooking time during cooking Microwave Microwaves are high-frequency electromagnetic waves. The microwave energy 1. Press the Cooking Time button. enables food to be cooked or reheated without changing either the form or the 2. Press the Up and Down button to adjust colour.

  • Page 19: Auto Mode

    Auto mode Auto Reheat/Cook The oven offers 15 auto reheat/cook programmes for your convenience. The time The oven offers 2 different auto modes for your convenience: Auto Reheat/Cook and power level are automatically adjusted according to the selected programme. and Auto Defrost. Select one that best fits your needs. Step 1 Step 2 Step 3...
  • Page 20 Operations Steam cleaning WARNING This is useful for cleaning light soiling with steaming. Do not open the door before the cycle is complete. The water inside the oven is very hot, and it can cause a burn. 1. Pour 100 ml of water onto the bottom of the oven and close the oven door.

  • Page 21: Cooking Smart

    Cooking Smart Auto cooking Code Food Weight (kg) Instructions Pop corn Use special popcorn product for preparing Auto Reheat/cook guide in microwave oven. Follow the instructions of food manufacturer and put the bag in the Code Food Weight (kg) Instructions center of ceramic tray.
  • Page 22 Cooking Smart Auto defrost guide Code Food Weight (kg) Instructions Code Food Weight (kg) Instructions Peeled 0.5-0.6 Weigh the potatoes after peeling, washing Potato 0.7-0.8 and cutting into a similar size. Put them Meat 0.2-2.0 Shield the edges with aluminium foil. Turn into a glass bowl with lid.

  • Page 23: Microwave Cooking Guide

    Microwave cooking guide Code Food Weight (kg) Instructions Fruit 0.1-0.8 Distribute frozen fruit evenly on ceramic General guidelines tray. This programme is suitable for fruits like raspberries, mixed berries, and tropical fruits. Food suitable for microwave cooking Stand for 5-15 minutes. Many kinds of food are suitable for microwave cooking, including fresh or frozen vegetables, fruit, pasta, rice, grains, beans, fish, and meat.
  • Page 24 Cooking Smart Portion Power Time Standing Portion Time Standing Food Instructions Food Instructions (min.) time (min.) (min.) time (min.) Mixed Add 15 ml (1 tbsp.) Courgettes Cut courgettes into slices. Add Vegetables cold water. 30 ml (2 tbsp.) water or a (Carrots/Peas/ knob of butter.
  • Page 25 Cooking guide for rice and pasta Reheating Use a large glass Pyrex bowl with lid. (Note that rice doubles in volume Your microwave oven will reheat food in a fraction of the time a conventional Rice: during cooking.) Cook covered. After cooking time is over, stir before oven takes.
  • Page 26 Cooking Smart Reheating baby food Standing Food Portion Power Time time Instruction Baby food (min.) Extra caution should also be exercised when reheating baby foods. Put food into a deep ceramic plate. Cover with plastic lid. Stir well after reheating. Let stand Baby Porridge 190 g 600 W...
  • Page 27 Reheating liquids and food Defrosting Use the power levels and times in this table as guide lines for reheating. Microwaves are an excellent way of defrosting frozen food. Microwaves gently defrost frozen food in a short period of time. This can be a great advantage, if Standing unexpected guests suddenly show up.

  • Page 28: Troubleshooting

    You may encounter a problem using the oven. In that case, first check the table below and try the suggestions. If a problem persists, or if any information code Portion Time Standing Food Instructions keeps appearing on the display, contact a local Samsung service centre. (min.) time (min.) POULTRY Checkpoints Chicken 12-14...
  • Page 29 Troubleshooting Problem Cause Action Problem Cause Action The power turns off The oven has been cooking After cooking for an The door cannot be Food residue is stuck Clean the oven and then during operation. for an extended period of extended period of time, let opened properly.
  • Page 30 Troubleshooting Problem Cause Action Problem Cause Action The thaw function The oven may not work, Put one cup of water in a There is electricity The power or power socket Make sure the power and does not work. too much food is being microwave-safe container coming from the is not properly grounded.

  • Page 31: Information Codes

    Press the Stop button to try C-F2 again. Unplug the power cord for cooling enough time, and The touch key is malfunction. clean the button. (Dust, Water) C-d0 When appear same problem, contact a local Samsung service centre. English 31 NQ50K5137KB_EU_DE68_04356H-00_EN.indd 31 2016-12-26 4:51:24...

  • Page 32: Technical Specifications

    Technical specifications Technical specifications SAMSUNG strives to improve its products at all times. Both the design specifications and these user instructions are thus subject to change without notice. By right of the common regulation 2/1984 (III.10) BKM-IpM. we as distributors testify, that the NQ50K5137** oven of Samsung comply with the undermentioned technological parameters.
  • Page 33 Memo NQ50K5137KB_EU_DE68_04356H-00_EN.indd 33 2016-12-26 4:51:24...
  • Page 34 Memo NQ50K5137KB_EU_DE68_04356H-00_EN.indd 34 2016-12-26 4:51:24...
  • Page 35 Memo NQ50K5137KB_EU_DE68_04356H-00_EN.indd 35 2016-12-26 4:51:24...
  • Page 36 Please be advised that the Samsung warranty does NOT cover service calls to explain product operation, correct improper installation, or perform normal cleaning or maintenance. QUESTIONS OR COMMENTS? COUNTRY CALL OR VISIT US ONLINE AT 0800-SAMSUNG (0800-7267864) AUSTRIA [Only for Premium HA] 0800-366661 www.samsung.com/at/support...
