This assembly manual describes the design, function and assembly of the “VESA VSM Loudspeaker Mount” and the “VESA VSM XL Loudspeaker Mount”. It is aimed at system technicians and persons assigned the task of installing and operating a relevant system.
The screws included in the assembly kit marked with * must be used to mount the VESA monitor mount with the VESA VSM / VSM XL loudspeaker mount on the display. If these screws cannot be used due to their length and shape, they must be replaced by suitable screws by the person assem- bling the system.
XL loudspeaker mount including the loudspeakers in accordance with the applicable safety regu- lations. • Only the original parts delivered by Pan Acoustics may be used for mounting and assembling the VSM / VSM XL loudspeaker mount. The use of other parts, in particular parts from unknown or third-party manufacturers, is prohibited.
National safety regulations for operation and assembly must be followed. CONNECTION OF THE LOUDSPEAKER AND MOUNT • All mounts sourced via Pan Acoustics are delivered with suitable assembly material for connec- tion to the loudspeaker. • The connection between the loudspeaker and the mount is made by fi xing points (e.g. a slot nut, which is inserted into the rear slot of the loudspeaker and tightened with two M6 set screws).
