Input; Picture - NEC MultiSync V404-T User Manual

Setting

INPUT

DVI
HDMI1
HDMI2
DisplayPort1
DisplayPort2
VGA (RGB/YPbPr)
VIDEO
MP
COMPUTE MODULE*
5
OPTION* 3


PICTURE MODE
BRIGHTNESS* 1
BACKLIGHT
BRIGHTNESS*
2
GAMMA* *
1, 2
NATIVE
2.2
2.4
S GAMMA
DICOM SIM.
PROGRAMMABLE1, 2, 3 A programmable gamma curve can be loaded using optional NEC software.
COLOR*
2
COLOR
COLOR
TEMPERATURE*
1
COLOR CONTROL
HUE*
4
MP, VIDEO inputs only
CONTRAST* 1, * 2
SHARPNESS*
1
*1: If SPECTRAVIEW ENGINE is ON, this function is grayed out.
*2: This function is not available when sRGB is selected at PICTURE MODE.
*3: When you select OPTION for signal input, this function depends on which option board you are using.
*4: This function is not available for still image by MP input.
*5: This function is only available when Raspberry Pi Compute Module Interface Board and Raspberry Pi Compute Module are installed.
Select input signal.
Displays images or movies saved in microSD memory card or USB storage device. Please refer to the Media
Player setting (See page 21).
Select input signal.
Select input signal.
Select picture mode:
SpectraView Engine = OFF: [HIGHBRIGHT], [STANDARD], [sRGB], [CINEMA], [CUSTOM1], [CUSTOM2].
SpectraView Engine = ON: [SVE-1 SETTINGS], [SVE-2 SETTINGS], [SVE-3 SETTINGS], [SVE-4 SETTINGS] or
[SVE-5 SETTINGS]. See page 28.
NOTE: If WHITE is set to NATIVE when the SPECTRAVIEW is ON, WHITE is not functioning.
To be able to set the CUSTOM VALUE, please set CST at GAMMA.
Adjusts the overall image and background brightness. Press + or - to adjust.
NOTE: When MODE1 or MODE2 is selected in ROOM LIGHT SENSING, this function cannot be changed.
Adjusts the image brightness in relationship to the background. Press + or - to adjust.
Select a monitor gamma correction for best picture quality. Selection depends on the desired usage.
Gamma correction is handled by the LCD panel.
Typical monitor gamma for use with a computer.
Good for video (DVD, etc.)
Special gamma for certain types of movies. Raises the dark parts and lowers the light parts of the image
(S-Curve).
DICOM GSDF curve simulated for LCD type.
Adjusts the color depth of the screen. Press + or - to adjust.
Adjusts the color temperature of the entire screen. A low color temperature will result in a reddish screen. A high
color temperature will make the screen bluish. If TEMPERATURE needs further adjustment, the individual R/G/B/
levels of the white point can be adjusted. To adjust the R/G/B levels, set CUSTOM as COLOR TEMP selection.
NOTE: Predefined 6500k is set as picture mode, a color temperature of 6500k is predefined so it cannot be
changed.
When PROGRAMMABLE1, PROGRAMMABLE2 or PROGRAMMABLE3 is selected in GAMMA CORRECTION,
this function cannot be changed.
Adjusts the hue of the Red, Yellow, Green, Cyan, Blue and Magenta.
Adjusts the hue of the screen. Press + or - to adjust.
Adjusts the image brightness in relationship to the input signal. Press + or - to adjust.
Adjusts the crispness of the image. Press + or - to adjust.
English-32
