Summary of Contents for Tannoy AMS 5
- Page 1 AMS SERIES Surface mount loudspeakers All AMS 5 Models All AMS 6 Models All AMS 8 Models Quick Start Guide...
- Page 2 This Quick Start Guide (QSG) provides the basic information required to install and connect all 1. Fix the yoke bracket to an appropriate structural models in the Tannoy AMS range of surface-mount surface using a suitable fixing method. loudspeakers. 2. Remove the yoke trims from the product to For additional information, including product access the bracket fixing points.
- Page 3 7. Connect the euro plug. If required, replace the rubber grommet and fit snugly for a watertight seal. 8. Connect a secondary support line to the safety tab at the rear of the cabinet. 5 Setting transformer taps 1. The rotary transformer tapping switch is found on the top of models with 5-inch drivers, and on the bottom of models with 6-inch and 8-inch drivers.
- Page 4 Tannoy operates a policy of continuous research and development. The introduction of new materials or manufacturing methods will always equal or exceed the published specifications. All specifications are subject to change without notice. Copyright (c) 2015 Tannoy Limited. All rights reserved.
