Specifications

Autograph Mini
PERFORMANCE
Recommended amplifier power
Continuous power handling
Frequency response
Sensitivity
Nominal impedance
DRIVE UNITS
Dual Concentric™ high frequency
Dual Concentric™ low frequency
Dispersion
CROSSOVER
Frequency
Type
CONSTRUCTION
Enclosure type
Volume
Dimensions
Weight
Finish
20 - 100 Watts
50 Watts RMS
68Hz - 54kHz -6dB
88dB (2.83 Volts @ 1 metre)
8 Ohms
19mm (0.75") titanium dome with Tulip WaveGuide™
100mm (4.00") treated paper pulp cone with rubber
surround. 33mm (1.33") edge wound voice coil
90 degrees conical
2.3kHz
Passive low loss 2nd order compensated LF, 1st order
compensated HF
Rear ported
3.5L (213.5 cu.ins")
345 x 210 x 130mm
(13.50 x 8.25 x 5.00")
4.0kg (8.8 lbs)
Teak veneer with solid teak trim detail
