Summary of Contents for Tannoy Autograph Mini
- Page 1 Autograph Mini SERVICE MANUAL...
- Page 2 Technical Manual Contents • Introduction – The Technical Manual explained Page 2 • Technical Specs – Specifications relating to this particular item. Page 3 • Instructions – For faultfinding, assembly & disassembly. Page 4 • Spares Drawing – All spare parts available to order for your loudspeaker as well as additional spares including the likes of spikes &...
- Page 3 Technical Manual Explained This Manual is designed to help you and your customers. In this manual you will find all information you will need regarding service to your Tannoy loudspeaker including technical specs, instructions for assembly, disassembly & faultfinding, spares drawings & parts lists as well as a detailed explanation of how to go about returning parts under warranty.
-
Page 4: Specifications
Specifications Autograph Mini PERFORMANCE Recommended amplifier power 20 - 100 Watts Continuous power handling 50 Watts RMS Frequency response 68Hz - 54kHz -6dB Sensitivity 88dB (2.83 Volts @ 1 metre) Nominal impedance 8 Ohms DRIVE UNITS Dual Concentric™ high frequency 19mm (0.75”) titanium dome with Tulip WaveGuide™... -
Page 5: Fault Finding
Fault Finding Tannoy loudspeakers are designed and manufactured to be reliable. When a fault occurs in a hi-fi system the effect is always heard through the loudspeakers although they may not be the source of the fault. It is important to trace the cause of the problem as accurately as possible. - Page 6 Page 5...
- Page 7 Method: 1. You - Fill in the complete product failure details on to the attached Field Failure Report template, including product serial number, and then fax or e-mail to Tannoy Service Department. Fax: +44 (0) 1236 428230 or E-mail: service@tannoy.com 2.
- Page 8 Customer Complaint / Fault Report Internal Use Only: Warranty Decision: Source Area: Report No: Customer Section: Product Description: Part Number: Date: Customer / Distributor: 20-Digit Product Barcode Number (MANDATORY): Detailed description of problem/ fault (MANDATORY): Insert pictures below: Please be aware that we cannot accept field-failure reports that do not have mandatory sections completed.
- Page 9 FOR GUIDANCE Diagnosis of low frequency driver failures resulting from misuse:- SYMPTOM PROBABLE CAUSE Charred voice coil Under powered amplifier clipping; Excessive peak amplifier power; DC at amp output (amp failure) Under powered amplifier clipping; Excessive peak amplifier power; Excessive low frequency equalisation applied F u s e d , b r o k e n o r b l a c k e n e d l e a d o u t w i r e s Excessive peak amplifier power;...
- Page 10 - Quote you a Returns Authorization Number and send you an Export Returns Authorization Form, by fax or e-mail. 3. Y - Fill in all the relevant details in the form and send it to Tannoy, before arranging shipment. 4. W –...
-
Page 11: Warranty Policy
If you suspect a problem with your loudspeakers then in the first instance discuss it with your Tannoy Dealer. The Dealer has the expertise and experience to help you troubleshoot the system and assess the situation. - Page 12 NOTES Page 11...
- Page 13 NOTES Page 12...
