Summary of Contents for Tannoy i15
- Page 1 USER MANUAL...
-
Page 2: Table Of Contents
CONTENTS 1. Introduction 2. Unpacking 3. Connectors/Cabling 4. Polarity Checking 5. Amplification & Power Handling 6. Crossovers 7. Equalisation 8. Dimensions 9. Rigging 10. Performance Data 11. Technical Specifications 12. i15 Recommended Service Parts & Accessories 13. Warranty 14. Wall Mounting Bracket - Assembly Instructions 15. -
Page 3: Introduction
1. Introduction The Tannoy i15 professional loudspeaker has been designed for a wide variety of sound reinforcement applications requiring extended frequency response from a compact system, capable of delivering high sound pressure levels with extremely low distortion, resulting in outstanding clarity, definition and detail. -
Page 4: Polarity Checking
Should you encounter any problems obtaining Speakon connectors, please contact Neutrik or its distributors directly on the following numbers:- UK: N EUTRIK ARKETING: 0171 792 8188 USA: N USA I EUTRIK NC.: (201) 901 9488 For a world wide list of distributors, please contact Neutrik directly:- +41 7529666 EUTRIK Cable choice consists mainly of selecting the correct cross sectional area in relation... -
Page 5: Amplification & Power Handling
If higher peak outputs are required then the i15 can be used in conjunction with the Tannoy TX2 controller/crossover which provides high pass filtering and a degree of parametric equalisation (see performance data section), as well as a fixed crossover point for use with sub-bass loudspeakers. -
Page 6: Dimensions
8. Dimensions... -
Page 7: Rigging
9. Rigging... -
Page 8: Performance Data
10. Performance Data... -
Page 9: Technical Specifications
Tannoy operate a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications which Tannoy reserve the right to alter without prior notice. Please verify the latest specifications when dealing with critical applications. -
Page 10: I15 Recommended Service Parts & Accessories
13. Warranty No maintenance of the i15 loudspeaker is necessary. All Tannoy professional loudspeaker products are covered by a 5 year warranty from the date of manufacture subject to the absence of misuse, overload or accidental damage. Claims will not be considered is the serial number has been altered or removed. -
Page 11: Wall Mounting Bracket - Assembly Instructions
14. Wall Mounting Bracket - Assembly Instructions A dedicated wall mounting bracket (Part No. 8000 0671) is available for the i15. The design of the bracket allows the loudspeaker to mounted either in portrait or landscape orientation:- Landscape mounting - Remove two of the original M8 countersunk screws on one side of the cabinet, place the T- Bar in position and fix in place using the two cap- head bolts which are included along with the bracket hardware, remembering to use the washers and locking washers which are also provided. -
Page 12: Declaration Of Conformity
Declaration of Conformity The following apparatus is/are manufactured in the United Kingdom by Tannoy Ltd of Rosehall Industrial estate, Coatbridge, Scotland, ML5 4TF and conform(s) to the protection requirements of the European Electromagnetic Compatibility Standards and Directives relevant to Domestic Electrical Equipment. The apparatus is...
